Industrial Ethernet Communication Solution – YOKOGAWA F3LE01-5T | FA-M3 Series
Where This Product Is Used
The YOKOGAWA F3LE01-5T Ethernet Interface Module is deployed across a wide range of industrial automation environments where reliable, high-speed network communication between PLCs and supervisory systems is critical:
- Process Manufacturing Plants – Connects FA-M3 PLCs to DCS/SCADA systems over Ethernet for real-time process data exchange in chemical, petrochemical, and refining facilities.
- Automotive Assembly Lines – Enables deterministic Ethernet communication between production-line controllers and MES platforms, supporting traceability and OEE monitoring.
- Water & Wastewater Treatment – Integrates remote pump stations and valve actuators into centralized SCADA networks via Modbus TCP or FINS protocol.
- Power Generation & Utilities – Provides Ethernet backbone connectivity for substation automation and distributed energy management systems.
- Food & Beverage Processing – Supports hygienic-area PLC networking where fiber or copper Ethernet replaces legacy serial fieldbus wiring.
- Semiconductor Fab Equipment – Facilitates high-speed data logging and recipe management between FA-M3 controllers and host computers.
Technical Specifications
| Parameter | Value |
|---|---|
| Model Number | F3LE01-5T |
| Series | YOKOGAWA FA-M3 |
| Module Type | Ethernet Interface Module |
| Communication Standard | IEEE 802.3u (100BASE-TX) |
| Transmission Speed | 10/100 Mbps (Auto-negotiation) |
| Connector | RJ-45 (8-pin modular) |
| Supported Protocols | FINS, Modbus TCP, FTP, HTTP |
| Max. Connections | 16 simultaneous TCP connections |
| IP Address Setting | Rotary switch / Software configurable |
| Power Consumption | 5 VDC, 0.8 A (from backplane) |
| Operating Temperature | 0 °C to +55 °C |
| Storage Temperature | -20 °C to +70 °C |
| Humidity | 10% to 90% RH (non-condensing) |
| Weight | Approx. 214 g |
| Mounting | FA-M3 base unit slot (any slot) |
| Applicable CPU | FA-M3 series (F3SP□□ CPUs) |
Why Engineers Specify This Model
- Native FINS Protocol Support – Seamless peer-to-peer communication with other YOKOGAWA FA-M3 nodes without gateway hardware, reducing latency and BOM cost.
- Dual-Speed Auto-Negotiation – 10/100 Mbps auto-sensing eliminates manual speed configuration and ensures backward compatibility with legacy switch infrastructure.
- Multi-Protocol Flexibility – A single module handles FINS, Modbus TCP, FTP, and HTTP simultaneously, consolidating communication tasks that previously required multiple cards.
- Deterministic Performance – Dedicated Ethernet ASIC ensures consistent cycle-time performance even under heavy network load, critical for closed-loop control applications.
- Compact FA-M3 Form Factor – Occupies one standard FA-M3 slot; no external power supply or DIN-rail adapter required.
- Long Product Lifecycle – YOKOGAWA’s FA-M3 platform is supported with long-term spare parts availability, reducing obsolescence risk for 10–20 year plant lifecycles.
Complete System Bill of Materials
A typical FA-M3 Ethernet node using the F3LE01-5T includes the following components:
- F3LE01-5T – Ethernet Interface Module (this item)
- F3SP71-4N / F3SP76-7N – FA-M3 CPU Module
- F3BU04-0N / F3BU16-0N – FA-M3 Base Unit (4-slot or 16-slot)
- F3PU20-0S – Power Supply Module (100–240 VAC input)
- F3XD32-3H – 32-point DC Input Module (application-dependent)
- F3YD32-3T – 32-point Transistor Output Module (application-dependent)
- CAT5e / CAT6 shielded Ethernet cable + managed industrial switch
Contact Konmask.com for complete system configuration and compatibility verification.
Compliance & Industry Standards
- IEEE 802.3 / 802.3u Ethernet Standard
- CE Marking – EMC Directive 2014/30/EU
- UL Listed – UL 508 (Industrial Control Equipment)
- RoHS Compliant – Directive 2011/65/EU
- IEC 61131-2 – Programmable Controllers Hardware Requirements
- SEMI E30 / E37 compatible communication architecture (semiconductor applications)
Quality Assurance & Sourcing
All YOKOGAWA modules supplied by Konmask.com are sourced through verified industrial distribution channels. Each unit undergoes the following quality checks before shipment:
- Visual inspection for physical damage, label integrity, and connector condition
- Firmware version verification against YOKOGAWA’s published release matrix
- Functional power-on test with FA-M3 base unit
- Anti-static packaging with humidity indicator card
- Certificate of conformance available upon request
We do not supply counterfeit, refurbished-as-new, or grey-market components. Traceability documentation is available for OEM and EPC customers.
How to Source This Part
- In-Stock Orders: Add to cart and check out directly. Most orders ship within 1–3 business days from our warehouse.
- Bulk / Project Quotes: Email [email protected] with your BOM and required delivery date for a project price.
- Urgent Requirements: Call or WhatsApp +0086 19859288691 for same-day quotation on critical spares.
- Lead Time for Out-of-Stock: Typical factory lead time is 4–8 weeks; expedited sourcing available through our supplier network.
- Export & Customs: We handle export documentation (CO, packing list, commercial invoice) for international shipments to Asia, Europe, and the Middle East.
Application-Specific FAQ
Q: Can the F3LE01-5T communicate with non-YOKOGAWA PLCs?
A: Yes. Via Modbus TCP, the F3LE01-5T can exchange data with any Modbus-compliant device including Siemens, Allen-Bradley, Mitsubishi, and Omron PLCs, as well as third-party SCADA/HMI systems.
Q: How many F3LE01-5T modules can be installed in one FA-M3 base unit?
A: Multiple modules can be installed subject to the base unit’s slot count and power budget. Consult YOKOGAWA’s FA-M3 system configuration guide (IM 34M06H11-01E) for slot assignment rules.
Q: Is the F3LE01-5T compatible with EtherNet/IP?
A: No. The F3LE01-5T supports FINS and Modbus TCP natively. EtherNet/IP requires the F3LE11-1T or F3LE12-1T variant. Contact us to confirm the correct module for your network architecture.
Q: What software is used to configure the F3LE01-5T?
A: Configuration is performed using YOKOGAWA’s WideField3 programming software (IM 34M06Q16-01E). IP address can also be set via the onboard rotary switches without software.
Q: Can this module be used in a redundant Ethernet ring topology?
A: The F3LE01-5T supports standard star and bus topologies. For ring redundancy (MRP/RSTP), YOKOGAWA’s F3LE34-1T module is recommended.
