Allen-Bradley 1746-NIO4I High Resolution Analog Input/Output Module – SLC 500 Series
When a high-precision analog signal chain fails on the plant floor, the consequences cascade instantly: process variables drift out of tolerance, PID loops lose their reference, and operators are left flying blind. In continuous manufacturing—chemical dosing, temperature profiling, pressure regulation—even a brief loss of analog fidelity can trigger costly shutdowns, product waste, or safety incidents. The Allen-Bradley 1746-NIO4I exists precisely to prevent that scenario, delivering rock-solid, high-resolution analog I/O that keeps your SLC 500 control system in command of every critical process variable.
Within the SLC 500 family, the 1746-NIO4I occupies a specialized niche: it combines four isolated analog inputs with four analog outputs on a single module, eliminating the need for separate NI and NO cards and conserving precious rack slots. Globally, the SLC 500 platform remains one of the most widely deployed mid-range PLC architectures in process and discrete manufacturing, and the NIO4I is the go-to choice for applications demanding simultaneous, high-accuracy measurement and control on a compact footprint.
Technical Specifications
- Part Number: 1746-NIO4I
- Series: Allen-Bradley SLC 500
- Analog Inputs: 4 channels (individually isolated)
- Analog Outputs: 4 channels
- Input Signal Ranges: ±10 VDC, 0–10 VDC, 0–5 VDC, 1–5 VDC, 0–20 mA, 4–20 mA
- Output Signal Ranges: ±10 VDC, 0–10 VDC, 0–20 mA, 4–20 mA
- Resolution: 16-bit (input & output)
- Accuracy: ±0.1% of full scale (typical)
- Input Isolation: Channel-to-channel isolated
- Backplane Current Draw: 250 mA @ 5 VDC; 75 mA @ 24 VDC
- Operating Temperature: 0 °C to 60 °C (32 °F to 140 °F)
- Storage Temperature: -40 °C to 85 °C
- Relative Humidity: 5–95% non-condensing
- Enclosure Rating: Open (must be installed in suitable enclosure)
- Agency Certifications: UL, CSA, CE
- Weight: Approx. 300 g
Note: Specifications are based on published Rockwell Automation documentation. Always verify against the official product manual for your specific revision.
Key Features & Benefits
- 16-Bit High Resolution – Captures fine process variations that lower-resolution modules miss, enabling tighter control loops and superior product quality.
- Combined I/O on One Module – Four inputs plus four outputs in a single slot reduces rack space consumption and simplifies wiring compared to using separate NI and NO modules.
- Channel-to-Channel Isolation – Prevents ground loops and cross-channel interference, critical in electrically noisy industrial environments such as motor drives and welding cells.
- Flexible Signal Ranges – Supports both voltage and current modes on inputs and outputs, accommodating a wide variety of field transmitters and actuators without additional signal conditioning.
- Seamless SLC 500 Integration – Plug-and-play compatibility with all SLC 500 fixed and modular chassis; configured via RSLogix 500 / Studio 5000 Logix Designer.
- Proven Industrial Reliability – Designed to Rockwell Automation’s stringent quality standards for continuous 24/7 operation in demanding process environments.
Industry & Equipment Applications
- Chemical & Petrochemical: Flow, pressure, and temperature loop control with 4–20 mA transmitters and control valves.
- Food & Beverage: Precise dosing, mixing ratio control, and pasteurization temperature profiling.
- Water & Wastewater Treatment: pH, dissolved oxygen, and flow measurement with simultaneous pump speed control.
- Automotive Manufacturing: Weld current monitoring, press force feedback, and conveyor tension control.
- HVAC & Building Automation: Chiller staging, VAV damper positioning, and energy metering.
- Oil & Gas: Wellhead pressure monitoring and valve positioner control in remote RTU panels.
- Pharmaceutical: Bioreactor parameter control requiring high-accuracy, isolated analog channels.
