YASKAWA USAHEM-01-TL31 – High-Performance AC Servo Motor | Sigma-II Series
Engineering Background
The YASKAWA USAHEM-01-TL31 is a precision AC servo motor from YASKAWA Electric Corporation’s Sigma-II series — one of the most widely deployed servo platforms in global industrial automation. Designed for demanding motion control applications, this motor delivers exceptional torque density, low cogging, and seamless integration with YASKAWA SGDH-series servo drives. It is the preferred choice for procurement engineers specifying reliable, high-cycle motion axes in machine tools, semiconductor equipment, packaging lines, and robotics.
Product Positioning
The USAHEM-01-TL31 occupies the small-frame, high-precision segment of the Sigma-II motor lineup. Its compact form factor combined with a high-resolution encoder makes it ideal for applications requiring tight positional accuracy in constrained installation envelopes. Konmask.com stocks and sources this model to support MRO replacement, OEM production continuity, and system integrator procurement across Asia-Pacific and global markets.
Complete Technical Specifications
- Model Number: USAHEM-01-TL31
- Manufacturer: YASKAWA Electric Corporation
- Series: Sigma-II (USAHEM)
- Motor Type: AC Servo Motor (Permanent Magnet Synchronous)
- Rated Output Power: 100 W (0.1 kW)
- Rated Torque: 0.318 N·m
- Rated Speed: 3,000 rpm
- Maximum Speed: 5,000 rpm
- Encoder Type: Incremental encoder, 2,048 P/R (standard)
- Encoder Resolution: 8,192 pulses/rev (×4 multiplication)
- Voltage: 200 VAC, 3-phase / single-phase compatible
- Insulation Class: Class F (155°C)
- Protection Rating: IP67 (shaft seal standard)
- Shaft Type: Straight shaft with key (TL31 suffix)
- Frame Size: 40 mm square flange
- Weight: Approx. 0.5 kg
- Ambient Temperature: 0°C to 40°C (operating); -20°C to 65°C (storage)
- Humidity: 20% to 80% RH (non-condensing)
- Compatible Drive: YASKAWA SGDH-01AE / SGDH-01BE series
- Country of Origin: Japan
Proven Application Environments
- Semiconductor & FPD Equipment: Wafer handling, stage positioning, and pick-and-place axes requiring sub-micron repeatability.
- CNC Machine Tools: Auxiliary axes, tool changers, and rotary indexing tables on machining centers.
- Packaging Machinery: High-speed intermittent motion, registration control, and form-fill-seal drives.
- Robotics & Articulated Arms: Wrist and elbow joints in SCARA and 6-axis collaborative robots.
- Medical & Laboratory Automation: Pipetting robots, diagnostic carousel drives, and precision dispensing systems.
- Printing & Converting: Tension control, register correction, and nip roll positioning.
Engineering Advantages
- Low Cogging Torque: Skewed rotor design minimizes torque ripple for smooth low-speed operation — critical in precision contouring and scanning applications.
- High Torque-to-Inertia Ratio: Enables rapid acceleration/deceleration cycles without overshooting, reducing cycle time on high-throughput lines.
- IP67 Sealing: Shaft-end seal and connector sealing allow operation in wash-down and coolant-splash environments without additional enclosures.
- Plug-and-Play with Sigma-II Drives: Auto-tuning and one-parameter setup via SGDH drives eliminates lengthy commissioning; encoder data is read automatically.
- Long Service Life: Precision ball bearings rated for >30,000 hours MTBF under rated load conditions.
- Compact Footprint: 40 mm flange fits space-constrained machine designs without sacrificing torque output.
System Architecture & Signal Flow
The USAHEM-01-TL31 operates within a closed-loop servo system architecture:
- Controller (PLC/CNC/Motion Controller) → issues position/speed/torque commands via pulse-train, analog ±10 V, or MECHATROLINK-II fieldbus to the SGDH servo drive.
- SGDH Servo Drive → performs current-loop control at 16 kHz switching frequency, outputs 3-phase PWM power to the motor stator windings.
- USAHEM-01-TL31 Motor → converts electrical energy to mechanical torque; encoder feedback (A/B/Z differential signals) returns position data to the drive at 2,048 P/R.
- Encoder Feedback Loop → drive closes position and velocity loops in real time, achieving position accuracy of ±1 encoder pulse (≈0.044°).
Wiring: Power connector (MS3102A18-10P or equivalent) + encoder connector (MS3102A20-29P). Shielded encoder cable (YASKAWA JZSP-CMP00-xx) is strongly recommended to maintain signal integrity over distances up to 20 m.
Sourcing & Quality Verification
- Origin: Sourced from authorized YASKAWA distributors and verified OEM supply chains. All units are inspected for authentic labeling, serial number traceability, and undamaged connector/shaft condition prior to dispatch.
- Condition: New (factory-sealed) and refurbished (tested-to-spec) units available — condition specified at time of quotation.
- Documentation: CE Declaration of Conformity, RoHS compliance statement, and YASKAWA product datasheet available upon request.
- Counterfeit Risk Mitigation: Konmask performs visual inspection, label verification, and functional bench-test on all refurbished units. New units ship in original YASKAWA packaging with intact tamper seals.
- Warranty: 12-month warranty on new units; 6-month warranty on refurbished units, covering manufacturing defects under normal operating conditions.
Procurement Process
- Submit RFQ: Contact support@konmask.com or call +0086 19859288691 with your required quantity, delivery timeline, and destination port.
- Receive Quotation: Konmask issues a formal quotation within 1 business day including unit price (HKD/USD), lead time, and shipping options (DHL Express / sea freight / air freight).
- Order Confirmation: Place order via this product page or via PO email. 30% deposit required for orders >10 units; full prepayment for standard orders.
- Quality Inspection & Dispatch: Units inspected, photographed, and packed in anti-static foam. Tracking number provided within 24 hours of dispatch.
- After-Sales Support: Technical support available for installation, drive parameter setup, and troubleshooting via email or WeChat.
Technical FAQ
Q: Is the USAHEM-01-TL31 compatible with SGDM-series drives?
A: No. The USAHEM series is designed for SGDH-series drives. SGDM drives use a different encoder interface and motor parameter set. Cross-series pairing is not supported by YASKAWA and may damage the drive or motor.
Q: Can this motor be used with a third-party servo drive?
A: Technically possible with drives supporting incremental encoder input and 200 VAC 3-phase motors, but YASKAWA does not provide parameter files for third-party drives. Konmask recommends pairing with genuine SGDH drives for guaranteed performance and warranty coverage.
Q: What is the difference between TL31 and TL21 shaft suffixes?
A: TL31 denotes a straight shaft with keyway and IP67 shaft seal. TL21 denotes a straight shaft without keyway. Verify your coupling or pulley bore specification before ordering.
Q: What is the lead time for this model?
A: Stock items ship within 3–5 business days. Non-stock items typically require 4–8 weeks depending on YASKAWA production schedule. Contact us for real-time availability.
Q: Do you provide installation and commissioning support?
A: Yes. Konmask provides remote technical support including SGDH parameter configuration guides, wiring diagrams, and troubleshooting assistance at no additional charge for verified purchasers.
