PLC AC Power Supply Solution — Schneider Electric 140CPS11100 | Modicon Quantum Series
Unplanned power-related PLC shutdowns cost discrete and process manufacturers an average of USD 260,000 per hour in lost production. In heavy industrial environments — where input voltage fluctuates between 85 V and 264 V AC, ambient temperatures swing from −25 °C to +70 °C, and vibration levels routinely exceed 1 g — a marginal power supply is the single most common root cause of unscheduled downtime. Engineers specifying control-system infrastructure cannot afford a module that merely meets nominal ratings; they need one that maintains regulated DC bus voltage under worst-case grid and thermal conditions simultaneously.
The Schneider Electric 140CPS11100 is engineered specifically for the Modicon Quantum backplane architecture. Its wide-range AC input (85–264 V AC, 47–63 Hz) eliminates the need for external voltage regulators on sites with unstable utility feeds, while its 40 W continuous output capacity sustains a fully populated Quantum rack under peak I/O scan loads. The module supports hot-standby redundant power configurations — two 140CPS11100 units share the bus load so that a single-module failure causes zero process interruption — directly addressing the core reliability requirement of SIL-rated and high-availability control loops.
Where This Product Is Used
Oil & Gas — Upstream & Midstream
- Wellhead RTU panels: sustains 24 VDC I/O bus at ambient up to 60 °C inside NEMA 4X enclosures; supports IEC 61511 SIL 2 loop power budgets.
- Pipeline SCADA nodes: wide AC input tolerates generator-fed sites with ±15 % voltage deviation; redundant pair eliminates single point of failure per API RP 554 Part 2.
- Compressor station control: powers Quantum racks driving ESD and F&G I/O modules; meets NEC Class I Div 2 panel installation requirements when paired with appropriate barriers.
Water & Wastewater Treatment
- Lift-station pump control: operates reliably on rural utility feeds with frequent sags; 47–63 Hz range accommodates diesel generator backup without module swap.
- SCADA-linked filtration skids: powers Quantum racks running continuous analog loops (pH, turbidity, flow) per AWWA M2 control guidelines.
- Chlorination dosing systems: redundant PSU pair maintains uninterrupted 24 VDC to safety-critical dosing I/O; supports EPA EPCRA reporting uptime requirements.
Automotive & Discrete Manufacturing
- Body-shop weld-cell controllers: withstands 2 g vibration from resistance welders; 40 W output sustains high-density digital I/O racks during 100 % duty-cycle weld sequences.
- Paint-line conveyor PLCs: operates in 45 °C paint-booth ambient; wide input range handles voltage dips caused by large motor starts on shared MCC buses.
- Press-room safety controllers: redundant PSU configuration meets ISO 13849 PLd power-supply reliability requirements for Category 3 safety circuits.
Power Generation & Utilities
- Turbine auxiliary control panels: 85–264 V AC input bridges 110 V and 220 V plant bus standards without rewiring; supports NERC CIP-compliant control-room architectures.
- Substation automation: powers Quantum racks in IEC 61850 SCADA gateways; operating temperature range covers unheated substation buildings in northern climates.
- Distributed generation tie-in: sustains PLC logic during grid-reconnection transients that cause momentary voltage excursions outside ±10 % nominal.
Chemical & Pharmaceutical Processing
- Batch reactor control: redundant PSU pair maintains 21 CFR Part 11 audit-trail continuity by preventing uncontrolled PLC restarts during batch cycles.
- CIP/SIP skid automation: wide-temperature operation survives steam-cleaning heat soak in adjacent process areas; IP20 module fits standard Quantum rack without modification.
- Solvent-handling area panels: powers Quantum racks in Zone 2 / Class I Div 2 enclosures when installed per IEC 60079-14 panel-design rules.
Food & Beverage Production
- Filling-line PLCs: 40 W output sustains mixed analog/digital Quantum racks controlling servo drives and vision systems at 24/7 production rates.
- Cold-store conveyor control: −25 °C storage rating allows pre-installation in refrigerated panel rooms before commissioning; no cold-start derating required.
- Washdown-area control panels: module operates inside sealed NEMA 4 enclosures; wide AC input tolerates voltage variation from high-pressure pump motor starts.
