Yokogawa ANB10D-427/CU2T ESB Bus Node Unit | Replacement, Equivalent & Selection Guide
The Yokogawa ANB10D-427/CU2T is an ESB (Extended Serial Backplane) Bus Node Unit designed for use in Yokogawa CENTUM CS3000 and CENTUM VP Distributed Control Systems (DCS). It provides high-speed, deterministic communication between field control stations and I/O modules via the ESB bus architecture. Konmask.com supplies genuine and compatible units with full traceability for industrial automation projects worldwide.
Technical Specifications
- Part Number: ANB10D-427/CU2T
- Manufacturer: Yokogawa Electric Corporation
- Series: CENTUM CS3000 / CENTUM VP
- Function: ESB Bus Node Unit – interfaces field control stations with remote I/O units over the ESB bus
- Bus Type: ESB (Extended Serial Backplane) Bus
- Communication Speed: High-speed deterministic serial bus
- Mounting: DIN rail / backplane slot mount
- Power Supply: Supplied via backplane (24 VDC system bus)
- Operating Temperature: 0 °C to 55 °C
- Storage Temperature: −25 °C to 70 °C
- Humidity: 5% to 95% RH (non-condensing)
- Weight: Approx. 2,480 g (module + housing)
- Certifications: CE, UL (refer to Yokogawa datasheet for full compliance list)
- Suffix /CU2T: Denotes specific hardware revision and connector configuration
Compatible Replacement & Equivalent Models
When the ANB10D-427/CU2T is unavailable or end-of-life, the following models may serve as direct or functional replacements depending on system configuration. Always verify firmware and backplane compatibility before substitution.
- ANB10D-427/CU2 – Same base module, earlier connector suffix; verify slot compatibility
- ANB10S-427/CU2T – Simplex variant; suitable for non-redundant node applications
- ANB10D-427 – Base model without suffix options; confirm hardware revision with Yokogawa
- ANB11D – Next-generation ESB node for CENTUM VP R6 and later; requires firmware update
- Third-party ESB node units – Not recommended; ESB bus protocol is proprietary to Yokogawa
Note: Konmask.com recommends using genuine Yokogawa parts for safety-critical loops. Contact our team for cross-reference verification.
Why Choose the Original ANB10D-427/CU2T
- ✅ Guaranteed protocol compatibility – Native ESB bus timing and addressing, no configuration workarounds
- ✅ Redundancy support – Dual-redundant node architecture (D suffix) for high-availability systems
- ✅ Seamless integration – Plug-and-play with CENTUM CS3000 R3/R4 and CENTUM VP R5/R6 engineering stations
- ✅ Long service life – Yokogawa industrial-grade components rated for continuous 24/7 operation
- ✅ Full traceability – Genuine units supplied with manufacturer documentation and test records
Typical Applications
- Oil & gas refinery DCS field control stations
- Chemical and petrochemical plant automation
- Power generation and utilities control systems
- Pulp and paper process control
- Pharmaceutical batch control systems
- Water treatment and environmental monitoring
System Compatibility
- Yokogawa CENTUM CS3000 – R3.xx, R4.xx (primary target platform)
- Yokogawa CENTUM VP – R5.xx, R6.xx (verify suffix compatibility)
- Field Control Stations: FCS, FFCS, SFCS series
- Remote I/O Units: RIO bus nodes via ESB-to-RIO bridge modules
- Engineering Workstation: CENTUM VP Engineering Environment (ENG)
Not compatible with CENTUM XL, μXL, or STARDOM FCN/FCJ platforms.
Selection Guide
Use the table below to select the correct ANB10D variant for your application:
- Redundant node required? → Choose ANB10D-427/CU2T (D = Dual/Redundant)
- Simplex node sufficient? → Consider ANB10S-427/CU2T for cost savings
- CENTUM VP R6 or later? → Evaluate ANB11D for forward compatibility
- Replacing an existing unit? → Match the full part number including suffix (/CU2T) to ensure connector and firmware alignment
- Spare parts inventory? → Konmask.com offers quantity pricing; contact us for bulk orders
Quality Assurance & Sourcing
- All units sourced from authorized distributors or directly from Yokogawa-certified channels
- Pre-shipment inspection: visual check, label verification, and functional power-on test where applicable
- Anti-static packaging with humidity indicator cards for long-distance shipping
- Counterfeit prevention: serial number and date code verification on every unit
- Warranty: 12 months from date of shipment (see full terms at Konmask.com/policies)
How to Order
- Confirm your system platform (CENTUM CS3000 or CENTUM VP) and firmware revision
- Verify the required suffix (/CU2T) matches your existing backplane connectors
- Add to cart or contact support@konmask.com for a formal quotation
- Provide your shipping address and preferred Incoterms (EXW, FOB Xiamen, CIF, DDP available)
- Lead time: In-stock units ship within 3–5 business days; sourced units 2–4 weeks
Replacement & Compatibility FAQ
Q: Can ANB10D-427/CU2T replace ANB10D-427/CU2 directly?
A: In most cases yes, but verify the backplane connector pinout and firmware version in your CENTUM engineering environment before hot-swapping.
Q: Is this module compatible with CENTUM VP R6?
A: The ANB10D-427/CU2T is primarily validated for CS3000 R3/R4 and VP R5. For VP R6, Yokogawa recommends evaluating the ANB11D. Contact us for a compatibility assessment.
Q: Can I use a third-party ESB bus node?
A: The ESB bus protocol is proprietary. Third-party nodes are not supported and may cause communication faults or system instability.
Q: Do you provide a test report with the unit?
A: Yes. A pre-shipment inspection report is available upon request for all orders.
Q: What is the lead time for out-of-stock units?
A: Typically 2–4 weeks for sourced units. Contact us early for project planning.
