Yaskawa DKR-E 2601 GAT 543012R0101 Servo Control Board | Replacement, Equivalent & Selection Guide
The Yaskawa DKR-E 2601 (Part No. GAT 543012R0101) is a servo control board designed for Yaskawa servo drive systems. This page serves as a comprehensive selection, replacement, and compatibility reference for engineers and procurement teams sourcing this component or evaluating alternatives.
Technical Specifications
- Manufacturer: Yaskawa Electric Corporation
- Part Number / SKU: DKR-E 2601 / GAT 543012R0101
- Type: Servo Control Board (PCB Assembly)
- Series: DKR-E
- Function: Servo drive control signal processing and feedback interface
- Weight: Approx. 13.6 kg (packaged)
- Condition: New / Refurbished / Tested Available — specify at order
- Origin: Japan
Compatible Replacement & Equivalent Models
The following models may serve as functional replacements or equivalents depending on your drive system configuration. Always verify electrical and mechanical compatibility before substitution:
- Yaskawa GAT 543012R0100 (prior revision)
- Yaskawa GAT 543012R0102 (later revision — confirm firmware compatibility)
- Yaskawa DKR-E series control boards with matching connector layout
- Third-party servo control boards compatible with Yaskawa DKR-E drive chassis (consult datasheet)
Note: Revision suffixes (R0101, R0100, R0102) may indicate PCB layout or firmware differences. Confirm with your drive documentation or contact our technical team before ordering a substitute.
Why Choose the Original Model
- OEM Precision: Engineered specifically for Yaskawa DKR-E drive systems — guaranteed signal integrity and timing compliance.
- Firmware Compatibility: Factory-matched firmware revision eliminates drive fault codes caused by mismatched control logic.
- Warranty & Traceability: Full serial number traceability and manufacturer warranty support.
- Reduced Commissioning Risk: Drop-in replacement with no parameter re-tuning required in most applications.
Typical Applications
- CNC machine tool servo axis control (milling, turning, grinding)
- Industrial robot joint servo drives
- Automated assembly line servo positioning systems
- Injection molding machine servo hydraulic control
- Packaging and labeling machine servo drives
- Semiconductor and electronics manufacturing equipment
System Compatibility
The DKR-E 2601 GAT 543012R0101 control board is designed for use within the Yaskawa DKR-E series servo drive platform. Verify compatibility by checking:
- Drive chassis model number (DKR-E series)
- Connector type and pin count on the existing board
- Firmware version of the host drive unit
- Power supply voltage rail requirements of the control board
If you are unsure of compatibility, provide your drive nameplate data to our technical team for confirmation.
Selection Guide
Use the following decision framework when selecting between original, revised, or equivalent models:
- Exact replacement needed: Order GAT 543012R0101 — identical form, fit, and function.
- Revision upgrade acceptable: GAT 543012R0102 may offer improved reliability; confirm with Yaskawa service bulletin.
- Budget-sensitive application: Tested refurbished GAT 543012R0101 units available — request test report.
- Emergency downtime recovery: Contact us for expedited sourcing and same-day quotation.
- Long-term spares planning: Inquire about multi-unit pricing and consignment stock programs.
Quality Assurance & Sourcing
- All units inspected and function-tested prior to shipment
- Anti-static packaging with humidity indicator cards
- Certificate of conformance available on request
- Sourced from authorized distributors and verified secondary market channels
- Counterfeit prevention: serial number and date code verification performed on every unit
How to Order
- Add to cart directly, or contact us for bulk / project pricing.
- Specify required condition: New OEM, Refurbished, or Tested Used.
- Provide your drive model and serial number for compatibility confirmation if needed.
- Request a proforma invoice for bank transfer / TT payment.
- Lead time: In-stock units ship within 1–3 business days; sourced units 5–15 business days.
📧 Email: support@konmask.com
📞 Phone / WhatsApp: +0086 19859288691
🌐 Website: https://Konmask.com
Replacement & Compatibility FAQ
Q: Can I use GAT 543012R0100 instead of GAT 543012R0101?
A: In most cases yes, as R0100 is the prior revision. However, verify that your drive firmware does not require the R0101 revision specifically. Contact us for guidance.
Q: Is this board compatible with Yaskawa SGDH or SGDS series drives?
A: No. The DKR-E 2601 is specific to the DKR-E drive platform. SGDH/SGDS use different control board architectures.
Q: Do you offer repair services for faulty DKR-E 2601 boards?
A: Yes. Send your faulty board for evaluation. Repair quotation provided within 3 business days.
Q: What warranty is provided?
A: New OEM units carry manufacturer warranty. Refurbished and tested units carry a 90-day functional warranty from Konmask.
Q: Can I return the board if it does not fit?
A: Yes, within 30 days of receipt in original condition. See our returns policy for details.
