Genuine Allen-Bradley 1336-QOUT-SP19A Transistor Output Assembly | 1336 PLUS Series – Verified Source
The Allen-Bradley 1336-QOUT-SP19A is a critical spare part for the 1336 PLUS and 1336 PLUS II AC Variable Frequency Drive series — one of Rockwell Automation’s most widely deployed industrial drive platforms across manufacturing, oil & gas, water treatment, and heavy process industries. As production lines age and OEM support windows narrow, sourcing a genuine, functional transistor output assembly becomes increasingly difficult. The market is flooded with counterfeit boards, refurbished-as-new units, and misrepresented substitutes that can cause catastrophic drive failures, unplanned downtime, and safety hazards.
At Konmask, we specialize exclusively in genuine, verified industrial automation components. Every 1336-QOUT-SP19A we supply is sourced through traceable supply chains and subjected to our rigorous 4-step quality verification process before shipment. We do not sell grey-market, cloned, or unverified parts. Our commitment to authentic, original Allen-Bradley components means you receive a part that performs to Rockwell Automation’s published specifications — the first time, every time.
Technical Specifications
- Part Number: 1336-QOUT-SP19A
- Description: Transistor Output Assembly
- Compatible Series: Allen-Bradley 1336 PLUS / 1336 PLUS II AC Drive
- Output Type: IGBT Transistor Output Stage
- Function: Power switching assembly for three-phase AC output to motor
- Voltage Rating: Per 1336 PLUS drive frame rating (refer to drive nameplate)
- Mounting: Internal drive assembly, frame-specific
- Condition: New / Surplus New (clearly stated per order)
- Manufacturer: Rockwell Automation / Allen-Bradley
- Country of Origin: USA
- RoHS Compliance: Per Rockwell Automation product declaration
Specifications verified against Allen-Bradley / Rockwell Automation official documentation and 1336 PLUS User Manual (Publication 1336 PLUS-6.2).
Our 4-Step Quality Verification Process
- Step 1 — Visual & Physical Inspection: Each unit is inspected for physical damage, corrosion, burn marks, counterfeit labeling, and tamper evidence. Part markings are cross-referenced against Rockwell Automation’s genuine part identification database. High-resolution photos are taken and retained on file.
- Step 2 — Functional Bench Test: Where applicable, the transistor output assembly is bench-tested for switching integrity, gate drive signal response, and thermal performance. Test results are logged and available upon request as a formal Test Report.
- Step 3 — Documentation Verification: We verify and provide: Certificate of Conformance (COC), Packing List with part traceability, Country of Origin (COO) Declaration, and optionally a third-party inspection report for high-value orders.
- Step 4 — Secure Packaging & Final QC Sign-Off: Units are packaged in anti-static ESD bags, placed in foam-lined boxes with desiccant, and sealed with tamper-evident tape. A final QC sign-off sheet is included inside every shipment.
Key Features & Benefits
- Drop-in OEM Replacement: Designed and manufactured to Rockwell Automation’s exact specifications — no modifications or recalibration required upon installation.
- IGBT Switching Technology: Provides low switching losses and high efficiency output waveform, compliant with IEC 61800-2 adjustable speed electrical power drive systems standard.
- Thermal Protection Compatibility: Integrates with the 1336 PLUS drive’s onboard thermal management and fault detection circuitry for safe, monitored operation.
- Extended Drive Lifecycle: Restores full drive functionality without the capital cost of a complete drive replacement — critical for legacy system continuity per ISA-18.2 maintenance best practices.
- Traceable Supply Chain: Every unit is sourced with full traceability documentation, reducing counterfeit risk in compliance with AS6081 (Fraudulent/Counterfeit Electronic Parts) mitigation guidelines.
- Rapid Availability: In-stock and ready to ship — minimizing Mean Time to Repair (MTTR) for critical production assets.
Typical Applications
- Automotive Manufacturing: Conveyor drive systems and robotic cell motor control using 1336 PLUS drives requiring output stage replacement during scheduled maintenance.
