Industrial Digital Input Solution – Weidmuller 1315700000 UR20-4DI-P | u-remote Series
Where This Product Is Used
The Weidmuller UR20-4DI-P (Part No. 1315700000) is a 4-channel digital input I/O module from the u-remote decentralized I/O system. It is deployed across a wide range of industrial environments where reliable, high-speed digital signal acquisition is critical:
- Automated Assembly Lines – Captures proximity sensor and limit switch signals for conveyor positioning and part detection.
- Process Plants & Chemical Facilities – Monitors valve position feedback, flow switches, and level sensors in hazardous or demanding environments.
- Machine Tool & CNC Systems – Interfaces with door interlocks, tool presence sensors, and safety switches for machine cycle control.
- Packaging & Material Handling – Reads encoder pulses and photoeye signals for product counting and sorting logic.
- Water & Wastewater Treatment – Acquires digital status signals from pumps, valves, and level switches in distributed field cabinets.
- Building Automation & HVAC – Integrates with BMS controllers to monitor damper positions, fan status, and alarm inputs.
Technical Specifications
- Part Number: 1315700000
- Model: UR20-4DI-P
- Series: u-remote
- Manufacturer: Weidmuller
- Module Type: Digital Input (DI)
- Number of Channels: 4
- Input Voltage: 24 V DC (PNP / P-switching)
- Input Current: Typ. 3 mA per channel
- Signal Type: PNP (positive switching)
- Electrical Isolation: Yes (channel group to backplane bus)
- Connection Method: Push-in spring clamp (tool-free)
- Fieldbus Compatibility: PROFIBUS, PROFINET, EtherNet/IP, Modbus TCP, CANopen, DeviceNet (via u-remote head station)
- Operating Temperature: -25 °C to +60 °C
- Protection Rating: IP20
- Weight: 91 g
- Mounting: DIN rail (35 mm)
- Certifications: CE, UL, cUL, ATEX (zone 2/22 with appropriate head station)
Why Engineers Specify This Model
- Tool-Free Wiring: Push-in spring clamp terminals dramatically reduce panel wiring time versus screw terminals — critical for high-density cabinet builds.
- Modular Scalability: The u-remote system allows engineers to mix DI, DO, AI, AO, and specialty modules on a single backplane, minimizing BOM complexity.
- Fieldbus Agnostic: One hardware platform supports all major industrial protocols via interchangeable head stations — future-proofing the installation.
- Compact Footprint: Slim module width maximizes channel density per DIN rail meter, essential in space-constrained enclosures.
- Diagnostic LEDs: Per-channel status indication enables rapid fault isolation without a laptop or SCADA access.
- Wide Temperature Range: Rated to -25 °C, suitable for outdoor field cabinets and cold-storage automation.
Complete System Bill of Materials
To build a fully operational u-remote I/O station with this module, the following components are typically required:
- u-remote Head Station (e.g., UR20-FBC-PN for PROFINET, UR20-FBC-PB for PROFIBUS)
- UR20-4DI-P Digital Input Module (this item – P/N 1315700000)
- u-remote Power Feed Module (UR20-PF-O-1DI-SIL or standard power feed)
- u-remote End Bracket / Bus End Cover
- 24 V DC DIN Rail Power Supply (e.g., Weidmuller PRO ECO 24V)
- 35 mm DIN Rail (steel or aluminum)
- Field wiring: 0.14–1.5 mm² flexible conductors for push-in terminals
Compliance & Industry Standards
- CE Marking – EU Low Voltage Directive & EMC Directive compliant
- UL 508 / cUL – Industrial Control Equipment (North America)
- IEC 61131-2 – Programmable Controllers: Equipment Requirements & Tests
- EN 61000-6-2 / EN 61000-6-4 – Industrial EMC Immunity & Emission
- ATEX / IECEx Zone 2 / Zone 22 – Explosive atmosphere suitability (with certified head station)
- RoHS Compliant – Restriction of Hazardous Substances
Quality Assurance & Sourcing
Konmask.com sources the Weidmuller 1315700000 exclusively through verified industrial distribution channels. Every unit is:
- Inspected against Weidmuller factory labeling and date codes
- Stored in ESD-safe, climate-controlled warehousing
- Shipped with original manufacturer packaging and documentation
- Traceable to authorized supply chain records
We do not supply grey-market, refurbished, or counterfeit components. All parts carry the original Weidmuller warranty.
How to Source This Part
- In Stock: Add to cart and check out directly — most orders ship within 1–3 business days.
- Bulk / Project Quantity: Contact us for volume pricing and lead-time commitments on quantities of 10+.
- Urgent Requirement: Email [email protected] or call +0086 19859288691 for expedited sourcing.
- System Integration Support: Our engineering team can advise on compatible head stations, power feeds, and fieldbus configuration for your specific application.
Application-Specific FAQ
Q: Is the UR20-4DI-P compatible with SIEMENS S7-1500 via PROFINET?
A: Yes. Pair it with the UR20-FBC-PN head station and import the GSDML file into TIA Portal for seamless integration.
Q: Can this module be used in a Zone 2 hazardous area?
A: The module itself is IP20 rated for standard enclosures. When used with an ATEX-certified u-remote head station and installed in a suitable Ex e enclosure, Zone 2 / Zone 22 operation is supported.
Q: What sensor types are compatible with the PNP inputs?
A: Any PNP (sourcing) 24 V DC sensor — including inductive proximity sensors, photoelectric sensors, magnetic reed switches, and push-buttons with PNP output.
Q: How many UR20-4DI-P modules can be connected to one head station?
A: Up to 32 I/O modules (mix of DI, DO, AI, AO) per u-remote head station, subject to total current consumption limits.
Q: Is a configuration tool required for commissioning?
A: No software configuration is required for the module itself. The head station handles all fieldbus addressing. Diagnostic data is accessible via the fieldbus master.
