Industrial Ethernet Solution – Allen-Bradley 1783-MS10T | Stratix 8000 Series
Where This Product Is Used
The Allen-Bradley 1783-MS10T Stratix 8000 10-port managed switch is deployed across demanding industrial environments where network reliability and deterministic communication are non-negotiable:
- Automotive Assembly Lines — Backbone switching for robot controllers, vision systems, and servo drives on EtherNet/IP networks.
- Food & Beverage Processing — Hygienic-zone network segmentation between PLCs, HMIs, and SCADA servers with VLAN isolation.
- Oil & Gas Facilities — Redundant ring topologies using Device Level Ring (DLR) to eliminate single points of failure in remote pump stations.
- Water & Wastewater Treatment — Managed switching between ControlLogix/CompactLogix controllers and field instrumentation across distributed lift stations.
- Pharmaceutical Manufacturing — Validated network infrastructure supporting 21 CFR Part 11 compliant SCADA and MES connectivity.
- Material Handling & Logistics — High-speed conveyor and sortation system networks requiring low-latency I/O communication.
- Power Generation & Utilities — Substation automation networks integrating IEDs, RTUs, and DCS controllers.
Technical Specifications
| Part Number | 1783-MS10T |
| Series | Stratix 8000 |
| Manufacturer | Allen-Bradley / Rockwell Automation |
| Port Count | 10 Ports |
| Port Type | 10/100 Mbps RJ45 Copper (all ports) |
| Switch Type | Managed Layer 2 |
| Protocol Support | EtherNet/IP, DLR (Device Level Ring), IGMP Snooping, RSTP, VLAN (802.1Q) |
| Management Interface | Studio 5000 Logix Designer, RSLogix 5000, Web Browser, CLI |
| Power Supply | 24V DC (nominal), 18–32V DC range |
| Power Consumption | ≤ 12W typical |
| Operating Temperature | 0°C to +60°C (32°F to 140°F) |
| Storage Temperature | -40°C to +85°C |
| Relative Humidity | 5–95% non-condensing |
| Mounting | DIN Rail |
| Enclosure Rating | IP20 |
| Weight | 2.6 kg |
| Dimensions (H×W×D) | Refer to Rockwell Automation publication 1783-UM007 |
Why Engineers Specify This Model
- Native EtherNet/IP Integration — Appears as a standard I/O module in Studio 5000, enabling configuration, diagnostics, and port-level monitoring directly from the PLC programming environment without separate network management tools.
- Device Level Ring (DLR) Support — Provides sub-millisecond network recovery (<3 ms) in ring topologies, meeting the redundancy requirements of motion control and safety-critical applications.
- VLAN & QoS Traffic Prioritization — Segregates control traffic from HMI and IT traffic; prioritizes time-sensitive I/O data using 802.1p CoS markings.
- Compact DIN Rail Form Factor — Fits standard 35 mm DIN rail inside control panels, minimizing cabinet footprint in space-constrained installations.
- Rockwell Ecosystem Compatibility — Fully tested and validated with ControlLogix, CompactLogix, GuardLogix, and PowerFlex drive families.
- Simplified Commissioning — Auto-negotiation, auto-MDIX, and pre-configured EtherNet/IP device profile reduce setup time on the plant floor.
Complete System Bill of Materials
Typical control panel BOM pairing the 1783-MS10T with complementary Rockwell Automation components:
- 1783-MS10T — Stratix 8000 10-Port Managed Switch (this item)
- 1756-L85E — ControlLogix 5580 Controller (EtherNet/IP backplane)
- 1756-EN2T — ControlLogix EtherNet/IP Communication Module
- 1783-ETAP — EtherNet/IP Tap for DLR ring topology
- 1606-XLP95E — 24V DC Power Supply, 95W (switch power source)
- 1492-CABLE010A — Pre-wired DIN Rail Terminal Block Cables
- 2711P-T10C21D8S — PanelView Plus 7 HMI (network node)
- PowerFlex 525 (25B-D010N104) — AC Drive with embedded EtherNet/IP adapter
Contact Konmask.com for complete BOM pricing and availability on all line items.
