YASKAWA PCU-ETHIOEI JZRCR-YSV24-111 Servo Communication Unit – DX200 Robot Controller Series
When a YASKAWA DX200 robot controller loses its servo communication unit, the entire production line comes to a halt. Welding cells go cold, assembly arms freeze mid-cycle, and every minute of unplanned downtime translates directly into lost output and escalating maintenance costs. The YASKAWA PCU-ETHIOEI — paired with cables X82 CBL-YRC-061-1, X81 CBL-YRC-061-1 8M J, and servo drive board JZRCR-YSV24-111 — is the precision-engineered component that keeps your DX200 system communicating reliably between the robot controller and servo amplifiers. Without it, there is no motion control, no feedback loop, and no production.
The JZRCR-YSV24-111 servo communication PCB is a core internal board within the DX200 controller architecture, responsible for real-time EtherNet/IP-based servo axis communication via the PCU-ETHIOEI interface unit. This assembly — including the 8-meter harness cables CBL-YRC-061-1 — represents YASKAWA’s industrial-grade solution for multi-axis coordinated motion in arc welding, material handling, and spot welding robot cells. As one of the most widely deployed robot controller platforms globally, the DX200 powers hundreds of thousands of YASKAWA Motoman robots across automotive, electronics, and heavy manufacturing sectors worldwide.
Technical Specifications
- Part Number / SKU: PCU-ETHIOEI X82 CBL-YRC-061-1 X81 CBL-YRC-061-1 8M J JZRCR-YSV24-111 DX200
- Brand: YASKAWA (安川電機)
- Compatible Controller: DX200 Robot Controller
- Interface Unit: PCU-ETHIOEI (EtherNet/IP Servo Communication Unit)
- Internal Board: JZRCR-YSV24-111 (Servo Communication PCB)
- Cable Assembly X82: CBL-YRC-061-1 (Controller-to-Amplifier Harness)
- Cable Assembly X81: CBL-YRC-061-1, Length: 8M, Connector Type: J
- Communication Protocol: EtherNet/IP real-time servo axis control
- Application: Multi-axis servo drive coordination in Motoman robot systems
- Condition: New / Refurbished / Tested (specify on inquiry)
- Weight: 100 g (unit only, excluding cables)
Key Features & Benefits
- Real-Time Servo Communication: PCU-ETHIOEI enables high-speed, deterministic EtherNet/IP communication between the DX200 CPU and servo amplifiers, ensuring precise multi-axis synchronization.
- Drop-In Replacement: Exact OEM-equivalent assembly — no firmware modification or reconfiguration required for compatible DX200 systems.
- Complete Cable Kit Included: X82 and X81 CBL-YRC-061-1 harnesses (8M, J-type connector) are included, eliminating sourcing complexity for a full repair or upgrade.
- Proven DX200 Platform Reliability: Designed and manufactured to YASKAWA’s stringent industrial automation standards for 24/7 continuous operation environments.
- Rapid Downtime Recovery: Stocking this assembly as a critical spare reduces mean time to repair (MTTR) for servo communication faults in DX200 robot cells.
- Global OEM Traceability: Sourced through verified supply channels with full part traceability documentation available on request.
Industry & Equipment Applications
- Automotive Manufacturing: Body welding lines, spot welding cells, and paint shop robots using YASKAWA Motoman MA, EA, and VA series arms with DX200 controllers.
- Arc Welding Automation: MIG/TIG welding robot systems requiring precise servo axis coordination for weld path accuracy.
- Material Handling & Palletizing: High-cycle pick-and-place and palletizing systems in food, beverage, and logistics industries.
- Electronics Assembly: PCB handling and precision assembly robots in semiconductor and consumer electronics manufacturing.
- Heavy Industry: Foundry, forging, and press-tending robots operating in harsh environments with DX200 controllers.
