Allen-Bradley 1336F-B025-AA-EN Adjustable Frequency AC Drive | Replacement, Equivalent & Selection Guide
The Allen-Bradley 1336F-B025-AA-EN is a 2.5 HP (1.8 kW) adjustable frequency AC drive from Rockwell Automation’s 1336 FORCE series, designed for precise speed and torque control of three-phase induction motors in industrial automation systems. It operates on a 200–240 V AC input and delivers reliable, field-proven performance across a wide range of manufacturing and process control applications.
Selection Background: Why Replacement & Equivalent Models Matter
Procurement engineers and maintenance teams frequently search for replacement and equivalent models when the original unit is discontinued, long lead-time, or cost-prohibitive. Understanding which drives are true drop-in replacements versus functional equivalents—and which cross-brand substitutes require parameter re-mapping or mechanical adaptation—is critical to avoiding unplanned downtime. This guide consolidates that intelligence so you can make a confident sourcing decision. Whether you need an exact substitute or a compatible equivalent, Konmask’s engineering team can validate fit before shipment.
Technical Specifications
- Part Number: 1336F-B025-AA-EN
- Series: 1336 FORCE
- Output Power: 2.5 HP / 1.8 kW ⚑ (key replacement parameter)
- Input Voltage: 200–240 V AC, 3-Phase ⚑
- Output Voltage: 0–240 V AC, 3-Phase
- Output Current: 8.0 A ⚑ (key replacement parameter)
- Input Frequency: 47–63 Hz
- Output Frequency Range: 0–400 Hz
- Control Method: Sensorless Vector / V/Hz
- Communication: EN (EtherNet/IP) ⚑ (must match in replacement)
- Enclosure: IP20 / Open Type
- Ambient Temperature: 0–50 °C (operating)
- Weight: 5.9 kg
- Certifications: UL, CE, CSA
⚑ Parameters marked are the most critical when evaluating any replacement or equivalent model.
Compatible Replacement & Equivalent Models
1. Direct Drop-in Replacements — Same form factor, voltage class, power rating, and EtherNet/IP interface. No parameter re-mapping required under normal conditions.
- 1336F-B025-AA-EN (new-production or refurbished) — Identical OEM unit
- 1336FORCE-B025-AA-EN — Alternative catalog notation, same hardware
2. Functional Equivalents — Same power class and communication protocol; may require minor parameter adjustment or different mounting footprint. Verify output current ≥ 8.0 A and EtherNet/IP support before substituting.
- Allen-Bradley PowerFlex 40 22B-D010N104 — 240 V, 10 A, EtherNet/IP option; compact footprint differs
- Allen-Bradley PowerFlex 525 25B-D010N104 — Modern replacement with integrated EtherNet/IP; requires Studio 5000 re-commissioning
- Allen-Bradley PowerFlex 4M 22F-D010N103 — Budget-tier equivalent; no EtherNet/IP native, add 22-COMM-E adapter
3. Cross-Brand Alternatives — Functionally equivalent drives from other manufacturers. Require full parameter re-mapping, possible I/O wiring changes, and PLC program updates. Confirm motor nameplate data and control architecture before ordering.
- Siemens SINAMICS G120 6SL3210-1PE13-2UL0 — 1.5 kW, 240 V; add CU240E-2 PN for PROFINET (not EtherNet/IP native)
- ABB ACS355-03E-08A8-2 — 1.5 kW, 200–240 V, 8.8 A; add FENA-21 for EtherNet/IP
- Yaskawa GA700 CIPR-GA70B2007ABBA — 2.2 kW, 200 V class; EtherNet/IP option card required
- Mitsubishi FR-E720-0.75K — 0.75 kW; suitable only for non-critical low-power substitution
⚠ Cross-brand substitution must be validated by a qualified engineer. Konmask can provide pre-shipment compatibility consultation at no charge.
