YOKOGAWA ADV561-P00 S2 Digital Output Module | Replacement, Equivalent & Selection Guide
The YOKOGAWA ADV561-P00 S2 is a high-reliability digital output module designed for use in YOKOGAWA CENTUM VP and CS 3000 distributed control systems (DCS). This page provides full technical specifications, compatible replacement models, system integration guidance, and a structured selection guide to help engineers and procurement teams make confident sourcing decisions.
Technical Specifications
- Manufacturer: YOKOGAWA Electric Corporation
- Part Number: ADV561-P00 S2
- Module Type: Digital Output (DO) Module
- Output Points: 16 points (typical for ADV561 series)
- Output Type: Transistor (sink/source, model-dependent)
- Rated Voltage: 24 VDC
- Isolation: Optical isolation between field and system bus
- Communication Bus: YOKOGAWA ESB (Enhanced Signal Bus) / V-net
- Mounting: DIN rail / node unit slot
- Operating Temperature: 0°C to 55°C
- Weight: Approx. 200 g
- Compliance: CE, UL, IEC 61508 (SIL-capable platform)
- Suffix S2: Indicates specific hardware revision / conformal coating variant
Compatible Replacement & Equivalent Models
When the ADV561-P00 S2 is discontinued, hard to source, or requires a cost-effective alternative, the following models may serve as functional equivalents. Always verify electrical and firmware compatibility before substitution.
- YOKOGAWA ADV561-P00 S1 — Earlier hardware revision; functionally identical in most applications. Confirm suffix compatibility with your node firmware version.
- YOKOGAWA ADV561-P10 — Extended variant with additional diagnostic features; drop-in compatible in CENTUM VP R5 and above.
- YOKOGAWA ADV151-P50 — 32-point DO module; suitable when channel density upgrade is acceptable.
- YOKOGAWA ADV561-P00 (no suffix) — Base revision; verify hardware generation with YOKOGAWA FAE before substitution.
- Third-party equivalents: Consult Konmask engineering team for validated cross-reference to Siemens, ABB, or Honeywell DO modules in retrofit projects.
Why Choose the Original Model
- Guaranteed system compatibility: Native integration with CENTUM VP / CS 3000 without additional configuration.
- Firmware-certified: Validated against YOKOGAWA’s official firmware release matrix.
- Safety integrity: Supports SIL-rated loops when used within certified system architecture.
- Long service life: YOKOGAWA modules are designed for 10+ year operational cycles in continuous process environments.
- OEM traceability: Full manufacturing traceability and certificate of conformance available upon request.
Typical Applications
- Petrochemical and refinery DCS control loops
- Power generation plant automation (turbine, boiler control)
- Pharmaceutical batch process control
- Pulp & paper and water treatment facilities
- Offshore platform and pipeline SCADA integration
- Steel and metallurgical process automation
System Compatibility
- YOKOGAWA CENTUM VP R4.01 and above (recommended R5.03+)
- YOKOGAWA CS 3000 R3.08 and above
- Node Units: ANB10D, ANB11D, ANR10D series
- Engineering Tool: CENTUM VP Builder / CS 3000 Builder
- Not compatible with: YOKOGAWA STARDOM, ProSafe-RS (separate module families)
⚠️ Always confirm node unit slot assignment and I/O builder tag configuration before installation.
Selection Guide
Use the following criteria to confirm the ADV561-P00 S2 is the correct module for your application:
- ✅ Output type required: Digital (discrete) output — not analog
- ✅ Field voltage: 24 VDC field devices (solenoids, relays, indicators)
- ✅ Point count: 16 DO points per module slot
- ✅ DCS platform: CENTUM VP or CS 3000
- ✅ Suffix S2: Required if your node firmware mandates S2 hardware revision
- ❌ If you need analog output → consider AAV141 or AAV542 series
- ❌ If you need digital input → consider ADV151 series
- ❌ If your platform is ProSafe-RS → consult separate safety module catalog
Quality Assurance & Sourcing
- Stock status: In-stock and available for immediate shipment (subject to inventory)
- Condition: New original, refurbished OEM, and tested surplus options available
- Testing: All modules undergo functional power-on and I/O point verification prior to dispatch
- Packaging: Anti-static ESD packaging with original or equivalent protective casing
- Documentation: Certificate of conformance, test report, and datasheet available on request
- Lead time: In-stock items ship within 1–3 business days; sourced items 5–15 business days
- Warranty: 12-month warranty against manufacturing defects
How to Order
- Confirm your part number: ADV561-P00 S2 (verify suffix with your system documentation)
- Specify quantity and required condition (new / refurbished / tested surplus)
- Submit your enquiry via [email protected] or use the store checkout
- Receive quotation with lead time, shipping options, and payment terms within 24 hours
- For urgent requirements, call +0086 19859288691 directly
Replacement & Compatibility FAQ
Q: Can I replace ADV561-P00 S2 with ADV561-P00 S1?
A: In most cases yes, but the suffix revision must match the minimum hardware requirement of your node firmware. Check YOKOGAWA TI (Technical Information) document for your CENTUM VP version.
Q: Is the ADV561-P00 S2 compatible with CENTUM VP R6?
A: Yes. YOKOGAWA maintains backward hardware compatibility across CENTUM VP major releases. Confirm with your system integrator for site-specific validation.
Q: Can this module be used in a SIL 2 safety loop?
A: The ADV561 series is part of the CENTUM VP platform which supports SIL-capable architectures. However, SIL certification depends on the complete loop design, not the module alone. Consult your functional safety engineer.
Q: Do you supply YOKOGAWA modules with full traceability documentation?
A: Yes. New original modules come with full OEM traceability. Refurbished and surplus units include our internal test certificate. Contact us for specific documentation requirements.
Q: What is the lead time for ADV561-P00 S2?
A: In-stock units ship within 1–3 business days. If sourcing is required, typical lead time is 5–15 business days depending on supply chain availability.
