Allen-Bradley 1768-EWEB CompactLogix Enhanced Web Server Module | Replacement, Equivalent & Selection Guide
The Allen-Bradley 1768-EWEB is a dedicated Enhanced Web Server Module designed for the CompactLogix 1768 control platform. It provides embedded web-based monitoring, tag browsing, and remote diagnostics for CompactLogix L4x controllers without requiring additional software licenses. As a bridge between the controller backplane and Ethernet/IP infrastructure, the 1768-EWEB is a critical component in distributed industrial automation architectures.
Selection Background: Why Replacement & Equivalent Models Matter
Industrial buyers frequently search for 1768-EWEB replacement or 1768-EWEB equivalent options due to end-of-life announcements, long lead times, budget constraints, or the need for cross-brand compatibility in multi-vendor environments. Understanding which modules are direct drop-in replacements versus functional equivalents — and the conditions under which substitution is safe — is essential for maintaining system uptime and compliance. This guide is designed to help engineers and procurement teams make informed substitution decisions.
Technical Specifications
| Part Number | 1768-EWEB |
| Brand | Allen-Bradley / Rockwell Automation |
| Platform | CompactLogix 1768 Series |
| Module Type | Enhanced Web Server / EtherNet/IP Communication |
| Network Interface | 10/100 Mbps EtherNet/IP (RJ-45) |
| Web Server | Embedded HTTP/HTTPS, tag-based data access |
| Backplane Compatibility | 1768 CompactLogix backplane only ⚠️ (key substitution constraint) |
| Controller Compatibility | 1768-L4x series (L43, L45, L45S) |
| Power Consumption | ~1.0 A @ 5 VDC (backplane) |
| Operating Temperature | 0 – 60 °C |
| Certifications | UL, CE, cUL ⚠️ (verify equivalents carry same certs) |
| Firmware | Upgradeable via ControlFlash |
| Weight | ~350 g |
| Catalog Status | Active (verify current lifecycle with Rockwell) |
Compatible Replacement & Equivalent Models
① Direct Drop-in Replacements
Modules that fit the 1768 backplane slot and replicate all 1768-EWEB functions with no firmware or wiring changes required:
- 1768-EWEB/A, /B revisions — Same catalog number, different hardware revision. Fully interchangeable in most applications; verify firmware compatibility with your L4x controller revision.
- Refurbished / tested 1768-EWEB — Sourced from decommissioned systems; must pass 4-step inspection (see Quality Assurance section).
② Functional Equivalents
Modules that provide equivalent web server and EtherNet/IP functionality but may require configuration changes or are platform-specific:
- 1769-L3xE / 1769-L4xERM (built-in Ethernet) — If upgrading the controller is an option, newer CompactLogix controllers include integrated EtherNet/IP ports with web diagnostic capability, eliminating the need for a separate 1768-EWEB module.
- 1756-EWEB (ControlLogix platform) — Functional equivalent for web server features but requires a 1756 ControlLogix chassis. Not a physical drop-in for 1768 systems.
③ Cross-Brand Alternatives
Third-party or alternative-brand modules offering similar EtherNet/IP web monitoring capability. Suitable only when the original platform is being replaced or supplemented:
- Moxa MGate / EDS-G series — Industrial Ethernet gateways with web management; require protocol mapping configuration.
- HMS Anybus Communicator — Cross-protocol industrial communication modules; suitable for multi-vendor integration projects.
- ⚠️ Cross-brand alternatives are NOT drop-in substitutes. They require engineering evaluation, wiring changes, and software reconfiguration. Contact Konmask for a compatibility assessment before ordering.
Why Choose the Original 1768-EWEB
- Precision Compatibility: Engineered exclusively for the 1768 CompactLogix backplane — guaranteed slot fit, power draw, and backplane communication protocol compliance.
- Rockwell Certifications: Carries UL, CE, and cUL certifications validated for the 1768 platform; third-party alternatives may not meet the same regulatory requirements for your installation.
- Native Studio 5000 Integration: Fully supported in Logix Designer / Studio 5000 with no additional EDS files or driver configuration required.
- Firmware Ecosystem: Upgradeable via ControlFlash with Rockwell-validated firmware; maintains compatibility across controller firmware revisions.
- Technical Support: Backed by Rockwell Automation TechConnect and Konmask’s pre-sales engineering support for configuration and integration questions.
- Warranty & Traceability: Genuine modules supplied by Konmask include full traceability documentation and are eligible for manufacturer warranty claims.
Typical Applications
- Automotive Manufacturing: Remote monitoring of CompactLogix-controlled assembly line stations via plant intranet dashboards.
- Water & Wastewater Treatment: Web-based SCADA integration for distributed pump and valve control systems using 1768-L4x controllers.
