Analog Signal Acquisition Solution — YOKOGAWA AAI141-S00 S2 | CENTUM VP Series
Where This Product Is Used
The YOKOGAWA AAI141-S00 S2 Analog Input Module is deployed in mission-critical process control environments where accurate, real-time analog signal acquisition is non-negotiable. Typical installation sites include:
- Oil & Gas Refineries — Continuous monitoring of flow, pressure, and temperature transmitters across distillation columns and pipeline segments.
- Chemical & Petrochemical Plants — Integration with 4–20 mA field instruments for reactor temperature and level control loops.
- Power Generation Facilities — Turbine and boiler control systems requiring high-density analog input with galvanic isolation.
- Pulp & Paper Mills — Multi-loop process control where consistent signal fidelity across long cable runs is essential.
- Water & Wastewater Treatment — SCADA-integrated DCS architectures monitoring pH, dissolved oxygen, and flow sensors.
- Pharmaceutical Manufacturing — GMP-compliant process automation requiring validated, traceable analog signal chains.
Technical Specifications
| Parameter | Specification |
|---|---|
| Model | AAI141-S00 S2 |
| Manufacturer | YOKOGAWA Electric Corporation |
| Series | CENTUM VP / CS 3000 |
| Module Type | Analog Input Module |
| Number of Channels | 8 channels |
| Input Signal Range | 4–20 mA DC (standard); 1–5 V DC (optional) |
| Resolution | 16-bit A/D conversion |
| Isolation | Channel-to-channel and channel-to-bus galvanic isolation |
| Scan Cycle | Configurable; compatible with CENTUM VP control cycle |
| Power Consumption | Refer to YOKOGAWA AAI141 datasheet |
| Operating Temperature | 0°C to 55°C |
| Storage Temperature | -20°C to 60°C |
| Humidity | 5% to 95% RH (non-condensing) |
| Weight | Approx. 300 g |
| Mounting | CENTUM VP I/O nest (plug-in module) |
| Suffix -S00 | Standard configuration, no HART communication |
| Suffix S2 | SIL 2 functional safety rated |
Why Engineers Specify This Model
- SIL 2 Safety Rating (S2 suffix) — Certified for use in Safety Instrumented Systems (SIS) per IEC 61508, enabling integration into safety loops without additional safety relays.
- 16-bit Resolution — Delivers 0.003% full-scale accuracy, critical for tight PID control in refinery and chemical applications.
- Galvanic Isolation — Eliminates ground loop interference in large-scale plant installations with long cable runs between field instruments and the control room.
- Plug-in Hot-Swap Design — Allows module replacement without shutting down the I/O nest, minimizing process downtime during maintenance windows.
- Native CENTUM VP Integration — Zero-configuration compatibility with YOKOGAWA’s CENTUM VP DCS platform; recognized automatically by the engineering station.
- Proven Field Reliability — YOKOGAWA’s AAI series has accumulated decades of deployment in Tier 1 process industries globally.
Complete System Bill of Materials
For a fully operational CENTUM VP analog input subsystem, engineers typically specify the following alongside the AAI141-S00 S2:
- I/O Nest / Node Unit — ANB10D or ANR10D (remote node) for housing the AAI141 module
- Field Control Station (FCS) — AFCS135 or AFCS140 as the host controller
- Power Supply Module — APW100 or APW110 for I/O nest power
- Terminal Board — ATB141 (marshalling terminal board for AAI141 field wiring)
- Cable Assembly — ACB141 (connector cable between AAI141 and ATB141)
- Engineering Workstation — Running CENTUM VP R6.x or later for configuration
- Redundancy Module (optional) — For SIL 2 architectures, a redundant AAI141-S00 S2 pair is recommended
Contact Konmask.com for bundle pricing on complete I/O subsystem configurations.
Compliance & Industry Standards
- IEC 61508 — Functional Safety of E/E/PE Safety-related Systems (SIL 2 certified, S2 suffix)
- IEC 61511 — Functional Safety for the Process Industry Sector
- CE Marking — Compliant with EU EMC and Low Voltage Directives
- UL / cUL Listed — North American safety certification
- ATEX / IECEx — Consult YOKOGAWA for zone-rated installation configurations
- RoHS Compliant — Restriction of Hazardous Substances Directive
- ISA-5.1 — Instrumentation symbols and identification compatibility
Quality Assurance & Sourcing
Konmask.com sources the YOKOGAWA AAI141-S00 S2 through verified industrial automation supply channels. Every unit offered is subject to the following quality controls:
- Visual Inspection — PCB, connector pins, and housing checked for physical damage or counterfeit indicators prior to listing.
- Traceability — Batch and serial number documentation maintained for each unit.
- Functional Verification — Where applicable, modules are bench-tested against YOKOGAWA I/O specifications before dispatch.
- Secure Packaging — Anti-static ESD packaging with foam cushioning for international shipment.
- Warranty — 90-day replacement warranty against DOA (Dead on Arrival) defects. Extended warranty available on request.
How to Source This Part
- Add to Cart — Click “Add to Cart” above to proceed directly to checkout.
- Request a Quote — For bulk orders (5+ units) or project-based procurement, email support@konmask.com with your project BOM for volume pricing.
- Lead Time — In-stock units ship within 1–3 business days. Out-of-stock units: estimated lead time provided upon inquiry.
- Export & Cross-Border — We ship internationally. Contact us for export documentation, HS code confirmation (8537.10), and freight options.
- Payment — T/T (bank transfer), PayPal, and major credit cards accepted. Net-30 terms available for qualified accounts.
Application-Specific FAQ
Q: Is the AAI141-S00 S2 compatible with CENTUM CS 3000?
A: Yes. The AAI141 series is backward-compatible with CENTUM CS 3000 I/O nests, though SIL 2 functionality requires CENTUM VP R5.03 or later firmware on the FCS.
Q: Can this module accept HART signals?
A: The -S00 suffix indicates no HART communication capability. For HART pass-through, specify the AAI141-H00 variant instead.
Q: What is the difference between the S2 suffix and a standard AAI141?
A: The S2 suffix denotes SIL 2 certification per IEC 61508. This version includes additional diagnostic coverage and is approved for use in Safety Instrumented Functions (SIF) without external safety relays.
Q: Can I use this module in a redundant I/O configuration?
A: Yes. CENTUM VP supports dual-redundant I/O configurations. Two AAI141-S00 S2 modules can be paired in a redundant nest for high-availability SIL 2 loops.
Q: Do you provide the ATB141 terminal board and ACB141 cable?
A: Yes. Contact us at support@konmask.com to confirm availability of associated accessories for your project.
Q: What is the lead time for out-of-stock units?
A: Typical lead time for sourced units is 2–6 weeks depending on global availability. We maintain supplier relationships across Asia-Pacific and European distribution networks.
