Westinghouse 5X00105G14 – Electronics Module | Ovation DCS Platform
Engineering Background
The Westinghouse 5X00105G14 is a field-proven electronics module designed for deployment within the Westinghouse Ovation Distributed Control System (DCS) — one of the most widely adopted process control platforms in power generation, nuclear, and heavy industrial facilities worldwide. This module represents the engineering heritage of Westinghouse Electric’s automation division, now continued under Emerson’s Ovation product line, and remains a critical spare and replacement component for legacy and active Ovation installations.
Product Positioning
Targeted at maintenance engineers, reliability teams, and procurement specialists managing Ovation DCS infrastructure, the 5X00105G14 is sourced through verified industrial supply channels. Konmask.com specializes in hard-to-find, OEM-grade automation components with documented traceability — making this module available to facilities that require fast, reliable replacement without extended OEM lead times.
Complete Technical Specifications
| Part Number | 5X00105G14 |
| Manufacturer | Westinghouse Electric / Ovation (Emerson) |
| Module Type | Electronics Module |
| Platform | Ovation DCS |
| Form Factor | Rack-mount card module |
| Weight | 480 g (approx.) |
| Operating Temperature | 0°C to +60°C (standard industrial range) |
| Humidity | 5% to 95% RH, non-condensing |
| Communication Interface | Ovation proprietary backplane bus |
| Power Supply | Supplied via Ovation controller chassis backplane |
| Compliance | CE, UL (per original OEM certification) |
| Condition | New / Refurbished / Tested (specify on inquiry) |
Note: Full datasheet available upon request. Contact [email protected] for detailed electrical specifications.
Proven Application Environments
- Power Generation: Coal, gas, and combined-cycle power plants running Ovation DCS for turbine and boiler control
- Nuclear Facilities: Non-safety-class instrumentation and control upgrades in nuclear power stations
- Petrochemical & Refining: Process control loops requiring high-reliability I/O and signal conditioning
- Water & Wastewater Treatment: SCADA-integrated Ovation installations for pump and valve automation
- Pulp & Paper / Mining: Continuous process industries with legacy Ovation DCS infrastructure
Engineering Advantages
- Drop-in Compatibility: Direct replacement for existing 5X00105G14 slots — no firmware reconfiguration required in most installations
- Reduced Downtime Risk: Stocking this module as a critical spare eliminates extended OEM procurement lead times (typically 8–20 weeks)
- Verified Functionality: Each unit undergoes bench-level power-on and signal integrity checks prior to shipment
- Traceability Documentation: Certificate of conformance and inspection report available upon request
- Long-term Availability: Konmask maintains inventory of legacy Ovation modules to support facilities beyond OEM active production windows
System Architecture & Signal Flow
The 5X00105G14 integrates into the Ovation DCS controller chassis via the standard Ovation backplane. Within the system architecture:
- The module interfaces with the Ovation controller node via the high-speed backplane data bus
- Field signals are conditioned and digitized on-board before transmission to the controller
- The module supports Ovation’s redundancy architecture — hot-standby configurations are supported where the chassis design permits
- Configuration and diagnostics are managed through the Ovation Developer Studio (ODS) engineering workstation
Consult your Ovation system documentation (OW350 series) for slot assignment, I/O mapping, and redundancy configuration procedures.
Sourcing & Quality Verification
Konmask.com operates as a specialist distributor of industrial automation and control system components. Our sourcing protocol for the 5X00105G14 includes:
- Multi-tier supplier vetting: Components sourced from decommissioned plant inventories, authorized distributors, and OEM surplus channels
- Visual & physical inspection: Board-level inspection for corrosion, component damage, and counterfeit indicators
- Functional testing: Power-on verification and where applicable, signal loop testing
- Packaging: ESD-safe anti-static packaging with moisture barrier for international shipment
- Documentation: Inspection report, photos of actual unit, and CoC provided on request
Procurement Process
- Inquiry: Submit your RFQ via email to [email protected] or via the product page inquiry form, specifying quantity, required condition (new/refurbished/tested), and delivery timeline
- Quotation: Konmask will respond within 1 business day with pricing, lead time, and available stock confirmation
- Order Confirmation: Purchase order accepted via email; proforma invoice issued for payment processing
- Quality Check & Dispatch: Unit inspected, photographed, and packed; tracking number provided within 24–48 hours of payment clearance
- Delivery: DHL / FedEx / UPS international express; customs documentation prepared for CN export
- After-sales Support: 30-day DOA (Dead on Arrival) warranty; technical support available via email
Technical FAQ
Q: Is the 5X00105G14 compatible with all Ovation DCS versions?
A: The module is designed for the Ovation platform. Compatibility depends on your specific controller version and chassis configuration. Contact us with your system details for confirmation.
Q: What is the difference between G14 and other G-suffix variants (e.g., G01, G05)?
A: The G-suffix denotes hardware revision or configuration variant. G14 specifies a particular hardware build level. Substitution between G-variants requires engineering review — do not substitute without consulting your Ovation system documentation or Konmask technical support.
Q: Can Konmask provide a tested/refurbished unit with warranty?
A: Yes. Tested and refurbished units are available with a 30-day DOA warranty. Extended warranty options can be discussed on a case-by-case basis.
Q: What lead time should I expect?
A: In-stock units ship within 2–3 business days. If not in stock, typical sourcing lead time is 2–4 weeks. Contact us for current availability.
Q: Do you provide export documentation for international shipments?
A: Yes. Commercial invoice, packing list, and certificate of origin are standard. Additional documentation (e.g., ECCN classification, end-user declaration) available on request.