Why Choose the Original Model
- Precision Performance: Factory-calibrated sensorless vector control delivers ±0.5% speed regulation without encoder feedback
- Certified Compliance: UL, CE, and CSA listings ensure regulatory acceptance in North American and European installations without re-certification
- Seamless EtherNet/IP Integration: Native 1336F EtherNet/IP firmware integrates directly with ControlLogix and CompactLogix PLCs—no gateway or adapter required
- Proven Compatibility: Validated against Rockwell Automation’s full 1336 FORCE ecosystem including HIM modules, dynamic braking resistors, and EMC filters
- OEM Technical Support: Full Rockwell Automation TechConnect support coverage available; firmware updates and parameter backup via DriveExplorer
- Warranty & Traceability: Konmask supplies units with full traceability documentation; 12-month warranty on all verified-original stock
Typical Applications
- Automotive Manufacturing: Conveyor belt speed control on assembly lines requiring precise synchronization
- Food & Beverage Processing: Pump and mixer drives in hygienic environments with variable flow demand
- HVAC Systems: Fan and blower speed regulation for energy-efficient building climate control
- Water & Wastewater: Booster pump control with soft-start to reduce water hammer and pipe stress
- Packaging Machinery: Servo-like positioning on form-fill-seal and labeling equipment
- Material Handling: Hoist and crane duty cycles requiring high starting torque and dynamic braking
System Compatibility
- 1336-MOD-HC2 — Human Interface Module (HIM) for local parameter programming
- 1336-BRF-SP2 — Dynamic braking resistor kit for regenerative load applications
- 1336-FCAR-SP2 — EMC line filter for CE compliance in sensitive environments
- 22-COMM-E — EtherNet/IP communication adapter (for non-EN variant cross-reference)
- ControlLogix 1756-L8x — Host PLC platform; native EtherNet/IP messaging via MSG instruction
- CompactLogix 5380 — Compact PLC host; same EtherNet/IP integration path
- 1321-3R Series — Line reactors for input harmonic mitigation and drive protection
Selection Guide
Answer these three questions to confirm the 1336F-B025-AA-EN—or its equivalent—is the right fit for your application:
- Power & Current Match: Is your motor rated ≤ 1.8 kW / 2.5 HP with a full-load current ≤ 8.0 A at 200–240 V? If yes, this drive is correctly sized. If your motor exceeds these values, contact Konmask for a higher-power equivalent.
- Communication Protocol: Does your control system use EtherNet/IP (Allen-Bradley ControlLogix / CompactLogix)? The -EN suffix confirms native EtherNet/IP. If your system uses DeviceNet or PROFIBUS, a different suffix variant or adapter is required.
- Replacement vs. Upgrade: Are you replacing a failed unit in an existing 1336 FORCE installation, or upgrading to a newer platform? For direct replacement, the original part number is safest. For platform upgrades, Konmask recommends the PowerFlex 525 migration path with full commissioning support.
📩 Not sure? Email our engineers or call +0086 19859288691 — we respond within 24 hours.
Quality Assurance & Sourcing
Konmask sources the 1336F-B025-AA-EN exclusively through authorized distribution channels and verified surplus inventory with full chain-of-custody documentation.
4-Step Inspection Process:
- Visual Inspection: Label authenticity, housing integrity, connector condition, and date code verification
- Electrical Bench Test: Power-on test, output voltage/frequency sweep, and fault code check under no-load conditions
- Functional Load Test: Motor run test at rated current to verify torque response and thermal performance
- Documentation Review: Serial number cross-reference against Rockwell Automation’s product database
Available Documentation: Test report, certificate of conformity, packing list with serial numbers, and optional third-party inspection report on request.
How to Order
- Confirm Your Requirements: Share your motor nameplate data, control system model, and required quantity with our team via email or phone
- Receive a Quote: Konmask will confirm stock availability, lead time, and pricing within 24 hours
- Place & Ship: Orders confirmed before 14:00 CST ship same day; international DHL/FedEx express available to 180+ countries
Replacement & Compatibility FAQ
Q: Can the PowerFlex 525 directly replace the 1336F-B025-AA-EN without rewiring?
A: The PowerFlex 525 is a functional equivalent in terms of power and EtherNet/IP communication, but it has a different physical footprint and terminal layout. Rewiring of control and power terminals is required. Konmask recommends a site survey before committing to this substitute.
Q: Is the ABB ACS355 a compatible equivalent for the 1336F-B025-AA-EN in a Rockwell system?
A: The ACS355 is compatible at the motor power level (1.5–2.2 kW, 240 V), but it is not natively compatible with EtherNet/IP. An FENA-21 adapter card is required, and the PLC program must be updated to use the ABB EDS file. This is a cross-brand equivalent, not a drop-in replacement.
Q: Where can I find a verified substitute for the 1336F-B025-AA-EN if it’s discontinued?
A: Konmask maintains a curated inventory of both original and equivalent substitute drives. Contact us with your application details and we will recommend the most cost-effective replacement with the shortest lead time—typically the PowerFlex 40 or PowerFlex 525 series for modern installations.