System Integration & Compatible Parts
The 1746-NIO4I is designed for use within the Allen-Bradley SLC 500 modular system. Compatible and commonly paired components include:
- SLC 500 Processors: 1747-L511, 1747-L514, 1747-L524, 1747-L531, 1747-L532, 1747-L541, 1747-L542, 1747-L543, 1747-L551, 1747-L552, 1747-L553
- SLC 500 Chassis: 1746-A4, 1746-A7, 1746-A10, 1746-A13
- Power Supplies: 1746-P1, 1746-P2, 1746-P3, 1746-P4, 1746-P7
- Related Analog Modules: 1746-NI4, 1746-NI8, 1746-NO4I, 1746-NO4V, 1746-NIO4V
- Communication Modules: 1747-SDN (DeviceNet), 1747-KE (DH-485), 1747-AENTR (EtherNet/IP)
Contact Konmask.com to verify compatibility with your specific system revision and firmware version.
Our Quality Assurance Process
Every Allen-Bradley 1746-NIO4I sourced through Konmask.com undergoes a rigorous multi-stage verification process before shipment:
- Authenticity Verification: Visual inspection of labeling, date codes, and physical markings against genuine Rockwell Automation standards.
- Functional Testing: Where applicable, modules are bench-tested to confirm analog channel response and communication integrity.
- Condition Grading: Units are clearly graded as New, Refurbished, or Used-Tested, with full disclosure of condition prior to purchase.
- Secure Packaging: Anti-static packaging with moisture barrier and shock-absorbing materials to protect sensitive electronics during international transit.
- Documentation: Shipment includes relevant test records and, where available, original Rockwell Automation documentation.
How to Order
- Submit an inquiry via the Contact / RFQ form on this page with your required quantity and delivery timeline.
- Our technical team will confirm availability, condition grade, and lead time within 1 business day.
- Receive a formal quotation with pricing, shipping options, and payment terms.
- Confirm your order and complete payment via bank transfer (T/T), PayPal, or other agreed method.
- Module is tested, packaged, and dispatched with full tracking information.
For urgent requirements or large-quantity orders, please contact us directly at support@konmask.com or +0086 19859288691.
Why Choose Konmask.com?
- Industrial Automation Specialists: We focus exclusively on PLC, DCS, and automation hardware—our team speaks your engineering language.
- Global Sourcing Network: Access to both new and hard-to-find legacy parts, including discontinued Rockwell Automation modules.
- Fast Response: RFQ responses within 24 hours; expedited shipping available for critical downtime situations.
- Transparent Grading: No surprises—every unit’s condition is clearly disclosed before you commit.
- Export Expertise: Experienced in international shipping documentation, customs compliance, and multi-currency transactions.
- After-Sales Support: Technical assistance available post-delivery to support installation and commissioning.
Frequently Asked Questions
Q: Is the 1746-NIO4I still in production by Rockwell Automation?
A: The SLC 500 product line has reached end-of-life status with Rockwell Automation. However, Konmask.com maintains stock of new-surplus and refurbished units to support ongoing maintenance and system longevity.
Q: What is the difference between 1746-NIO4I and 1746-NIO4V?
A: The NIO4I is optimized for current-mode signals (4–20 mA) on its inputs, while the NIO4V is optimized for voltage-mode signals. Both support multiple ranges, but the NIO4I provides better noise immunity for long-distance 4–20 mA loops common in process industries.
Q: Can I use this module with a MicroLogix or ControlLogix system?
A: No. The 1746-NIO4I is exclusively compatible with the SLC 500 modular chassis (1746-Axx series). It is not compatible with MicroLogix, ControlLogix, or CompactLogix platforms.
Q: What software is required to configure the 1746-NIO4I?
A: Configuration is performed using Allen-Bradley RSLogix 500 software. The module is addressed as an I/O module in the SLC 500 rack and configured via the I/O configuration table in your ladder logic project.
Q: Do you provide a warranty on this module?
A: Yes. Warranty terms vary by unit condition (New, Refurbished, Used-Tested). Please request warranty details when submitting your RFQ.
Q: Can you ship internationally?
A: Yes. Konmask.com ships worldwide. We handle export documentation and can advise on import requirements for your destination country.