Compliance & Industry Standards
- UL 508 — Industrial Control Equipment
- CE Marking — EMC Directive 2014/30/EU; Low Voltage Directive 2014/35/EU
- IEC 61000-4 — Electromagnetic Compatibility (ESD, EFT, Surge, Conducted Immunity)
- IEEE 802.3 — Ethernet Standard (10BASE-T / 100BASE-TX)
- IEEE 802.1Q — Virtual LANs (VLAN)
- IEEE 802.1D / 802.1w — Spanning Tree / Rapid Spanning Tree Protocol
- ODVA EtherNet/IP — Conformance Tested
- RoHS Compliant — Restriction of Hazardous Substances Directive
- ATEX / IECEx — Consult factory for hazardous location installation guidance
Quality Assurance & Sourcing
Konmask.com specializes in industrial automation components for B2B buyers who require verified, spec-accurate parts. Our sourcing and QA process includes:
- Authorized & Verified Supply Chain — Parts sourced from authorized distributors and verified secondary-market channels with full traceability documentation.
- Pre-Shipment Inspection — Each unit undergoes visual inspection, label verification, and firmware/revision-level confirmation against Rockwell Automation published specifications.
- Counterfeit Mitigation — Serial number validation and holographic label checks performed on every unit prior to dispatch.
- Packaging Integrity — Original OEM packaging preserved where available; ESD-safe anti-static packaging used for all shipments.
- Documentation Included — Certificate of conformance, packing list, and applicable test records provided upon request.
How to Source This Part
- Add to Cart — Click the purchase button above to place an order directly through Konmask.com.
- Request a Quote — For volume orders (>5 units), OEM project pricing, or BOM-level procurement, email support@konmask.com with your quantity and required delivery date.
- Lead Time — In-stock units ship within 1–3 business days. Out-of-stock items are sourced within 5–15 business days depending on supply chain availability.
- Export & Cross-Border Orders — We support international shipments with full commercial invoice, packing list, and HS code documentation (HS: 8517.62) for customs clearance.
- Technical Pre-Sales Support — Our engineering team can confirm firmware compatibility, revision levels, and system integration requirements before you order.
Application-Specific FAQ
Q: Can the 1783-MS10T support a Device Level Ring (DLR) topology with ControlLogix?
A: Yes. The 1783-MS10T is DLR-capable and can function as a DLR supervisor or ring node. It integrates natively with ControlLogix via EtherNet/IP for ring health monitoring in Studio 5000.
Q: What is the maximum number of VLANs supported?
A: The Stratix 8000 platform supports up to 255 VLANs (802.1Q), enabling robust network segmentation between control, HMI, and enterprise zones.
Q: Is this switch compatible with Cisco IOS-based management tools?
A: Yes. The Stratix 8000 series is built on a Cisco IOS foundation, allowing network engineers familiar with Cisco CLI to configure and manage the switch using standard IOS commands in addition to the Rockwell Automation Studio 5000 interface.
Q: What power supply voltage does the 1783-MS10T require?
A: The switch operates on 24V DC (18–32V DC range). A dedicated 24V DC industrial power supply such as the 1606-XLP95E is recommended for panel installations.
Q: Can I use this switch in a hazardous (classified) location?
A: The standard 1783-MS10T carries an IP20 rating and is not rated for direct installation in Class I/II hazardous locations. For hazardous area installations, the switch must be housed in a purged/pressurized enclosure meeting NEC Article 500 or IEC 60079 requirements. Contact Konmask.com for application-specific guidance.
Q: What is the network recovery time in a DLR ring?
A: DLR provides sub-3 ms network recovery time upon a single fault, meeting the requirements of most motion control and safety-instrumented system (SIS) applications.
Q: Do you supply firmware update files or configuration templates?
A: Firmware files are available through Rockwell Automation’s Product Compatibility and Download Center (PCDC). Konmask.com can provide baseline configuration templates for common topologies upon request.
