Industrial Control Power Solution — Allen-Bradley 1770-XYC | PLC-5 Series
Where This Product Is Used
The Allen-Bradley 1770-XYC is the OEM-specified lithium battery module for the Rockwell Automation PLC-5 programmable logic controller family. It is deployed across a wide range of mission-critical industrial environments where uninterrupted CMOS RAM backup is essential:
- Automotive Manufacturing — Body-in-white welding lines, paint shop conveyors, and powertrain assembly cells running PLC-5/10, 5/15, 5/20, 5/25, 5/30, 5/40, and 5/60 processors.
- Oil & Gas Processing — Upstream wellhead RTU panels and downstream refinery DCS integration nodes where program loss during power interruption is unacceptable.
- Water & Wastewater Treatment — SCADA-linked pump station controllers and chemical dosing systems requiring 24/7 uptime with infrequent maintenance windows.
- Pulp & Paper Mills — Continuous process lines (digesters, bleach plants, paper machines) where a controller restart causes costly production loss.
- Food & Beverage — CIP-intensive packaging lines and batch process controllers subject to frequent power cycling during sanitation shutdowns.
- Mining & Minerals — Conveyor drive control panels and crusher automation systems in remote sites with limited spare-parts logistics.
- Semiconductor Fab — Cleanroom HVAC and process gas control panels requiring validated, traceable replacement components.
Technical Specifications
| Attribute | Value |
|---|---|
| Catalog Number | 1770-XYC |
| Manufacturer | Allen-Bradley / Rockwell Automation |
| Compatible Series | PLC-5 (all variants: 5/10, 5/15, 5/20, 5/25, 5/30, 5/40, 5/60, 5/80) |
| Battery Chemistry | Lithium (Li-MnO₂) |
| Nominal Voltage | 3.0 V DC |
| Function | CMOS RAM backup — retains ladder logic, data tables, and I/O configuration during power loss |
| Typical Service Life | 3–5 years (ambient temperature dependent) |
| Low Battery Warning | Processor status bit S:11/14 (BAT) activates when voltage drops below threshold |
| Operating Temperature | 0 °C to +60 °C |
| Storage Temperature | −40 °C to +70 °C |
| Form Factor | Plug-in module, DIN-rail compatible chassis slot |
| Hazardous Material | Contains lithium — subject to IATA/IMDG shipping regulations |
| Weight | Approx. 100 g |
Why Engineers Specify This Model
- Zero-reprogram guarantee — A healthy 1770-XYC ensures the PLC-5 processor retains its full program image across planned and unplanned power outages, eliminating costly re-download and recommission cycles.
- Early-warning diagnostics — The processor’s built-in BAT status bit (S:11/14) provides advance notice before battery failure, enabling planned replacement during scheduled maintenance windows rather than emergency shutdowns.
- Drop-in replacement — Identical form, fit, and function to the original factory-installed battery; no firmware changes, no configuration edits, no tools required beyond a flat-blade screwdriver.
- Long shelf life — Lithium chemistry retains >90% capacity after 5 years of storage, making it suitable for strategic spare-parts inventory.
- Broad processor compatibility — A single SKU covers the entire PLC-5 family, simplifying procurement and reducing storeroom SKU proliferation.
Complete System Bill of Materials
When planning a PLC-5 battery replacement or preventive maintenance kit, engineers typically source the following complementary components:
- 1770-XYC — Battery module (this item)
- 1771-A1B / A2B / A3B / A4B — PLC-5 I/O chassis (matched to processor slot count)
- 1785-L20B / L40B / L60B / L80B — PLC-5 processor modules
- 1771-P4S / P6S — Power supply modules for the I/O chassis
- 1784-U2DHP — USB-to-DH+ interface for program backup prior to battery swap
- 1770-CD — DH+ coaxial cable (if network topology requires replacement)
Contact support@konmask.com to request a consolidated BOM quote for your maintenance project.
Compliance & Industry Standards
- RoHS — Compliant with EU Directive 2011/65/EU (Restriction of Hazardous Substances)
- IATA Dangerous Goods Regulations — Lithium battery; classified and shipped per IATA DGR Section II (PI 968/970)
- IEC 62133 — Battery safety standard for portable sealed secondary lithium cells
- UL 1642 — Standard for Lithium Batteries (where applicable to OEM certification)
- CE Marking — Applicable for EU market distribution
- Rockwell Automation Product Certification — OEM-specified replacement; catalog number traceable to Rockwell Automation publication 1770-IN009
Quality Assurance & Sourcing
Konmask.com sources the 1770-XYC exclusively through verified industrial automation distributors and authorized channel partners. Every unit shipped from our warehouse undergoes the following quality checks:
- Open-circuit voltage verification (≥ 2.9 V DC at dispatch)
- Visual inspection for label integrity, connector condition, and packaging seal
- Lot traceability recorded against order number for full audit trail
- Anti-static packaging with humidity indicator card for long-haul freight
We do not source from grey-market channels. All inventory is accompanied by a certificate of conformance available on request.
How to Source This Part
- Add to cart — Click the purchase button above to place a standard order. Most in-stock units ship within 1 business day.
- Request a quote — For quantities ≥ 5 units or project-based procurement, email support@konmask.com with your PO number and required delivery date.
- Urgent / AOG orders — Call +0086 19859288691 for same-day expedite assessment. We maintain a dedicated fast-track fulfillment lane for production-down situations.
- Blanket orders — Establish a standing purchase agreement for annual battery replacement programs across multiple PLC-5 assets. Volume pricing available.
Application-Specific FAQ
Q: How do I know when the 1770-XYC battery needs replacement?
A: Monitor the PLC-5 processor status file word S:11, bit 14 (BAT). When this bit goes HIGH, the battery voltage has dropped below the safe threshold. RSLogix 5 will also display a “Low Battery” fault in the controller diagnostics panel. Replace the battery within 30 days of the first warning to avoid data loss.
Q: Can I replace the battery while the PLC-5 is powered on (hot-swap)?
A: Yes — the PLC-5 processor maintains RAM from the backplane power supply while the battery is disconnected, provided the swap is completed in under 30 seconds. Always back up the program to a PC via RSLogix 5 before performing any battery replacement as a precaution.
Q: Is the 1770-XYC compatible with the PLC-5/250 and PLC-5/VME processors?
A: The 1770-XYC is specified for the standard PLC-5 rack-mount family. The PLC-5/250 and VME variants use different battery specifications — contact our technical team to confirm the correct part number for those platforms.
Q: What is the recommended replacement interval for preventive maintenance programs?
A: Rockwell Automation recommends replacing the 1770-XYC every 3 years in standard industrial environments (0–40 °C ambient). In high-temperature enclosures (>50 °C), annual replacement is advisable. Align battery replacement with your annual planned shutdown schedule.
Q: Do you provide a certificate of conformance (CoC)?
A: Yes. A CoC is available for every order upon request. Please note your requirement in the order comments or email support@konmask.com after purchase.
