Analog Voltage Output Solution – Allen-Bradley 1769-OF8V | CompactLogix MicroLogix Compact I/O
Where This Product Is Used
The Allen-Bradley 1769-OF8V is an 8-channel analog voltage output module engineered for precision process control in demanding industrial environments. It is widely deployed across the following application sectors:
- Process Manufacturing — Drives control valves, positioners, and variable-frequency drives (VFDs) in chemical, petrochemical, and pharmaceutical plants where ±10 V DC or 0–10 V DC command signals are required.
- Automotive Assembly Lines — Provides closed-loop torque and speed references to servo amplifiers and hydraulic proportional valves on body-in-white welding and stamping lines.
- Water & Wastewater Treatment — Controls pump speed references and dosing valve positions in SCADA-integrated lift stations and filtration systems.
- Food & Beverage Processing — Manages conveyor speed, mixing ratios, and temperature setpoints in hygienic production lines requiring repeatable analog references.
- Building Automation & HVAC — Outputs voltage setpoints to air-handling unit damper actuators and chiller capacity controllers integrated with CompactLogix PACs.
- Material Handling & Packaging — Coordinates multi-axis tension control and web-guiding systems requiring simultaneous independent voltage outputs.
- Oil & Gas Upstream/Midstream — Interfaces with electro-hydraulic actuators on wellhead control panels and pipeline compressor stations.
Technical Specifications
| Parameter | Specification |
|---|---|
| Catalog Number | 1769-OF8V |
| Module Type | Analog Voltage Output, Compact I/O |
| Number of Output Channels | 8 (single-ended, voltage) |
| Output Voltage Ranges | 0–10 V DC, ±10 V DC (software-selectable per channel) |
| Resolution | 16-bit DAC (1 part in 65,536) |
| Output Accuracy | ±0.1% of full scale at 25 °C |
| Load Impedance (min.) | 1 kΩ |
| Output Ripple & Noise | ≤ 10 mV peak-to-peak |
| Update Rate | All 8 channels updated each RPI (Requested Packet Interval) |
| Backplane Current Draw (5 V DC) | 75 mA |
| Backplane Current Draw (24 V DC) | 0 mA (no 24 V backplane draw) |
| Field-Side Power | Not required (output powered from backplane) |
| Operating Temperature | 0 °C to +60 °C (32 °F to 140 °F) |
| Storage Temperature | -40 °C to +85 °C |
| Relative Humidity | 5–95% non-condensing |
| Vibration | IEC 68-2-6, 2 g @ 10–500 Hz |
| Shock | IEC 68-2-27, 30 g |
| Dimensions (H × W × D) | 90 mm × 35 mm × 87 mm (3.54 × 1.38 × 3.43 in) |
| Weight | Approx. 250 g |
| Enclosure Rating | Open-type (IP20); mount in rated enclosure |
| Compatible Controllers | CompactLogix L1x–L4x, MicroLogix 1500 (with 1769 bus), SoftLogix (via 1769 adapter) |
| Compatible Bus | 1769 Compact I/O bus (left-side or right-side expansion) |
| Firmware | Configured via RSLogix 5000 / Studio 5000 Logix Designer |
Why Engineers Specify This Model
- 8 Independent Voltage Channels in One Slot — Maximizes I/O density in space-constrained control panels; replaces up to four 2-channel legacy modules.
- Per-Channel Range Selection — Engineers can mix 0–10 V and ±10 V channels within the same module to serve different field devices without additional hardware.
- 16-Bit Resolution — Delivers 65,536 discrete output steps, enabling sub-millivolt precision for servo drives and proportional valve controllers.
- Seamless Studio 5000 Integration — Module profile auto-populates in the I/O tree; channel scaling, fault states, and hold-last-state behavior are all configured in software without DIP switches.
- Configurable Fault & Program Mode Behavior — Each channel independently configured to hold last value, ramp to zero, or output a user-defined safe state on controller fault or program mode — critical for process safety.
- No External Field Power Required — Simplifies panel wiring; all output power sourced from the 1769 backplane, reducing terminal block count and potential wiring errors.
- Proven Platform Longevity — The 1769 Compact I/O platform has a multi-decade installed base with Rockwell Automation’s committed long-term support, protecting capital investment.
