YASKAWA DX100-JARCR-YPC01-1 Connection Unit Main Board – DX100 Robot Controller Series
When a YASKAWA DX100 robot controller loses its connection unit main board, the entire robotic cell goes dark. Motion commands fail to transmit, teach pendant communication drops, and production lines halt — costing manufacturers thousands of dollars per hour in unplanned downtime. The YASKAWA DX100-JARCR-YPC01-1 Connection Unit Main Board is the critical communication backbone of the DX100 controller, and without it, no signal reaches the servo drives, I/O modules, or external safety circuits.
The JARCR-YPC01-1 occupies a pivotal position within the DX100 controller architecture. As the primary connection and routing board, it manages internal bus communication between the CPU unit, servo amplifier boards, and peripheral I/O — making it one of the highest-demand spare parts in YASKAWA’s global installed base of industrial robots. With hundreds of thousands of DX100 controllers deployed across automotive, electronics, and general manufacturing industries worldwide, this board represents a mission-critical component for maintenance engineers and system integrators alike.
Technical Specifications
- Part Number: JARCR-YPC01-1
- Compatible Controller: YASKAWA DX100
- Function: Connection Unit Main Board (internal bus routing & communication)
- Manufacturer: YASKAWA Electric Corporation
- Product Series: DX100 Robot Controller
- Weight: 560 g (approx.)
- Condition: New / Refurbished / Tested (specify on inquiry)
- Warranty: 90-day functional warranty (Konmask standard)
Key Features & Benefits
- ✅ OEM-Grade Compatibility: Designed specifically for YASKAWA DX100 controller architecture — no firmware conflicts or signal mismatch.
- ✅ Plug-and-Play Replacement: Direct drop-in replacement for failed or degraded JARCR-YPC01-1 boards, minimizing re-commissioning time.
- ✅ Rigorous Pre-Shipment Testing: Each board undergoes functional verification before dispatch to ensure signal integrity and bus communication reliability.
- ✅ Fast Global Sourcing: Konmask maintains stock and sourcing channels for urgent replacement needs across Asia, Europe, and the Americas.
- ✅ Expert Technical Support: Our engineering team can assist with installation guidance, fault code interpretation, and compatibility verification.
Industry & Equipment Applications
- Automotive Manufacturing: Welding robots, body assembly lines, paint shop automation using YASKAWA DX100-controlled manipulators.
- Electronics Assembly: PCB handling, component placement, and precision soldering robot cells.
- Metal Fabrication: Arc welding, plasma cutting, and press-tending robot systems.
- Logistics & Palletizing: High-cycle palletizing robots in food, beverage, and consumer goods facilities.
- General Industrial Automation: Any facility operating YASKAWA Motoman robots with DX100 controller platforms.
System Integration & Compatible Parts
The JARCR-YPC01-1 works in conjunction with the following DX100 controller components. Konmask.com can source these parts as well:
- JARCR-XFB01B — I/O Interface Board
- JARCR-YSF21 — Safety Unit Board
- JARCR-RCO01-1 — Robot Control Board
- JZNC-YRK01-1E — CPU Unit
- JZNC-YIU01-E — Integrated I/O Unit
If you are performing a full DX100 controller overhaul or need a complete spare parts kit, contact our team for a bundled quotation.
Our Quality Assurance Process
- Source Verification: All boards are sourced from authorized distributors, decommissioned OEM systems, or certified refurbishers.
- Visual Inspection: Physical examination for burnt components, cracked PCB traces, corroded connectors, and mechanical damage.
- Functional Testing: Power-on and bus communication tests performed using DX100-compatible test rigs.
- Cleaning & Packaging: Anti-static cleaning, ESD-safe packaging, and moisture-barrier sealing for safe international shipping.
- Documentation: Test report and condition certificate included with each shipment upon request.
How to Order
- Submit your inquiry via the Contact Us form or email support@konmask.com.
- Provide your required quantity, preferred condition (new/refurbished), and destination country.
- Receive a formal quotation with lead time and shipping options within 24 business hours.
- Confirm order and complete payment via T/T, PayPal, or other agreed methods.
- Shipment dispatched with tracking number and commercial invoice.
Why Choose Konmask.com?
- 🏭 Industrial Automation Specialists: We focus exclusively on PLC, DCS, robot controller, and servo drive components — not general electronics.
- 🌍 Global Shipping: Reliable export logistics to 50+ countries with DHL, FedEx, and UPS express options.
- 🔧 Engineering-Led Team: Our staff includes experienced automation engineers who understand your application requirements.
- 📦 Flexible MOQ: Single-unit orders accepted — ideal for emergency maintenance and MRO procurement.
- 🔒 Secure Transactions: Verified supplier with transparent business documentation and export compliance.
Frequently Asked Questions
Q: Is the JARCR-YPC01-1 compatible with all DX100 controller variants?
A: The JARCR-YPC01-1 is designed for the YASKAWA DX100 controller platform. Please confirm your controller’s full model and software version with our team before ordering to ensure full compatibility.
Q: Do you offer a warranty on this board?
A: Yes. Konmask provides a standard 90-day functional warranty. Extended warranty options are available — please inquire.
Q: Can you ship to my country?
A: We ship to over 50 countries worldwide. Contact us with your destination for a shipping quote and estimated lead time.
Q: What if the board I receive is defective?
A: We offer a replacement or refund policy for DOA (Dead on Arrival) units. Please contact us within 7 days of receipt with photos and a fault description.
Q: Do you have stock available immediately?
A: Stock availability varies. Submit an inquiry and we will confirm availability and lead time within 24 business hours.
Q: Can I get a datasheet or technical drawing?
A: We can provide available technical documentation upon request. Contact support@konmask.com with your part number.