- Oil & Gas: Pump and compressor VFD drives in upstream/midstream facilities where drive uptime is mission-critical and counterfeit parts pose safety risks.
- Water & Wastewater Treatment: Municipal pump station drives requiring genuine spare parts to meet utility-grade reliability and regulatory compliance standards.
- Food & Beverage Processing: Mixer, conveyor, and packaging line drives in hygienic environments where unplanned downtime directly impacts production yield.
- Mining & Minerals: Heavy-duty crusher and conveyor drive systems operating in harsh environments with high thermal and vibration stress on output assemblies.
- HVAC & Building Automation: Large commercial chiller and air handling unit drives in facilities management applications requiring long-term parts availability.
Compatible System Components
- Allen-Bradley 1336 PLUS AC Drive (all frame sizes — confirm frame compatibility before ordering)
- Allen-Bradley 1336 PLUS II AC Drive
- 1336-MOD-C2A / C3A Gate Driver Boards
- 1336-BRF-SP2A Brake IGBT Assembly
- 1336-PB-SP2A Power Base Assembly
- 1336-L4E / L6E Control Boards
- Rockwell Automation 1321-3R Line Reactors (upstream protection)
- Allen-Bradley 1336-GM-SP1A Gate Module Assembly
Global Sourcing & Shipping Capabilities
- Primary Service Regions: China Mainland, Hong Kong SAR, Southeast Asia (Singapore, Malaysia, Thailand, Vietnam), Middle East (UAE, Saudi Arabia), Europe (Germany, Netherlands, UK), North America (USA, Canada), Australia & New Zealand.
- Export Packaging Standard: Anti-static ESD bag → foam-lined inner box → double-wall corrugated outer carton with moisture barrier. Gross weight and dimensions declared on packing list for customs clearance.
- Logistics Options: DHL Express, FedEx International Priority, UPS Worldwide, sea freight (LCL/FCL) for bulk orders, and air cargo for urgent requirements.
- Lead Time: In-stock items ship within 1–3 business days of order confirmation and payment. Custom sourcing orders: 5–15 business days depending on origin.
- Export Documentation: Commercial Invoice, Packing List, COO Declaration, COC, and HS Code declaration provided as standard for all international shipments.
Certifications & Compliance Statement
- CE Marking: Allen-Bradley 1336 PLUS series is CE-marked per EU Machinery Directive 2006/42/EC and Low Voltage Directive 2014/35/EU.
- UL Listed: Rockwell Automation 1336 PLUS drives carry UL listing for industrial control equipment.
- RoHS Compliant: Per Rockwell Automation’s product environmental compliance declarations.
- ISO 9001 Supply Chain: Konmask sources from ISO 9001-certified distributors and maintains internal quality management procedures aligned with ISO 9001:2015.
- AS6081 Counterfeit Mitigation: Our sourcing and inspection procedures are aligned with AS6081 guidelines for fraudulent/counterfeit electronic parts avoidance.
Konmask Quality Commitment: We stand behind every part we sell. If a unit is found to be non-genuine or fails to meet published specifications upon receipt, we will replace it or issue a full refund — no questions asked. Our reputation is built on verified authenticity, and we will never compromise it.
How to Order
- Step 1 — Submit Your Inquiry: Contact us via the product page, email support@konmask.com, or WhatsApp/WeChat at +0086 19859288691 with your required quantity, destination, and any special documentation requirements.
- Step 2 — Receive Quotation & Confirmation: We respond within 24 hours with a formal quotation including unit price, lead time, shipping options, and available documentation (COC, Test Report, Photos, Packing List, COO Declaration).
- Step 3 — Order Confirmation & Shipment: Upon payment confirmation, your order is processed, QC-inspected, packed, and dispatched with full tracking information and export documentation.
Sample Policy: Sample units are available for qualified buyers. Test reports and inspection photos can be provided prior to order confirmation upon request. Contact us to discuss your specific requirements.