Complete System Bill of Materials
A typical CompactLogix analog voltage output system using the 1769-OF8V includes the following components:
| Item | Catalog Number | Description |
|---|---|---|
| Controller | 1769-L33ER | CompactLogix 5370 L3 Controller, EtherNet/IP |
| Power Supply | 1769-PA2 | Compact I/O AC Power Supply, 2 A @ 5 V DC |
| Analog Output Module | 1769-OF8V | 8-Channel Analog Voltage Output Module (this item) |
| Digital Input Module | 1769-IQ16 | 16-Channel 24 V DC Digital Input Module |
| Digital Output Module | 1769-OB16 | 16-Channel 24 V DC Digital Output Module |
| Analog Input Module | 1769-IF8 | 8-Channel Analog Input Module (current/voltage) |
| End Cap | 1769-ECR | Right-End Cap for Compact I/O Bus Termination |
| Programming Software | 9324-RLD300ENE | Studio 5000 Logix Designer, Standard Edition |
| EtherNet/IP Switch | 1783-US5T | Stratix 2000 Unmanaged Switch, 5-Port |
Compliance & Industry Standards
- UL Listed — UL 508 (Industrial Control Equipment)
- CE Marked — Compliant with EU Low Voltage Directive (LVD) and EMC Directive
- RoHS Compliant — Restriction of Hazardous Substances Directive 2011/65/EU
- ATEX / IECEx — Not rated for Zone 0/1 hazardous areas; use approved barriers for Ex installations
- IEC 61131-2 — Programmable Controller Equipment standard compliance
- ODVA EtherNet/IP — Conforms to ODVA EtherNet/IP specification when used with compatible CompactLogix controllers
- Rockwell Automation Product Certification — Certified under RA’s global product certification program; certification documents available on the Rockwell Automation Product Compatibility and Download Center (PCDC)
Quality Assurance & Sourcing
At Konmask.com, every 1769-OF8V module offered is subject to the following quality controls before shipment:
- Authenticity Verification — Physical inspection of Rockwell Automation holographic labels, date codes, and country-of-manufacture markings against known-genuine references.
- Functional Bench Test — Each module is powered on a live 1769 backplane and all 8 output channels are verified for correct voltage output across both selectable ranges.
- Firmware Revision Check — Module firmware revision is documented and disclosed; customers requiring a specific revision for compatibility with existing Studio 5000 projects may request it at order time.
- Condition Grading — Modules are graded as New Sealed (factory original), New Open Box (unused, opened for inspection), or Refurbished (tested, cleaned, re-labeled). Grade is clearly stated on each listing.
- Traceability Documentation — Purchase records and supply-chain documentation retained for a minimum of 3 years; available to customers upon request for audit purposes.
- Packaging — Shipped in anti-static ESD bags with foam cushioning inside double-wall corrugated cartons; desiccant included for international shipments.
How to Source This Part
- Confirm Compatibility — Verify your CompactLogix or MicroLogix 1500 controller firmware supports the 1769-OF8V module profile. Check the Rockwell Automation PCDC for the latest AOP (Add-On Profile).
- Determine Quantity & Condition — Review your BOM. For new capital projects, New Sealed stock is recommended. For MRO/emergency replacement, New Open Box or Refurbished grades offer faster availability.
- Request a Quote — Contact us at support@konmask.com or +0086 19859288691 for volume pricing, lead time confirmation, and freight options.
- Place Order — Orders accepted via this product page (Add to Cart), purchase order (PO) via email, or wire transfer for international B2B customers.
- Shipping & Lead Time — In-stock units ship within 1–2 business days from our warehouse. Express international shipping (DHL / FedEx) available. Estimated transit: 3–7 business days to most destinations.
- After-Sales Support — Our technical team provides post-sale support including Studio 5000 configuration guidance, wiring diagram review, and warranty claim processing.
Application-Specific FAQ
Q: Can the 1769-OF8V drive a 4–20 mA current loop device directly?
A: No. The 1769-OF8V is a voltage output module only (0–10 V or ±10 V DC). For 4–20 mA current output, specify the 1769-OF8C (current output variant) or use an external V-to-I converter.
Q: How many 1769-OF8V modules can I add to a single CompactLogix system?
A: The 1769 Compact I/O bus supports up to 30 modules per local bank (controller-dependent). Consult your controller’s user manual for the maximum I/O module count and backplane current budget.
Q: What happens to the outputs if the controller faults or goes to Program mode?
A: Each channel is independently configurable in Studio 5000 to: (1) hold the last commanded value, (2) ramp to zero, or (3) go to a user-defined safe-state value. This is set in the module’s Output Configuration tab.
Q: Is the 1769-OF8V compatible with Studio 5000 Logix Designer v32 and later?
A: Yes. The module AOP is included in Studio 5000 v16 and later. For v32+, download the latest AOP from the Rockwell Automation PCDC to ensure full feature support.
Q: Can I use this module with a MicroLogix 1500 controller?
A: Yes, provided you use the 1769-L23 or 1769-L35 series CompactLogix, or a MicroLogix 1500 with a 1769 expansion bus adapter. Verify the specific controller’s compatibility list before ordering.
Q: Do you provide a warranty on refurbished units?
A: Yes. All refurbished 1769-OF8V modules sold by Konmask.com carry a 12-month functional warranty covering defects in materials and workmanship under normal operating conditions.
Q: Can I order a single module for emergency MRO replacement?
A: Absolutely. We supply single units with no minimum order quantity (MOQ). Contact us for expedited processing if your production line is down.
