Precision Motion Control Solution — YASKAWA UGRMEM-01SNQ72 | Σ-III Series
The YASKAWA UGRMEM-01SNQ72 is a compact, high-response AC servo motor from the Sigma-III (Σ-III) series, engineered for applications demanding sub-millisecond positioning accuracy, smooth torque delivery, and long-cycle reliability. As a trusted industrial automation distributor, Konmask.com supplies this model with full traceability to OEM-authorized channels.
Where This Product Is Used
The UGRMEM-01SNQ72 is specified by motion engineers across a broad range of precision-critical industries:
- CNC Machining Centers — Axis feed drives on vertical/horizontal machining centers requiring ±1 arc-min repeatability
- Industrial Robotics — Joint actuators on SCARA and articulated-arm robots in automotive assembly lines
- Semiconductor & Electronics Manufacturing — Wafer handling, PCB pick-and-place, and die-bonding stages
- Packaging Machinery — High-speed indexing, form-fill-seal, and cartoning lines
- Textile & Printing Equipment — Tension control and register correction on web-fed systems
- Medical Device Assembly — Clean-room compatible motion axes requiring low vibration and quiet operation
- AGV / Conveyor Systems — Precision positioning drives in automated material handling
Technical Specifications
| Parameter | Value |
|---|---|
| Manufacturer | YASKAWA Electric Corporation |
| Model Number | UGRMEM-01SNQ72 |
| Series | Σ-III (Sigma-III) |
| Motor Type | AC Servo Motor (Permanent Magnet Synchronous) |
| Rated Output Power | 100 W |
| Rated Torque | 0.318 N·m |
| Rated Speed | 3,000 rpm |
| Maximum Speed | 5,000 rpm |
| Encoder Type | Incremental / Serial Absolute (17-bit) |
| Shaft Type | Straight shaft without key (Q suffix) |
| Brake | None (N suffix) |
| IP Rating | IP67 (dust-tight, water-immersion resistant) |
| Insulation Class | Class F |
| Ambient Temperature | 0°C to +40°C (operating); -20°C to +60°C (storage) |
| Humidity | 20% to 80% RH (non-condensing) |
| Vibration Resistance | 49 m/s² (5G) |
| Weight | Approx. 0.5 kg |
| Compatible Servo Drive | YASKAWA SGDH / SGDS Σ-III Series Amplifiers |
| Mounting Standard | IEC 72-1 Flange Mount |
| Country of Origin | Japan |
Why Engineers Specify This Model
- Ultra-High Resolution Feedback — 17-bit serial absolute encoder delivers 131,072 pulses/rev, enabling sub-micron positioning without homing cycles after power-up
- IP67 Ingress Protection — Fully sealed against coolant splash, cutting fluid, and wash-down environments common in machining and food processing
- Compact Frame, High Power Density — 40 mm flange footprint with 100 W output; ideal for space-constrained multi-axis gantries
- Low Cogging Torque — Skewed rotor design minimizes torque ripple for smooth velocity control at low speeds
- Direct Σ-III Amplifier Compatibility — Plug-and-play with SGDH/SGDS drives; no parameter mapping required
- Proven MTBF — YASKAWA Σ-III motors are rated for >30,000 hours MTBF under rated load conditions
Complete System Bill of Materials
For a fully operational servo axis using the UGRMEM-01SNQ72, engineers typically specify:
- Servo Motor: YASKAWA UGRMEM-01SNQ72 (this unit)
- Servo Amplifier: YASKAWA SGDH-01AE or SGDS-01A (100 W, single-phase 200 VAC)
- Encoder Cable: YASKAWA JZSP-CMP00-03 (3 m) or JZSP-CMP00-05 (5 m)
- Power Cable: YASKAWA JZSP-B9P2E3-03 (3 m)
- Regenerative Resistor: YASKAWA JUSP-RA04 (if duty cycle demands)
- Mounting Coupling: Oldham or bellows coupling, 6 mm bore (match shaft diameter)
- Safety Relay / STO Module: Per IEC 62061 SIL 2 requirements
Contact support@konmask.com for complete BOM sourcing assistance.
Compliance & Industry Standards
- CE Marking — EMC Directive 2014/30/EU & Low Voltage Directive 2014/35/EU
- UL Listed — UL 1004 (Rotating Electrical Machines)
- RoHS Compliant — Directive 2011/65/EU
- IP67 — IEC 60529 Ingress Protection Standard
- Insulation Class F — IEC 60085
- REACH Compliant — SVHC substance declaration available on request
Quality Assurance & Sourcing
Konmask.com operates a rigorous multi-stage quality verification process for all servo motor inventory:
- OEM Traceability — Every unit is sourced through YASKAWA-authorized distribution channels with full lot traceability documentation
- Incoming Inspection — Visual inspection, nameplate verification, encoder signal test, and insulation resistance check (≥100 MΩ at 500 VDC)
- Anti-Counterfeit Verification — Serial number cross-referenced against YASKAWA’s manufacturer database
- Packaging Integrity — Original OEM packaging preserved; ESD-safe handling for encoder electronics
- Warranty — 12-month warranty against manufacturing defects from date of shipment
How to Source This Part
- Request a Quote — Email support@konmask.com with your required quantity and delivery timeline
- Phone / WhatsApp — +0086 19859288691 (Mon–Sat, 09:00–18:00 CST)
- Lead Time — In-stock units ship within 2 business days; ex-stock orders within 7–14 business days
- Export Documentation — Commercial invoice, packing list, COO certificate, and YASKAWA test report available
- Payment Terms — T/T, PayPal, and trade assurance accepted; OEM/volume pricing available for orders ≥5 units
Application-Specific FAQ
Q: Is the UGRMEM-01SNQ72 compatible with SGDV (Σ-V) amplifiers?
A: No. The Σ-III motor connector and encoder protocol differ from Σ-V. Use SGDH or SGDS amplifiers. Cross-series use requires a conversion cable and parameter adjustment — contact our engineers for guidance.
Q: Can this motor be used in a vertical axis application without a brake?
A: The UGRMEM-01SNQ72 has no integrated brake (N suffix). For vertical axes, a separate external brake or counterbalance mechanism is required to prevent load drop on E-stop or power loss.
Q: What is the maximum cable length between motor and amplifier?
A: YASKAWA specifies a maximum of 20 m for encoder cable and 30 m for power cable with standard wiring. Longer runs require shielded cable and may need a line driver booster.
Q: Is IP67 rating maintained after shaft seal wear?
A: IP67 is rated for new units. In continuous rotation applications with coolant exposure, inspect the shaft seal annually and replace per YASKAWA’s maintenance schedule.
Q: Do you provide YASKAWA test reports or factory certificates?
A: Yes. Factory test reports and certificates of conformance are available for all units. Request at time of order via support@konmask.com.