- Food & Beverage Processing: Real-time tag browsing for CIP (Clean-in-Place) cycle monitoring without dedicated HMI hardware at each station.
- Oil & Gas Upstream: Remote diagnostics for wellhead automation panels in areas with limited physical access.
- Building Automation: Integration of CompactLogix controllers into BMS networks via EtherNet/IP with web-accessible status pages.
- Pharmaceutical Manufacturing: Audit-trail-compliant remote monitoring for batch process controllers in GMP environments.
System Compatibility
The 1768-EWEB is designed to operate within the following system ecosystem:
- 1768-L43 / L45 / L45S — CompactLogix L4x controllers (primary host controllers)
- 1768-PA3 / PB3 — CompactLogix power supplies (required in same chassis)
- 1768-ENBT — EtherNet/IP bridge module (alternative communication option in same platform)
- 1769-SDN — DeviceNet scanner for mixed-network architectures
- Studio 5000 Logix Designer v21+ — Programming and configuration software
- FactoryTalk View SE/ME — HMI software for integrated visualization alongside web server data
Selection Guide
Answer these three questions to confirm the 1768-EWEB — or a suitable replacement — is the right choice for your application:
-
Is your controller a 1768-L4x (L43, L45, or L45S)?
If yes, the 1768-EWEB is the correct platform-specific web server module. If you are using a 1769 or 5069 CompactLogix, a different module or integrated port applies — contact Konmask for guidance. -
Do you need web-based tag monitoring without a dedicated HMI?
If yes, the 1768-EWEB provides embedded HTTP/HTTPS tag browsing. If you already have FactoryTalk View or a SCADA system with direct EtherNet/IP access, evaluate whether the web server module adds value for your architecture. -
Are you replacing a failed module or sourcing for a new build?
For replacement: confirm the existing module’s hardware revision and controller firmware version before ordering to ensure compatibility. For new builds: consider whether a newer CompactLogix platform with integrated Ethernet ports better meets your long-term needs. Contact Konmask’s engineering team for a free pre-order compatibility check.
Quality Assurance & Sourcing
Sourcing Channels: Konmask sources 1768-EWEB modules through authorized distribution networks, factory-surplus channels, and certified refurbishment partners. All units are traceable to original manufacture.
4-Step Inspection Process:
- Visual Inspection: Check for physical damage, bent pins, corrosion, and label integrity. Reject any unit with evidence of counterfeit markings.
- Firmware Verification: Boot the module and confirm firmware version via web interface or ControlFlash. Document revision for customer records.
- Functional Test: Install in a test 1768 chassis with an L4x controller; verify EtherNet/IP communication, web server accessibility, and tag browsing functionality.
- Documentation Package: Compile test report, firmware version record, and traceability certificate prior to shipment.
Available Documentation: Test report · Firmware version certificate · Traceability record · Datasheet · Certificate of Conformance (on request)
How to Order
- Submit Your Inquiry: Email support@konmask.com or call +0086 19859288691 with your part number (1768-EWEB), required quantity, and any revision or firmware preferences.
- Receive Quote & Compatibility Confirmation: Konmask’s engineering team will confirm compatibility with your controller revision and provide a formal quotation within 24 hours.
- Order Confirmation & Shipment: Upon order confirmation, modules are inspected, documented, and dispatched with full traceability paperwork. Expedited shipping available for urgent replacement needs.
Replacement & Compatibility FAQ
Q1: Can I use a 1756-EWEB as a direct replacement for the 1768-EWEB?
No. The 1756-EWEB is designed for the ControlLogix 1756 chassis and is not physically or electrically compatible with the 1768 CompactLogix backplane. It is a functional equivalent in terms of web server capability but requires a completely different hardware platform. If you are migrating from a 1768 to a 1756 system, Konmask can assist with the transition planning.
Q2: Is the 1768-EWEB compatible with 1769 CompactLogix controllers?
No. The 1768-EWEB is exclusively compatible with the 1768 backplane (L4x controllers). The 1769 CompactLogix platform uses a different backplane architecture. For 1769-series systems, consider controllers with integrated EtherNet/IP ports or consult Konmask for an equivalent substitute recommendation.
Q3: What is the best equivalent or substitute if the 1768-EWEB is discontinued or unavailable?
The most practical path depends on your timeline and budget: (1) Source a tested refurbished 1768-EWEB — Konmask maintains stock of inspected units; (2) Evaluate upgrading to a 1768-L45ER or newer CompactLogix platform with integrated Ethernet, eliminating the need for a separate web server module; (3) For cross-brand substitution in a platform migration, Konmask’s engineering team can recommend compatible industrial Ethernet gateway solutions. Contact us for a tailored recommendation.
