SIEMENS 6ES7153-1AA03-0XB0 IM153-1 Interface Module | Replacement, Equivalent & Selection Guide
The SIEMENS 6ES7153-1AA03-0XB0 is the IM153-1 Interface Module for the ET 200M distributed I/O system, designed to connect ET 200M stations to the PROFIBUS DP fieldbus. It serves as the communication gateway between the PROFIBUS DP master and the S7-300 signal modules installed in the ET 200M rack. This page provides full technical specifications, compatible replacement models, application guidance, and a structured selection guide to help engineers and procurement teams make the right sourcing decision.
Technical Specifications
- Order Number: 6ES7153-1AA03-0XB0
- Product Family: SIMATIC ET 200M
- Module Type: IM153-1 Interface Module
- Fieldbus: PROFIBUS DP (up to 12 Mbit/s)
- PROFIBUS Address Range: 1–125 (set via DIP switch)
- Max. I/O Modules per Station: Up to 8 S7-300 signal modules
- Power Supply: 24 V DC (via backplane bus)
- Current Consumption (5 V): Typically 0.8 A
- Operating Temperature: 0 °C to +60 °C
- Storage Temperature: −40 °C to +70 °C
- Degree of Protection: IP20
- Dimensions (W × H × D): 40 × 125 × 120 mm
- Weight: Approx. 300 g
- Certifications: CE, UL, cULus, ATEX (Zone 2)
- Firmware: Supports online firmware update via PROFIBUS
- Isochronous Mode: Not supported (see IM153-2 for isochronous)
Compatible Replacement & Equivalent Models
The table below lists direct replacements and functional equivalents for the 6ES7153-1AA03-0XB0. Always verify firmware compatibility and module count requirements before substituting.
| Order Number | Description | Compatibility Notes |
|---|---|---|
| 6ES7153-1AA03-0XB0 | IM153-1 (this product) | Original model — reference baseline |
| 6ES7153-2BA02-0XB0 | IM153-2 Interface Module | Adds isochronous mode & redundancy; drop-in for most ET 200M racks |
| 6ES7153-2BA83-0XB0 | IM153-2 HF (High Feature) | Supports PROFIBUS DP-V1; recommended for new designs |
| 6ES7153-1AA00-0XB0 | IM153-1 (earlier revision) | Functionally equivalent; older firmware baseline |
| 6ES7153-1AA01-0XB0 | IM153-1 (revision 01) | Compatible; check GSD file version |
| 6ES7153-1AA02-0XB0 | IM153-1 (revision 02) | Direct predecessor; interchangeable in most applications |
Note: Always cross-reference the GSD file and STEP 7 / TIA Portal hardware catalog entry when substituting interface modules.
Why Choose the Original Model
- Proven Reliability: The 6ES7153-1AA03-0XB0 has an extensive installed base in global manufacturing and process industries, with a well-documented maintenance history.
- Exact GSD File Match: Using the original order number guarantees GSD file alignment, eliminating reconfiguration risk in existing PROFIBUS networks.
- Spare Parts Continuity: Maintaining the same revision simplifies spare parts management and reduces engineering change order (ECO) overhead.
- Warranty & Traceability: Konmask.com supplies factory-sealed, traceable units with full documentation — critical for regulated industries (food, pharma, energy).
Typical Applications
- Distributed I/O expansion for SIMATIC S7-300 / S7-400 PLC systems via PROFIBUS DP
- Automotive body shop and paint line automation
- Chemical and petrochemical process control panels
- Water treatment and utilities SCADA field stations
- Packaging machinery and conveyor control systems
- Machine tool and CNC peripheral I/O expansion
- Building automation and HVAC control cabinets
System Compatibility
- PLC Platforms: SIMATIC S7-300, S7-400, S7-400H (redundant systems with IM153-2)
- Engineering Software: STEP 7 V5.x, TIA Portal V13 and above (with legacy support)
- Fieldbus: PROFIBUS DP (DP-V0); not compatible with PROFINET
- Rack: Standard ET 200M rack (UR1, UR2); up to 8 signal modules
- Power Supply Modules: PS307 series (2 A, 5 A, 10 A)
- Signal Modules: All standard S7-300 SM modules (digital, analog, technology)
Selection Guide
Use the decision criteria below to confirm whether the 6ES7153-1AA03-0XB0 is the right module for your application, or to identify the best alternative:
- Need standard PROFIBUS DP (non-isochronous)? → IM153-1 (6ES7153-1AA03-0XB0) ✔
- Need isochronous mode or motion control sync? → Upgrade to IM153-2 (6ES7153-2BA02-0XB0)
- Need redundant IM for high-availability systems? → IM153-2 with S7-400H
- Migrating to PROFINET? → Consider ET 200SP with IM155-6 PN
- Replacing an older revision (AA00/AA01/AA02)? → AA03 is a direct drop-in; update GSD file in STEP 7
- Module count > 8? → Use two ET 200M stations or consider ET 200M with IM153-4 PN
Quality Assurance & Sourcing
- Source: Authorized distribution channels and verified surplus stock with full traceability
- Inspection: Each unit undergoes visual inspection, label verification, and functional pre-shipment check
- Packaging: Original or equivalent ESD-safe packaging with anti-static protection
- Documentation: CE declaration, country of origin certificate available on request
- Lead Time: In-stock units ship within 1–3 business days; contact us for bulk order scheduling
- Warranty: 12-month warranty against manufacturing defects
How to Order
- Confirm the exact order number: 6ES7153-1AA03-0XB0
- Specify quantity and required delivery date
- Contact us via email or phone for a formal quotation (RFQ)
- Provide your shipping address and preferred freight method (DHL, FedEx, sea freight)
- Payment: T/T bank transfer, PayPal, or trade assurance — terms available for verified accounts
📧 support@konmask.com | 📞 +0086 19859288691
Replacement & Compatibility FAQ
Q: Can I replace 6ES7153-1AA03-0XB0 with 6ES7153-1AA02-0XB0?
A: Yes, in most cases. Both are IM153-1 revisions with the same functional scope. Verify the GSD file version in your STEP 7 project and update if necessary.
Q: Is the IM153-1 compatible with TIA Portal?
A: Yes, TIA Portal V13 and later support the IM153-1 via the legacy S7-300 hardware catalog. Full configuration is supported.
Q: Can I use IM153-1 in a redundant S7-400H system?
A: No. Redundant systems require the IM153-2 (6ES7153-2BA02-0XB0) which supports Y-link redundancy.
Q: What is the maximum PROFIBUS cable length with IM153-1?
A: At 12 Mbit/s, the maximum segment length is 100 m. At 1.5 Mbit/s, it extends to 200 m. Use repeaters for longer runs.
Q: Does Konmask.com supply new or refurbished units?
A: We supply both new (factory-sealed) and professionally refurbished units. All listings clearly state the condition. Contact us to confirm stock condition before ordering.
