YOKOGAWA PW302-S4 Power Supply Module | Replacement, Equivalent & Selection Guide
The YOKOGAWA PW302-S4 is a dedicated DC power supply module designed for use within the YOKOGAWA CENTUM VP / CS 3000 distributed control system (DCS) platform. It provides stable, regulated power to field control stations (FCS) and I/O modules, ensuring continuous and reliable process automation operation. This page serves as a comprehensive selection, replacement, and compatibility reference for engineers and procurement teams.
Technical Specifications
- Model: PW302-S4
- Manufacturer: YOKOGAWA Electric Corporation
- Series: CENTUM VP / CS 3000 Power Supply Series
- Module Type: DC Power Supply Module
- Input Voltage: 100–240 V AC, 50/60 Hz (universal input)
- Output Voltage: 24 V DC (regulated)
- Output Current: Refer to YOKOGAWA datasheet for rated current
- Redundancy: Supports 1+1 redundant power supply configuration
- Mounting: DIN rail / FCS nest mount
- Weight: Approx. 1,980 g
- Operating Temperature: 0–55 °C
- Protection: Overcurrent, overvoltage, short-circuit protection
- Certifications: CE, UL (refer to official YOKOGAWA documentation)
Compatible Replacement & Equivalent Models
The following models are commonly evaluated as replacements or equivalents for the PW302-S4. Always verify electrical and mechanical compatibility before substitution:
- YOKOGAWA PW301-S4 — Earlier generation power supply; verify output rating compatibility
- YOKOGAWA PW302-S3 — Predecessor variant; check nest/slot compatibility
- YOKOGAWA PW481-S4 — 48 V DC output variant; not a direct drop-in replacement
- YOKOGAWA PW302-S4-R — Redundant-pair version; functionally equivalent in single-unit use
- Third-party DCS PSU modules — Must match 24 V DC output, connector pinout, and FCS nest form factor; consult Konmask engineering support for validation
Note: Konmask.com recommends using genuine YOKOGAWA OEM parts for safety-critical DCS applications. Third-party alternatives should be validated by a qualified automation engineer.
Why Choose the Original PW302-S4
- ✅ OEM-guaranteed compatibility with CENTUM VP and CS 3000 FCS nests
- ✅ Redundancy-ready — pairs seamlessly with a second PW302-S4 for 1+1 redundant power
- ✅ Proven field reliability in petrochemical, power generation, and pharmaceutical DCS environments
- ✅ Full YOKOGAWA firmware and diagnostic support via CENTUM VP engineering tools
- ✅ Traceable quality — sourced from authorized channels with full documentation
Typical Applications
- YOKOGAWA CENTUM VP Field Control Station (FCS) power supply
- YOKOGAWA CS 3000 DCS cabinet power distribution
- Redundant power supply configurations in process automation
- Oil & gas, refinery, and petrochemical plant DCS systems
- Power generation and utilities control systems
- Pharmaceutical and food & beverage process control
System Compatibility
- YOKOGAWA CENTUM VP (all revisions)
- YOKOGAWA CS 3000 (R3.x and later)
- FCS Nest Types: AFV10D, AFV20D, AFV30D series (verify slot assignment)
- Redundancy Pair: Compatible with a second PW302-S4 unit in the same nest
For system-specific compatibility confirmation, contact support@konmask.com with your FCS model and revision.
Selection Guide
Use the following criteria to confirm the PW302-S4 is the correct module for your application:
- Step 1 — Confirm DCS platform: CENTUM VP or CS 3000 required
- Step 2 — Verify output voltage: System must require 24 V DC regulated supply
- Step 3 — Check nest slot: Confirm PSU slot designation in your FCS nest layout drawing
- Step 4 — Redundancy requirement: If 1+1 redundancy is needed, order two (2) units
- Step 5 — Input voltage: Confirm site AC supply is 100–240 V AC, 50/60 Hz
- Step 6 — Certifications: Verify CE/UL requirements for your region and industry
Not sure? Send your FCS model number and system revision to support@konmask.com for a free selection review.
Quality Assurance & Sourcing
- All PW302-S4 units at Konmask.com are sourced from authorized distributors or verified surplus channels
- Each unit undergoes visual inspection and functional verification prior to shipment
- Original YOKOGAWA part numbers, labels, and documentation are preserved
- Traceability records available upon request for regulated industries
- Warranty: 90-day replacement warranty on all stocked units
How to Order
- Online: Add to cart directly on this page at Konmask.com
- Email RFQ: support@konmask.com — include quantity, required delivery date, and destination country
- Phone/WhatsApp: +0086 19859288691
- Lead Time: In-stock units ship within 1–3 business days; ex-stock lead time varies
- Shipping: Worldwide DHL / FedEx / UPS express available; export documentation provided
- Payment: T/T bank transfer, PayPal, credit card accepted
Replacement & Compatibility FAQ
Q: Can the PW302-S4 replace a PW301-S4 directly?
A: In most CENTUM VP systems, yes — but verify the nest slot assignment and output current rating match your load requirements before substitution.
Q: Is the PW302-S4 compatible with CS 3000?
A: Yes. The PW302-S4 is designed for both CENTUM VP and CS 3000 FCS nests. Confirm your nest model with YOKOGAWA documentation.
Q: Can I use two PW302-S4 units for redundancy?
A: Yes. The PW302-S4 supports 1+1 redundant configuration when two units are installed in the designated PSU slots of the FCS nest.
Q: Do you supply new or refurbished units?
A: Konmask.com supplies both new OEM stock and professionally tested surplus units. Condition is clearly stated on each listing. Contact us if you require new-only supply.
Q: Can you provide a certificate of conformance (CoC)?
A: Yes. CoC and inspection reports are available upon request for regulated industries.
