Allen-Bradley 1783-US16T Stratix 2000 16-Port Unmanaged Switch | Replacement, Equivalent & Selection Guide
The Allen-Bradley 1783-US16T is a 16-port unmanaged industrial Ethernet switch from the Rockwell Automation Stratix 2000 series, designed for plug-and-play connectivity in factory-floor and process-control environments. This page provides full technical specifications, compatible replacement models, application guidance, and sourcing information to help engineers and procurement teams make confident selection decisions.
Technical Specifications
| Parameter | Value |
|---|---|
| Part Number | 1783-US16T |
| Series | Stratix 2000 |
| Manufacturer | Allen-Bradley / Rockwell Automation |
| Switch Type | Unmanaged |
| Total Ports | 16 × 10/100BASE-TX (RJ45) |
| Port Speed | 10/100 Mbps, Auto-negotiation, Auto-MDIX |
| Switching Capacity | 3.2 Gbps |
| Forwarding Rate | 2.38 Mpps |
| MAC Address Table | 2,000 entries |
| Power Supply | 24 VDC (18–32 VDC), dual redundant inputs |
| Power Consumption | ≤ 8 W (typical) |
| Operating Temperature | 0 °C to +60 °C |
| Storage Temperature | −40 °C to +85 °C |
| Relative Humidity | 5–95% non-condensing |
| Mounting | DIN rail |
| Enclosure Rating | IP30 |
| Certifications | UL, CE, cUL, ATEX Zone 2 (Class I Div 2) |
| Weight | ~1,180 g |
| Dimensions (W×H×D) | Approx. 135 × 130 × 55 mm |
Compatible Replacement & Equivalent Models
The table below lists verified drop-in replacements and functional equivalents for the 1783-US16T. All alternatives provide 16-port unmanaged 10/100 Mbps switching with DIN-rail mounting and 24 VDC power input.
| Model | Brand | Ports | Power | Temp Range | Notes |
|---|---|---|---|---|---|
| 1783-US16T | Allen-Bradley | 16 × RJ45 | 24 VDC | 0–60 °C | Original OEM |
| SCALANCE XB216 | Siemens | 16 × RJ45 | 24 VDC | 0–60 °C | Direct functional equivalent; PROFINET-ready |
| EDS-316 | Moxa | 16 × RJ45 | 12/24/48 VDC | 0–60 °C | Wide voltage range; IEC 61850 compliant |
| NS-316 | Antaira | 16 × RJ45 | 12–48 VDC | −10–60 °C | Cost-effective alternative |
| TH-1016 | Westermo | 16 × RJ45 | 10–60 VDC | −40–70 °C | Extended temperature; harsh environments |
| EKI-2516 | Advantech | 16 × RJ45 | 12–48 VDC | 0–60 °C | IEC 61000-4 surge protection |
Note: Always verify firmware compatibility and physical dimensions before substitution in safety-critical systems.
Why Choose the Original Model
- Seamless Studio 5000 / RSLogix integration — recognized natively by Rockwell Automation software without additional EDS files.
- Rockwell TechConnect support — full OEM technical support and lifecycle management.
- Validated for EtherNet/IP — optimized for CIP traffic prioritization in Allen-Bradley control architectures.
- Consistent hardware revision control — critical for regulated industries (FDA, ATEX, SIL).
- Long-term availability — Rockwell Automation provides multi-year product lifecycle commitments.
Typical Applications
- Factory automation and discrete manufacturing lines
- Machine-level EtherNet/IP device connectivity (drives, I/O, HMI)
- Panel-level network distribution in control cabinets
- Water/wastewater SCADA edge nodes
- Food & beverage processing lines requiring IP30 enclosures
- Automotive assembly plant floor networks
System Compatibility
- PLCs: Allen-Bradley ControlLogix, CompactLogix, MicroLogix, GuardLogix
- HMIs: PanelView Plus, PanelView 800
- Drives: PowerFlex 520, 750, 6000 series (EtherNet/IP)
- I/O: Point I/O, Flex I/O, POINT Guard I/O
- Software: Studio 5000 Logix Designer, FactoryTalk View, RSLinx Classic
- Protocols: EtherNet/IP, Modbus TCP (pass-through), IGMP Snooping (passive)
Selection Guide
Use the decision matrix below to confirm the 1783-US16T is the right choice — or identify a better-fit alternative:
| Requirement | Recommended Model |
|---|---|
| Standard AB control cabinet, 0–60 °C, EtherNet/IP | 1783-US16T (this product) |
| Need managed VLANs / QoS / SNMP | 1783-MS10T (Stratix 5700) or SCALANCE XC216 |
| Extended temperature −40 °C to +75 °C | 1783-US16T-A (Stratix 2000 XT) or Westermo TH-1016 |
| Fiber uplink required | 1783-US8T2F (8T + 2 SFP) or Moxa EDS-318-MM-SC |
| Budget-constrained, non-AB environment | Antaira NS-316 or Advantech EKI-2516 |
| PROFINET primary network | Siemens SCALANCE XB216 |
Quality Assurance & Sourcing
- Authentic OEM stock — all units sourced from authorized Rockwell Automation distributors or verified surplus channels with full traceability.
- Pre-shipment inspection — each unit undergoes visual inspection, label verification, and power-on functional test.
- Anti-counterfeit measures — holographic labels, serial number verification against Rockwell databases where applicable.
- Warranty — 12-month replacement warranty against manufacturing defects.
- Packaging — original OEM packaging retained where available; ESD-safe packaging for all units.
How to Order
- Confirm your required quantity and delivery timeline.
- Add to cart or contact us directly for bulk/project pricing.
- Provide your PO number, shipping address, and any special requirements (e.g., certificate of conformance, country of origin documentation).
- We will confirm stock availability, lead time, and issue a proforma invoice within 1 business day.
📧 support@konmask.com | 📞 +0086 19859288691
Replacement & Compatibility FAQ
Q: Can I replace the 1783-US16T with a managed switch?
A: Yes, but managed switches require additional configuration. The Stratix 5700 (1783-MS10T) is the recommended managed upgrade path within the AB ecosystem.
Q: Is the 1783-US16T compatible with Siemens PROFINET devices?
A: The switch is protocol-agnostic at Layer 2 and will pass PROFINET frames, but it is not PROFINET-certified. For PROFINET topologies, use a SCALANCE switch.
Q: What is the difference between 1783-US16T and 1783-US16TG?
A: The 1783-US16TG adds Gigabit (1000BASE-T) ports. If your devices support Gigabit, the TG variant offers higher throughput headroom.
Q: Can this switch be used in a Class I Division 2 hazardous location?
A: Yes, the 1783-US16T carries Class I Div 2 / ATEX Zone 2 certification when installed per Rockwell’s installation guidelines.
Q: Do you provide a certificate of conformance (CoC)?
A: Yes, CoC is available upon request at no additional charge.