System Integration & Compatible Parts
This assembly is designed for use within the YASKAWA DX200 robot controller ecosystem. Compatible and commonly paired components include:
- YASKAWA DX200 Robot Controller (all variants)
- YASKAWA Motoman MA1400, MA1900, EA1400, VA1400 robot arms
- JZRCR-YSV01-1, JZRCR-YSV12-1 (alternative servo communication boards)
- SGDV-series and SGDH-series YASKAWA servo amplifiers
- CBL-YRC series controller harness cables (various lengths)
- DX200 CPU board, power supply unit, and I/O modules
If you are unsure about compatibility with your specific robot model or controller revision, please contact our technical team with your controller serial number and robot model for confirmation before ordering.
Our Quality Assurance Process
At Konmask.com, every industrial automation component undergoes a rigorous verification process before shipment:
- Visual Inspection: All boards and cables are inspected for physical damage, corrosion, and connector integrity.
- Part Number Verification: SKU and revision codes are cross-referenced against YASKAWA’s official part documentation.
- Functional Testing (where applicable): Refurbished units are bench-tested on compatible DX200 test rigs prior to dispatch.
- Secure Packaging: ESD-safe anti-static packaging with foam cushioning for international freight protection.
- Documentation: Test reports and traceability certificates available upon request for MRO and OEM procurement teams.
How to Order
- Submit an Inquiry: Use the contact form or email [email protected] with your required quantity and delivery timeline.
- Receive a Quote: Our team will respond within 1 business day with pricing, availability, and lead time.
- Confirm & Pay: We accept T/T bank transfer, PayPal, and other B2B payment methods. Proforma invoice issued upon order confirmation.
- Shipment & Tracking: Orders are dispatched via DHL, FedEx, or UPS Express with full tracking. Export documentation (commercial invoice, packing list) provided for customs clearance.
Why Choose Konmask.com?
- ✅ Industrial Automation Specialists: Focused exclusively on PLC, DCS, servo, and robot controller components — not a generalist marketplace.
- ✅ Global B2B Supply: Serving MRO buyers, system integrators, and OEM procurement teams across 40+ countries.
- ✅ Technical Expertise: Our team includes experienced automation engineers who can assist with compatibility verification and system troubleshooting.
- ✅ Fast Response: Inquiry-to-quote within 24 hours. Emergency stock requests handled with priority.
- ✅ Verified Supply Chain: All parts sourced from authorized distributors or directly from OEM-certified channels with full traceability.
- ✅ Competitive Pricing: Direct sourcing relationships allow us to offer market-competitive pricing for both single units and bulk orders.
Frequently Asked Questions
Q: Is this a genuine YASKAWA OEM part or an aftermarket replacement?
A: We supply genuine YASKAWA OEM parts sourced through verified distribution channels. Aftermarket alternatives are not offered for this assembly. Please contact us for authenticity documentation.
Q: What DX200 controller revisions is the PCU-ETHIOEI compatible with?
A: The PCU-ETHIOEI is compatible with standard DX200 controller configurations supporting EtherNet/IP servo communication. Please provide your controller’s serial number and software version for precise compatibility confirmation.
Q: Can I order just the JZRCR-YSV24-111 board without the cables?
A: Yes. Please specify your exact requirement in your inquiry — we can supply the servo communication board, cables, or the complete assembly depending on your needs.
Q: What is the lead time for this part?
A: Lead time depends on current stock availability. In-stock items ship within 2–3 business days. Out-of-stock items typically have a 2–4 week lead time. Contact us for real-time availability.
Q: Do you provide a warranty?
A: Yes. New OEM parts carry the standard YASKAWA manufacturer warranty. Refurbished/tested units carry a 90-day functional warranty from Konmask.com. Terms are specified in the sales agreement.
Q: Can you assist with installation or commissioning guidance?
A: Our technical team can provide reference documentation and general guidance. For on-site commissioning, we recommend engaging a certified YASKAWA service partner in your region.
