YOKOGAWA ADV159-P00 Digital Input Module | Replacement, Equivalent & Selection Guide
The YOKOGAWA ADV159-P00 is a high-density Digital Input (DI) module designed for use with the CENTUM CS3000 / CENTUM VP Distributed Control System (DCS) platform. It provides reliable field signal acquisition for industrial process automation environments. This page serves as a comprehensive selection, replacement, and compatibility reference for engineers and procurement teams sourcing this module or its equivalents.
Technical Specifications
| Part Number | ADV159-P00 |
| Manufacturer | YOKOGAWA Electric Corporation |
| Module Type | Digital Input (DI) Module |
| Compatible Platform | CENTUM CS3000 / CENTUM VP (ST3 Field Control Station) |
| Input Channels | 32 channels (typical for ADV159 series) |
| Input Signal Type | Dry contact / Wet contact (24 VDC) |
| Isolation | Optical isolation between field and system |
| Communication | Internal V-net / ESB bus (CENTUM VP architecture) |
| Power Supply | Supplied via backplane (no external power required) |
| Operating Temperature | 0°C to 55°C |
| Weight | Approx. 320 g |
| Certifications | CE, UL (refer to YOKOGAWA datasheet for full listing) |
Note: Always verify specifications against the official YOKOGAWA datasheet (GS 33J60B10-01EN) before final procurement.
Compatible Replacement & Equivalent Models
When the ADV159-P00 is unavailable or end-of-life, the following models may serve as functional replacements depending on your system configuration. Always validate compatibility with your system integrator before substitution.
| Model | Manufacturer | Type | Compatibility Notes |
|---|---|---|---|
| ADV159-P10 | YOKOGAWA | DI Module | Variant with different terminal block; same I/O count |
| ADV151-P00 | YOKOGAWA | DI Module | 16-channel DI; use when lower channel density is acceptable |
| ADV161-P00 | YOKOGAWA | DI Module | High-speed DI variant; check scan rate requirements |
| ADV159-P00 (Refurbished) | Third-party / OEM | DI Module | Tested & certified refurbished units available via Konmask |
| Custom Equivalent | Contact Konmask | DI Module | Cross-reference available upon request for other DCS platforms |
Why Choose the Original Model
- Guaranteed Compatibility: Factory-validated for CENTUM CS3000 and CENTUM VP ST3 stations — no firmware or configuration risk.
- Long Service Life: YOKOGAWA modules are engineered for 10+ year operational cycles in continuous process environments.
- Seamless Integration: Plug-and-play replacement within existing CENTUM VP I/O racks — no re-engineering required.
- OEM Support: Full YOKOGAWA technical documentation, firmware updates, and field service support available.
- Traceability: Original modules carry full manufacturing traceability for regulated industries (pharma, oil & gas, power).
Typical Applications
- Oil & Gas upstream/downstream process control (valve position feedback, pump status monitoring)
- Chemical and petrochemical plant DCS integration
- Power generation — turbine and boiler control systems
- Pharmaceutical manufacturing (FDA-regulated batch control)
- Pulp & paper, water treatment, and general process industries
- Emergency Shutdown System (ESD) digital signal acquisition (verify SIL rating separately)
System Compatibility
The ADV159-P00 is designed for installation in the following YOKOGAWA system architectures:
- CENTUM CS3000 — Field Control Station FCS (ST3 type I/O nest)
- CENTUM VP R4.x / R5.x / R6.x — Compatible with current VP platform revisions
- Nest Type: Standard I/O nest (not compatible with RIO or FIO remote I/O nests without adapter)
- Slot Position: Any standard I/O slot in the ST3 nest; confirm slot assignment in your system builder
Not compatible with CENTUM XL, CENTUM μXL, or STARDOM FCN/FCJ platforms.
Selection Guide
Use the following criteria to confirm the ADV159-P00 is the correct module for your application:
- Step 1 — Platform Check: Confirm your FCS is a CENTUM CS3000 or CENTUM VP ST3 station.
- Step 2 — Channel Count: Verify you require 32 DI channels per module slot. If 16 channels suffice, consider ADV151-P00.
- Step 3 — Signal Type: Confirm field signals are dry or 24 VDC wet contact. For NAMUR sensors, a different module is required.
- Step 4 — Terminal Block: Distinguish between -P00 (standard terminal) and -P10 (MIL connector) suffix based on your field wiring.
- Step 5 — Redundancy: If redundant DI is required, confirm your nest and FCS support dual-module redundancy configuration.
- Step 6 — Revision: Check hardware revision compatibility with your CENTUM VP software version (use YOKOGAWA compatibility matrix).
Quality Assurance & Sourcing
- Source: Konmask.com sources ADV159-P00 modules from authorized distributors and verified secondary market suppliers.
- Inspection: All units undergo visual inspection, functional verification, and firmware version check prior to shipment.
- Warranty: 12-month warranty on new units; 90-day warranty on refurbished/tested units.
- Counterfeit Prevention: We do not source from unverified grey-market channels. Certificates of conformance available on request.
- Lead Time: In-stock units ship within 1–3 business days. Contact us for urgent or bulk requirements.
How to Order
- Confirm your part number: ADV159-P00 (include hardware revision if known).
- Specify quantity and required delivery date.
- Contact Konmask via email or phone for a formal quotation.
- Submit purchase order — we accept T/T, L/C, and major B2B payment terms.
- Receive shipping confirmation with tracking and certificate of conformance.
Email: support@konmask.com | Phone/WhatsApp: +0086 19859288691
Replacement & Compatibility FAQ
Q: Can ADV159-P00 replace ADV159-P10 directly?
A: Functionally yes — both are 32-channel DI modules for the same platform. The difference is the terminal block type (-P00 = screw terminal, -P10 = MIL connector). Field wiring must match the terminal type.
Q: Is ADV159-P00 compatible with CENTUM VP R6.x?
A: Yes, the ADV159-P00 is supported on CENTUM VP R6.x. Verify the hardware revision against YOKOGAWA’s compatibility matrix for your specific software build.
Q: Can I use a third-party DI module as a replacement?
A: Third-party modules are not officially supported by YOKOGAWA and may cause system alarms or communication errors. Konmask recommends using original or certified refurbished YOKOGAWA modules.
Q: What is the lead time for ADV159-P00?
A: In-stock units ship within 1–3 business days. Out-of-stock units typically have a 2–6 week lead time depending on sourcing. Contact us for current availability.
Q: Do you provide a certificate of conformance?
A: Yes. A certificate of conformance and inspection report are available for all units upon request.
Q: Can Konmask assist with cross-referencing to other DCS platforms?
A: Yes. Our engineering team can assist with cross-referencing YOKOGAWA modules to equivalent modules on ABB, Honeywell, Emerson, or Siemens DCS platforms. Contact us with your requirements.
