YASKAWA YPLT31006-1A – Drive Control Circuit Board | AC Drive Series
The YASKAWA YPLT31006-1A is an OEM drive control circuit board engineered for YASKAWA AC drive systems. Designed for procurement engineers and maintenance teams who require a verified, drop-in replacement PCB that restores full drive functionality without system redesign. Sourced directly from authorized channels and rigorously tested before dispatch.
Product Positioning: This board serves as the primary control intelligence within compatible YASKAWA AC drive units, governing PWM signal generation, fault detection, and closed-loop speed regulation. It is the preferred replacement component for field engineers managing industrial uptime-critical environments.
Complete Technical Specifications
- Part Number / SKU: YPLT31006-1A
- Manufacturer: YASKAWA Electric Corporation
- Component Type: Drive Control Circuit Board (PCB)
- Function: AC drive control — PWM generation, speed reference processing, fault logic, I/O interface
- Country of Origin: Japan
- Compatibility: YASKAWA AC drive series (confirm drive model with engineering team prior to order)
- Board Weight: Approx. 4,460 g (shipping weight including protective packaging)
- Condition: New / Refurbished OEM (specify at inquiry)
- Warranty: 12-month functional warranty from Konmask.com
Proven Application Environments
- Heavy industrial manufacturing lines requiring precise motor speed control
- HVAC and pump systems with variable frequency drive (VFD) configurations
- Crane, hoist, and conveyor drive systems
- CNC machining centers and servo-integrated production equipment
- Water treatment and process automation facilities
- Power generation auxiliary drive systems
Engineering Advantages
- OEM Authenticity: Genuine YASKAWA part — no third-party clone risk, full firmware compatibility
- Drop-In Replacement: Maintains original connector pinout and mounting footprint; no rewiring required
- Pre-Shipment Testing: Each board undergoes functional verification before dispatch
- Reduced Downtime: In-stock availability enables same-week dispatch for urgent MRO requirements
- Traceability: Full lot traceability documentation available upon request for quality audits
- Global Compliance: Meets CE and RoHS directives applicable to industrial electronic components
System Architecture & Signal Flow
The YPLT31006-1A operates as the central control node within the drive’s power electronics stack. It receives speed reference signals (analog/digital), processes closed-loop feedback from encoder or current sensors, and outputs PWM gate signals to the IGBT power module. Fault detection logic monitors over-current, over-voltage, thermal, and communication error states, triggering protective shutdowns and logging fault codes accessible via the drive’s operator panel or serial interface.
Note: Integration with external PLC or DCS systems is achieved via the drive’s I/O terminal block — the YPLT31006-1A interfaces with these signals internally. Confirm compatibility with your drive’s firmware revision before installation.
Sourcing & Quality Verification
- Source: Authorized distributor network and OEM surplus channels
- Inspection: Visual inspection + functional power-on test performed at Konmask warehouse
- Packaging: Anti-static ESD bag + foam-lined carton for international transit
- Documentation: Certificate of conformity, test report, and packing list included
- Lead Time: In-stock items ship within 1–3 business days; contact us for bulk order scheduling
Procurement Process
- Confirm Compatibility: Share your drive model number and nameplate data with our technical team
- Request Quotation: Email support@konmask.com with quantity and delivery requirements
- Order Placement: Purchase online or via proforma invoice for corporate procurement
- Dispatch & Tracking: ESD-safe packaging dispatched via DHL / FedEx with full tracking
- Installation Support: Technical guidance available post-delivery at no additional charge
Technical FAQ
Q: Is the YPLT31006-1A compatible with all YASKAWA drive models?
A: No — this board is specific to certain YASKAWA AC drive series. Please confirm your drive model number before ordering. Our engineers will verify compatibility within 24 hours.
Q: Can this board be reprogrammed or flashed with updated firmware?
A: Firmware is factory-loaded and model-specific. Field firmware updates should only be performed using YASKAWA’s official DriveWizard software and applicable firmware packages.
Q: What is the return policy if the board does not resolve the fault?
A: We offer a 30-day return window for unused boards. For boards installed and tested, our 12-month warranty covers functional defects. Contact support@konmask.com to initiate an RMA.
Q: Do you provide MSDS or RoHS documentation?
A: Yes. RoHS compliance declaration and material safety documentation are available upon request for regulatory submissions.
