Analog Signal Acquisition Solution – YOKOGAWA ASI133-S00 | CENTUM VP / ProSafe Series
Where This Product Is Used
The YOKOGAWA ASI133-S00 Analog Input Module is deployed across high-reliability process control environments where precise signal acquisition is mission-critical. Typical installation sites include:
- Oil & Gas Upstream / Midstream: Wellhead pressure and temperature monitoring, pipeline flow measurement, compressor station control loops.
- Petrochemical & Refining: Distillation column level sensing, reactor temperature profiling, heat-exchanger differential pressure loops.
- Power Generation: Turbine inlet/outlet parameter acquisition, boiler drum level control, generator excitation feedback.
- Pulp & Paper / Chemical: pH, conductivity, and dissolved-oxygen loop inputs feeding DCS regulatory control.
- Water & Wastewater Treatment: Flow totalizer inputs, dosing pump feedback, clarifier level monitoring.
- Pharmaceutical & Food Processing: Clean-in-place (CIP) temperature verification, batch reactor pressure acquisition under FDA 21 CFR Part 11 environments.
Technical Specifications
| Manufacturer | YOKOGAWA Electric Corporation |
| Part Number | ASI133-S00 |
| Module Type | Analog Input (AI) Module |
| Compatible Platform | CENTUM VP / CENTUM CS 3000 / ProSafe-RS |
| Signal Types Supported | 4–20 mA DC (HART-compatible), 1–5 V DC |
| Number of Channels | 8 channels (isolated) |
| Input Resolution | 16-bit A/D conversion |
| Accuracy | ±0.1% of full scale |
| Isolation | Channel-to-channel and channel-to-bus isolation |
| Power Consumption | Supplied via I/O bus backplane |
| Operating Temperature | 0°C to +60°C |
| Storage Temperature | -25°C to +70°C |
| Humidity | 5% to 95% RH (non-condensing) |
| Weight | 500 g (approx.) |
| Suffix Code -S00 | Standard configuration, no special options |
| Form Factor | Plug-in card for YOKOGAWA I/O nest / node unit |
Why Engineers Specify This Model
- High-Density Channel Count: 8 isolated AI channels per slot maximise I/O density in space-constrained marshalling cabinets.
- 16-Bit Resolution: Delivers fine-grained process variable resolution essential for tight regulatory control loops (e.g., cascade temperature control).
- HART Pass-Through: Enables device diagnostics and remote configuration of HART-enabled field instruments without additional multiplexers.
- Hot-Swap Capability: Supports online module replacement in redundant CENTUM VP configurations, eliminating planned shutdowns for maintenance.
- Proven Platform Longevity: CENTUM VP has an established multi-decade lifecycle with YOKOGAWA’s committed long-term parts support policy.
- Deterministic Scan Cycle: Synchronised with the CENTUM VP field control station (FCS) scan for predictable, jitter-free data acquisition.
Complete System Bill of Materials
A typical CENTUM VP analog input node incorporating the ASI133-S00 requires the following components:
- ASI133-S00 — Analog Input Module (this item)
- ANB10D / ANB11D — Node Unit (I/O nest / backplane)
- AIP588-S00 — I/O Power Supply Module
- ACM12 / ACM22 — Communication Module (ESB bus or ER bus)
- Terminal Board (TB) — Field wiring termination (model per channel count and signal type)
- Cable Assembly — Between I/O module and terminal board
- CENTUM VP FCS (e.g., AFV10D) — Field Control Station
- HART Multiplexer (optional) — If centralised HART asset management is required
Contact Konmask for complete BOM verification against your existing CENTUM VP revision and software version.
Compliance & Industry Standards
- CE Marking — EMC Directive and Low Voltage Directive compliant
- IEC 61511 / IEC 61508 — Applicable when used within ProSafe-RS safety instrumented system configurations
- NAMUR NE 43 — Fault-state signal level conventions for 4–20 mA loops
- HART Communication Foundation — HART 5/6/7 protocol compatibility
- RoHS Compliant — Restriction of Hazardous Substances
- UL / cUL Listed — Where applicable per YOKOGAWA product certification matrix
Quality Assurance & Sourcing
Konmask.com sources YOKOGAWA ASI133-S00 modules through authorised distribution channels and verified secondary-market suppliers with full traceability documentation. Every unit offered is subject to:
- Visual and dimensional inspection against YOKOGAWA OEM specifications
- Firmware / label verification to confirm genuine YOKOGAWA manufacture
- Functional power-on test where test fixtures are available
- Anti-static packaging with humidity indicator cards for safe international transit
- Certificate of Conformance (CoC) available upon request
- 90-day warranty covering manufacturing defects under normal operating conditions
How to Source This Part
- Add to Cart — Proceed directly for in-stock units with same-day or next-business-day dispatch.
- Request a Quote — For volume orders (5+ units), OEM pricing, or long-term blanket orders, email support@konmask.com.
- Urgent / Shutdown Requirements — Call or WhatsApp +0086 19859288691 for expedited sourcing and air-freight options.
- Cross-Reference Check — If you are unsure whether ASI133-S00 is the correct replacement for your existing module, share your system model and I/O nest revision with our engineering team for confirmation.
- Export & Customs — Konmask handles export documentation (commercial invoice, packing list, HS code declaration) for international shipments.
Application-Specific FAQ
Q: Is the ASI133-S00 compatible with CENTUM CS 3000 as well as CENTUM VP?
A: The ASI133-S00 is primarily designed for CENTUM VP I/O nests. Compatibility with CS 3000 depends on the specific node revision. Contact our team with your CS 3000 FCS model number for confirmation.
Q: Can this module be used in a SIL-rated safety loop?
A: For SIL-rated applications, YOKOGAWA’s ProSafe-RS platform with dedicated safety I/O modules is the correct solution. The ASI133-S00 is a standard (non-safety) AI module and should not be used as the primary safety element in a SIL loop without a formal functional safety assessment.
Q: Does the module support HART communication?
A: Yes. The ASI133-S00 supports HART pass-through, allowing HART commands to be issued to field devices via the CENTUM VP HART DTM or an external HART multiplexer.
Q: What is the scan cycle time for analog inputs on this module?
A: Scan cycle is determined by the CENTUM VP FCS configuration, typically 100 ms to 1000 ms selectable. The ASI133-S00 updates its channel data synchronously with the FCS scan.
Q: Can I replace a failed ASI133-S00 online without shutting down the process?
A: In a redundant CENTUM VP configuration with a standby FCS or redundant I/O, hot-swap replacement is supported. In a simplex configuration, the associated control loops will go to their configured fail-safe state during module replacement.
Q: What lead time should I expect?
A: In-stock units ship within 1–2 business days. For sourced units, typical lead time is 3–10 business days depending on global inventory availability. Expedited options are available — contact us for urgent requirements.