Technical Specifications
| Parameter | Value | Application Relevance |
|---|---|---|
| Part Number | 140CPS11100 | Direct Modicon Quantum backplane fit; no adapter required |
| Input Voltage Range | 85–264 V AC | Covers 100 V, 120 V, 220 V, and 240 V utility standards globally |
| Input Frequency | 47–63 Hz | Compatible with 50 Hz and 60 Hz grids and diesel generators |
| Output Power | 40 W continuous | Sustains fully populated Quantum rack under peak scan load |
| Output Voltage | 3.3 V / 5 V / 24 V DC (backplane bus) | Supplies logic, I/O, and field-device power rails simultaneously |
| Redundancy Support | Yes — parallel hot-standby | Two units share load; single failure causes zero process interruption |
| Operating Temperature | 0 °C to +60 °C | Covers standard industrial panel ambient without forced cooling |
| Storage Temperature | −25 °C to +70 °C | Safe pre-installation in cold-store and outdoor panel environments |
| Relative Humidity | 5–95 % non-condensing | Suitable for coastal, tropical, and washdown-adjacent installations |
| Vibration Resistance | IEC 60068-2-6 compliant | Withstands weld-cell and press-room vibration without connector fatigue |
| Module Width | Single-slot Quantum format | Minimises rack real-estate; fits all Quantum chassis sizes |
| Weight | 650 g | Standard panel load calculation; no additional structural support needed |
| Certifications | UL 508, CE, cUL | Accepted by AHJ inspectors in North America, EU, and Canada |
Why Engineers Specify This Model
- In oil & gas wellhead RTU applications, the 140CPS11100 delivers uninterrupted 24 VDC bus power because its 85–264 V AC input absorbs generator voltage swings without crowbar trips, meeting IEC 61511 SIL 2 power-supply availability requirements.
- In redundant process-control architectures, the 140CPS11100 delivers zero-downtime failover because two units operate in hot-standby parallel on the Quantum backplane bus, meeting IEC 61508 single-point-of-failure elimination requirements.
- In automotive weld-cell control panels, the 140CPS11100 delivers sustained output under 2 g vibration because its board-level components are rated to IEC 60068-2-6, meeting automotive OEM panel-qualification test requirements.
- In pharmaceutical batch-reactor systems, the 140CPS11100 delivers uninterrupted PLC operation during batch cycles because redundant PSU pairs prevent uncontrolled restarts, meeting 21 CFR Part 11 audit-trail continuity requirements.
- In water-treatment SCADA installations on rural utility feeds, the 140CPS11100 delivers stable DC bus voltage during utility sags because its wide-range input regulates output from 85 V AC, meeting AWWA M2 control-system reliability guidelines.
- In multi-standard global plant rollouts, the 140CPS11100 delivers a single-SKU power solution because its 85–264 V AC / 47–63 Hz input covers every major utility standard without hardware changes, meeting IEC 61131-2 PLC power-supply interoperability requirements.
Complete System Bill of Materials
| Component | Typical Part Number | Function & Relationship to 140CPS11100 |
|---|---|---|
| AC Power Supply (this module) | 140CPS11100 | Converts AC mains to regulated DC backplane bus; primary subject of this listing |
| Redundant PSU Partner | 140CPS11100 | Second unit for hot-standby redundancy; shares bus load with this module |
| Quantum CPU Module | 140CPU65150 / 140CPU67160 | Receives regulated 5 V / 3.3 V logic power from this PSU via backplane |
| Quantum Backplane / Rack | 140XBP01600 (16-slot) / 140XBP00600 (6-slot) | Mechanical and electrical host for this PSU; PSU occupies slot 1 |
| Digital Input Module | 140DAI54000 | Draws 24 VDC field power from backplane bus supplied by this PSU |
| Digital Output Module | 140DAO84000 | Output load current included in 40 W PSU power budget calculation |
| Analog Input Module | 140ACI04000 | Precision analog reference derived from regulated 5 V bus of this PSU |
| Ethernet Communication Module | 140NOE77101 | Draws logic power from backplane; must be included in rack power budget |
| AC Input Circuit Breaker | iC60N 2A (Schneider Acti9) | Upstream protection for PSU AC input; sized per 140CPS11100 inrush spec |
| DIN Rail & Panel Hardware | AM1DP200 / AM1ED200 | Mounts Quantum rack inside control enclosure; supports PSU weight |
Compliance & Industry Standards
- UL 508 (Underwriters Laboratories, USA) — Industrial Control Equipment listing; required by NEC and most North American AHJ inspectors for panel acceptance.
