Precision Motion Control Solution — Yaskawa SGDV-260D11A | Σ-V Series AC Servo Drive
Where This Product Is Used
The Yaskawa SGDV-260D11A is a high-performance AC servo amplifier engineered for demanding industrial motion control environments. Typical deployment scenarios include:
- CNC Machining Centers — Axis feed drives requiring tight velocity and position loop accuracy at high throughput
- Industrial Robotics — Joint actuators in articulated arms, SCARA, and Cartesian gantry systems
- Semiconductor & Electronics Assembly — Pick-and-place, die bonding, and wafer handling where micron-level repeatability is mandatory
- Packaging Machinery — High-speed indexing, flying shear, and registration control on form-fill-seal lines
- Printing & Converting Equipment — Web tension control and register mark tracking
- Injection Molding & Press Automation — Clamp, injection, and ejector axis control with force feedback
- Automated Warehousing & AGV Systems — Drive units for autonomous guided vehicles and stacker cranes
Technical Specifications
| Parameter | Value |
|---|---|
| Model Number | SGDV-260D11A |
| Series | Σ-V (Sigma-V) |
| Manufacturer | Yaskawa Electric Corporation |
| Rated Output Current | 26 A |
| Input Voltage | 200–230 V AC, 3-Phase |
| Frequency | 50 / 60 Hz |
| Control Method | IGBT PWM Sinusoidal Current Control |
| Feedback | Serial Encoder (20-bit absolute / incremental) |
| Communication Interface | MECHATROLINK-II |
| Control Modes | Position / Velocity / Torque / Full-closed loop |
| Regenerative Resistor | Built-in (external option available) |
| Protection Class | IP20 |
| Ambient Temperature | 0 – 55 °C (operating) |
| Weight | Approx. 11.46 kg |
| Applicable Motor Series | SGMJV / SGMAV / SGMGV / SGMCS |
Why Engineers Specify This Model
- High Current Rating (26 A) — Supports larger servo motors up to the medium-power range without external current boosters
- Σ-V Autotuning — One-parameter tuning with vibration suppression reduces commissioning time from hours to minutes
- MECHATROLINK-II Native — Synchronous network communication at 0.5 ms cycle time enables tight multi-axis coordination with Yaskawa MP-series and compatible PLCs
- Full-Closed Loop Capability — Accepts external linear or rotary encoder feedback for direct load position control, eliminating backlash error
- Safety Input (STO) — IEC 61800-5-2 Safe Torque Off function simplifies SIL 2 / PLd safety circuit design
- Compact DIN-rail Footprint — Optimized for high-density control cabinet layouts
Complete System Bill of Materials
For a fully operational servo axis using the SGDV-260D11A, the following components are typically required:
- Servo Motor — Yaskawa SGMGV or SGMAV series (matched by kW rating)
- Encoder Cable — Yaskawa JZSP-CHP00-xx-E (shielded, flex-rated for moving cable trays)
- Power Cable — Yaskawa JZSP-B9P□□□-E (motor power, matched gauge)
- Regenerative Resistor Unit — JUSP-RA04-E or JUSP-RA10-E (for high-duty-cycle deceleration)
- EMC Filter — Yaskawa or third-party line filter per CE/UL installation requirements
- Controller / PLC — Yaskawa MP3300, MP2600, or any MECHATROLINK-II master
- 24 V DC Control Power Supply — Isolated SMPS, minimum 3 A
- Circuit Breaker / Fuse — Per NEC / IEC wiring regulations for 200 V 3-phase branch circuit
Compliance & Industry Standards
- CE Marking — Low Voltage Directive 2014/35/EU & EMC Directive 2014/30/EU
- UL 508C — Power Conversion Equipment
- RoHS Compliant
- IEC 61800-5-1 — Adjustable Speed Electrical Power Drive Systems (Safety)
- IEC 61800-5-2 — Safe Torque Off (STO) functional safety
- ISO 13849-1 PLd / SIL 2 (STO function)
Quality Assurance & Sourcing
All units offered by Konmask.com are sourced through verified industrial supply channels. Each SGDV-260D11A is:
- Inspected for physical integrity, label authenticity, and firmware version prior to listing
- Stored in ESD-safe, climate-controlled warehousing
- Shipped with original manufacturer packaging where available
- Traceable to documented supply chain records
We do not list counterfeit, refurbished-as-new, or untested units. Condition is clearly stated on each listing.
How to Source This Part
- Confirm compatibility — Match your motor’s rated current and encoder type to the SGDV-260D11A datasheet before ordering
- Request a quote — Contact us via the form below or email [email protected] with your project BOM for volume pricing
- Lead time — In-stock units ship within 1–3 business days; expedited freight available
- Export compliance — We handle EAR99 / ECCN classification and commercial invoice documentation for cross-border shipments
Application-Specific FAQ
Q: Can the SGDV-260D11A be used with non-Yaskawa motors?
A: Technically possible with custom encoder emulation, but Yaskawa does not officially support this configuration. For warranty and reliability, use matched Yaskawa SGMGV/SGMAV motors.
Q: Is MECHATROLINK-II backward compatible with MECHATROLINK-III controllers?
A: No. MECHATROLINK-II and III are separate protocols. Verify your controller’s supported protocol version before ordering.
Q: What is the maximum motor capacity this drive supports?
A: At 26 A / 200 V 3-phase, this drive is rated for motors up to approximately 5.0 kW depending on the motor series. Consult the Yaskawa SGDV selection guide for exact pairing.
Q: Does this unit include a SigmaWin+ setup cable?
A: The setup cable (USB-to-CN3) is sold separately. SigmaWin+ software is available free from Yaskawa’s website.
Q: Can I use this drive in a single-phase 200 V application?
A: The SGDV-260D11A is rated for 3-phase input. Single-phase operation at this current rating is not recommended and may void compliance certifications.
