Allen-Bradley 1606-XLS120E Power Supply | Replacement, Equivalent & Selection Guide

The Allen-Bradley 1606-XLS120E is a 120W, 24VDC slim-line DIN-rail power supply from Rockwell Automation’s 1606-XLS series, engineered for demanding industrial control applications. This page provides full technical specifications, compatible replacement models, application guidance, and a structured selection guide to help engineers and procurement teams make confident sourcing decisions.

Technical Specifications

• Part Number: 1606-XLS120E
• Brand: Allen-Bradley (Rockwell Automation)
• Series: 1606-XLS (Extra-Low-Voltage Slim-Line)
• Output Voltage: 24 VDC (adjustable 24–28 V)
• Output Current: 5 A
• Output Power: 120 W
• Input Voltage: 85–264 VAC / 90–375 VDC (universal input)
• Input Frequency: 47–63 Hz
• Efficiency: ≥ 91% (typical at full load)
• Mounting: DIN rail (EN 60715 TH35)
• Width: 45 mm (slim-line form factor)
• Operating Temperature: -25°C to +70°C
• Protection: Overload, overvoltage, short-circuit, thermal shutdown
• Certifications: UL 508, CE, cULus, ATEX Zone 2
• MTBF: > 500,000 hours
• Parallel Operation: Supported (for redundancy or increased current)

Compatible Replacement & Equivalent Models

The following models are commonly evaluated as functional replacements or equivalents for the 1606-XLS120E. Always verify electrical and mechanical compatibility before substitution.

• Allen-Bradley 1606-XLS120E-3 — Three-phase input variant; same 120W/24VDC output
• Allen-Bradley 1606-XLP120E — XLP series, 120W/24VDC, wider temperature range
• Phoenix Contact QUINT-PS/1AC/24DC/5 — 120W, 24VDC/5A, SFB technology, direct DIN-rail equivalent
• PULS QS10.241 — 120W, 24VDC, ultra-slim, high efficiency (>93%)
• Siemens SITOP PSU100S 24V/5A (6EP1332-1SH52) — 120W, 24VDC, robust industrial grade
• Murr Elektronik MCS10-1AC/24DC/5 — 120W, 24VDC, compact DIN-rail form
• Omron S8VK-C12024 — 120W, 24VDC/5A, DIN-rail, CE/UL certified

Note: Cross-reference datasheets for output ripple, hold-up time, and derating curves before final selection.

Why Choose the Original Model

• Seamless Rockwell Integration: Native compatibility with Allen-Bradley PLCs (ControlLogix, CompactLogix, MicroLogix) and Studio 5000 diagnostics
• Proven Reliability: MTBF >500,000 hours; field-validated in automotive, food & beverage, and oil & gas sectors
• ATEX Zone 2 Certification: Suitable for hazardous area installations without additional enclosures
• Parallel Redundancy: Built-in current sharing for N+1 redundant architectures
• Slim 45mm Width: Maximizes panel space in high-density control cabinets
• Global Input Range: 85–264 VAC universal input eliminates transformer requirements worldwide

Typical Applications

• PLC and DCS control panel power distribution (24VDC bus)
• Industrial automation lines: automotive assembly, packaging, conveyor systems
• Process control: oil & gas, chemical, water treatment
• Food & beverage: washdown-rated panel builds requiring reliable 24VDC
• Machine safety circuits and safety relay power supplies
• SCADA and remote I/O node power
• Hazardous area (Zone 2) control panels

System Compatibility

• Allen-Bradley PLCs: ControlLogix 1756, CompactLogix 1769, MicroLogix 1100/1400, Micro800 series
• Allen-Bradley I/O: 1734 POINT I/O, 1756 ControlLogix I/O, 1769 Compact I/O
• HMI: PanelView Plus 6/7 (24VDC models)
• Safety Systems: GuardLogix, SmartGuard 600
• Third-Party Loads: Any 24VDC industrial device within 120W total load
• Redundancy Modules: Compatible with 1606-XLSRED redundancy modules

Selection Guide

Use the following criteria to determine whether the 1606-XLS120E is the right choice, or to select an appropriate alternative:

• Required Output Power: If load <120W → 1606-XLS120E ✓ | If 120–240W → consider 1606-XLS240E or parallel pair
• Input Supply: Single-phase AC → 1606-XLS120E ✓ | Three-phase → 1606-XLS120E-3
• Temperature Range: Standard (-25 to +70°C) → XLS series ✓ | Extended → XLP series
• Hazardous Area: ATEX Zone 2 required → 1606-XLS120E ✓ | Zone 1 → consult Rockwell
• Redundancy: N+1 required → pair with 1606-XLSRED module
• Budget / Availability: OEM equivalent needed → Phoenix Contact QUINT or PULS QS10 series
• Brand Standardization: Rockwell-only site → stay with 1606-XLS family

Quality Assurance & Sourcing

• Authenticity: All units sourced through authorized distribution channels or verified surplus with full traceability
• Inspection: Visual, functional, and electrical testing performed prior to shipment
• Documentation: Certificate of conformance, test reports, and original packaging available on request
• Warranty: 12-month warranty against manufacturing defects
• Lead Time: In-stock units ship within 1–3 business days; contact us for bulk order scheduling

How to Order

1. Confirm your required part number: 1606-XLS120E (or specify replacement model)
2. Specify quantity and required delivery date
3. Contact us via email or phone for a formal quotation
4. Submit purchase order — we accept T/T, L/C, and major payment platforms
5. Receive shipping confirmation with tracking within 24 hours of order confirmation

📧 support@konmask.com | 📞 +0086 19859288691 | 🌐 https://Konmask.com

Replacement & Compatibility FAQ

Q: Can I replace the 1606-XLS120E with a Phoenix Contact QUINT-PS/1AC/24DC/5?
A: Yes, in most cases. Both are 120W / 24VDC / 5A DIN-rail units. Verify output ripple (<150mVpp) and hold-up time meet your system requirements before substitution.

Q: Is the 1606-XLS120E compatible with three-phase input?
A: No. For three-phase input, use the 1606-XLS120E-3 variant.

Q: Can two 1606-XLS120E units be paralleled for 240W output?
A: Yes, with the 1606-XLSRED redundancy module for proper current sharing and N+1 redundancy.

Q: What is the difference between the XLS and XLP series?
A: The XLP series offers an extended operating temperature range and enhanced diagnostics; the XLS series is the standard slim-line variant optimized for cost and size.

Q: Do you supply original Allen-Bradley units or compatible replacements?
A: We supply both. Please specify your preference when requesting a quotation.

---