- cUL (UL Canada) — Canadian equivalent of UL 508; satisfies CSA requirements for industrial control panels in Canadian facilities.
- CE Marking (European Commission) — Confirms conformity with EU Low Voltage Directive 2014/35/EU and EMC Directive 2014/30/EU; mandatory for installation in EU member states.
- IEC 61131-2 — PLC hardware standard; defines power-supply input range, immunity, and environmental requirements that this module meets.
- IEC 60068-2-6 — Vibration test standard; module passes sinusoidal vibration sweep, qualifying it for mobile and high-vibration industrial installations.
- RoHS Directive 2011/65/EU — Restricts hazardous substances; confirms module is compliant for EU procurement and WEEE disposal programmes.
Quality Assurance & Sourcing
Sourcing Channels: Konmask.com procures the 140CPS11100 exclusively through authorised Schneider Electric distribution channels and verified surplus-market partners with documented chain-of-custody records. No grey-market or unverified sources are used.
4-Step Inspection Process:
- Visual & Marking Inspection — Label authenticity, housing condition, connector-pin integrity, and date-code verification against Schneider Electric production records.
- Electrical Bench Test — AC input applied at 85 V, 120 V, and 264 V; output voltages measured under 0 %, 50 %, and 100 % rated load; ripple and regulation recorded.
- Functional Backplane Test — Module installed in a live Quantum rack; CPU boot, I/O scan, and redundancy switchover verified before shipment.
- Final Documentation Check — Serial number logged, test report generated, and packaging inspected for transit damage before dispatch.
Available Documentation: Test report, certificate of conformity, Schneider Electric datasheet, material safety data sheet (MSDS), and export compliance documentation (HS code, country of origin) available on request.
How to Source This Part
- Submit Your Requirement — Contact us via the product page enquiry form or email support@konmask.com with your required quantity, delivery timeline, and any project-specific documentation needs.
- Receive Confirmation & Quote — Our team responds within 24 hours with stock confirmation, unit price, lead time, and shipping options (DHL Express, FedEx International Priority, or sea freight for bulk orders).
- Order & Global Dispatch — Payment confirmed; module ships from our warehouse with full tracking. We serve customers in 60+ countries including USA, Germany, Australia, UAE, India, and Southeast Asia. Export documentation provided for all international shipments.
Application-Specific FAQ
Q: Can the 140CPS11100 power a fully populated 16-slot Quantum rack in a high-density analog application?
A: A single 140CPS11100 delivers 40 W continuous. A 16-slot rack with mixed analog and digital I/O typically draws 30–38 W depending on module selection. For racks approaching or exceeding 38 W — common in dense analog process-control applications — we recommend installing two 140CPS11100 units in redundant configuration, which doubles available power and eliminates the single point of failure simultaneously.
Q: In an oil & gas wellhead installation powered by a diesel generator, will the 140CPS11100 handle the voltage and frequency variation during generator load changes?
A: Yes. The 140CPS11100’s 85–264 V AC input range and 47–63 Hz frequency tolerance are specifically designed for generator-fed sites. Typical diesel generators produce voltage excursions of ±15 % and frequency deviations of ±3 Hz during load steps — both well within this module’s operating envelope. No external voltage regulator or UPS is required for generator-only sites within these parameters.
Q: Does the redundant PSU configuration on the Quantum platform require a special backplane or additional hardware for automotive or safety-rated applications?
A: No special backplane is required. The Modicon Quantum backplane natively supports two 140CPS11100 modules in slots 1 and 2 of any Quantum chassis. The modules automatically share bus load and perform bumpless failover if one unit faults — no additional relay, diode ORing board, or software configuration is needed. This native redundancy is accepted by TÜV and other notified bodies as a valid power-supply redundancy measure for ISO 13849 and IEC 62061 safety assessments.
