Industrial Control Panel Wiring Solution – WEIDMULLER SAKDU4 | SAKDU Series
Where This Product Is Used
The WEIDMULLER SAKDU4 INTERFACE terminal block is a core wiring component deployed across a wide range of industrial automation and electrical distribution environments. Engineers and panel builders specify this model in:
- PLC Control Panels — Signal and power distribution between PLCs (Siemens S7, Allen-Bradley, Mitsubishi, Omron) and field devices, sensors, and actuators.
- DCS Marshalling Cabinets — Structured I/O termination in distributed control systems for process industries including oil & gas, chemical, and water treatment.
- Motor Control Centers (MCC) — Control wiring termination for motor starters, VFDs, and protection relays.
- Machine Tool & Robotics Panels — Compact, reliable termination in CNC machine cabinets and robotic cell junction boxes.
- Building Automation Systems (BAS) — HVAC, fire alarm, and access control panel wiring where reliable, labeled termination is required.
- Railway & Transportation Infrastructure — Vibration-resistant termination in trackside cabinets and rolling stock control systems.
- Renewable Energy Installations — Solar inverter combiner boxes and wind turbine control panels requiring IEC-compliant termination.
Technical Specifications
| Manufacturer | WEIDMULLER |
| Part Number / SKU | SAKDU4 |
| Series | SAKDU |
| Type | Feed-through terminal block (INTERFACE) |
| Nominal Cross Section | 4 mm² |
| Connection Method | Screw clamp |
| Mounting | DIN 35 rail (EN 60715) |
| Conductor Range | 0.5 – 6 mm² (AWG 20–10) |
| Rated Voltage | 800 V (IEC) / 600 V (UL) |
| Rated Current | 32 A |
| Insulation Material | Polyamide (PA 66), UL 94 V-0 |
| Color | Grey (standard) |
| Degree of Protection | IP 20 (installed) |
| Operating Temperature | -50 °C to +120 °C |
| Weight | 2,140 g (per pack) |
| Standards | IEC 60947-7-1, UL 508, CSA C22.2 |
Why Engineers Specify This Model
- Proven SAKDU Platform — The SAKDU series is one of Weidmüller’s most established terminal block families, with decades of field-proven reliability in harsh industrial environments.
- 4 mm² Nominal Cross Section — Ideal sweet spot for 24 VDC control circuits and low-voltage power distribution up to 32 A, covering the majority of panel wiring requirements.
- Screw Clamp Reliability — Vibration-resistant screw termination ensures long-term connection integrity without re-torquing, critical for maintenance-intensive facilities.
- Full Accessory Ecosystem — Compatible with Weidmüller end brackets, jumpers, marking systems (WMB, THM), and test plugs for complete panel engineering.
- UL + IEC Dual Certification — Accepted by inspectors and integrators in both North American and international projects without substitution.
- High-Density Packing — Slim profile allows maximum terminal count per DIN rail meter, reducing cabinet footprint and material cost.
Complete System Bill of Materials
For a complete SAKDU4-based termination assembly, engineers typically specify the following Weidmüller accessories:
- End Bracket — EW 35 (end stop for DIN rail)
- Jumper Bar — QB 4/..N (cross-connection jumper for SAKDU4)
- Marking System — WMB 6/5 (snap-in marker strips) or THM 5/5 (heat-shrink markers)
- Test Plug — P 4/..N (for in-circuit testing without disconnection)
- Partition Plate — ZTW 4 (phase separation between adjacent terminals)
- Ground Terminal — SAKDU4 PE (green/yellow, same series)
- DIN Rail — TS 35/7.5 or TS 35/15 steel rail
Contact Konmask for complete BOM sourcing and volume pricing on accessory kits.
Compliance & Industry Standards
- IEC 60947-7-1 — Low-voltage switchgear and controlgear: terminal blocks for copper conductors
- UL 508 — Industrial control equipment (UL Listed)
- CSA C22.2 No. 158 — Canadian Standards Association approval
- EN 60715 — DIN rail mounting compatibility
- RoHS Compliant — Restriction of Hazardous Substances Directive (EU 2011/65/EU)
- REACH Compliant — No SVHC substances above threshold
Quality Assurance & Sourcing
Konmask.com sources the WEIDMULLER SAKDU4 INTERFACE through verified industrial distribution channels. Every unit is:
- Inspected against OEM datasheet specifications before dispatch
- Supplied with original Weidmüller packaging and batch traceability
- Photographed and documented for customs and compliance records
- Backed by Konmask’s quality guarantee — if the part does not match the specification, we replace or refund
We maintain stock of high-velocity Weidmüller terminal block series to support urgent project timelines and MRO replenishment orders.
How to Source This Part
- Online Order — Add to cart and check out directly. We accept T/T bank transfer, PayPal, and major credit cards.
- RFQ for Volume — Email support@konmask.com with your quantity and project timeline for a volume quote within 24 hours.
- Urgent / Express — Call or WhatsApp +0086 19859288691 for same-day quotation on urgent MRO or project requirements.
- BOM Sourcing — Send your full panel BOM and we will cross-reference, quote, and consolidate shipment for all Weidmüller and multi-brand items.
Application-Specific FAQ
Q: Is the SAKDU4 suitable for 24 VDC PLC I/O wiring?
A: Yes. The SAKDU4 is rated 800 V / 32 A, making it significantly over-specified for 24 VDC control circuits — which is exactly why engineers prefer it for long-term reliability in PLC panels.
Q: Can I use SAKDU4 terminals with 1.5 mm² control cable?
A: Yes. The conductor range is 0.5–6 mm², so 1.5 mm² (AWG 16) fits perfectly with standard ferrules (e.g., Weidmüller H 1.5/12).
Q: What is the difference between SAKDU4 and SAK4?
A: The SAKDU4 belongs to the newer SAKDU series with updated insulation geometry and improved marker compatibility. SAK4 is the legacy series. Both are electrically equivalent but accessories are not interchangeable.
Q: Do you supply Weidmüller SAKDU4 in full packs or individual pieces?
A: We supply in full OEM packs (standard pack quantity per Weidmüller catalog). For partial quantities or mixed orders, contact us via RFQ.
Q: Can Konmask provide a Certificate of Conformance (CoC)?
A: Yes. A CoC is available upon request for all orders. Please specify at time of order or email support@konmask.com.
