Genuine Allen-Bradley 1783-US8T Stratix 2000 Unmanaged Switch | Stratix Series – Verified Source
Konmask.com is a verified distributor of genuine Rockwell Automation / Allen-Bradley industrial networking components. The 1783-US8T is an 8-port unmanaged Ethernet switch from the Stratix 2000 series, engineered for reliable plug-and-play connectivity in industrial control environments. Every unit we ship is sourced through authenticated supply channels and passes our 4-step quality verification process before dispatch.
Technical Specifications
- Manufacturer: Allen-Bradley / Rockwell Automation
- Part Number: 1783-US8T
- Series: Stratix 2000
- Switch Type: Unmanaged
- Ports: 8 × 10/100BASE-TX RJ45 (Auto-MDI/MDIX)
- Switching Capacity: 1.6 Gbps
- Forwarding Rate: 1.19 Mpps
- MAC Address Table: 2,000 entries
- Power Supply: 24 VDC (18–32 VDC range), dual redundant input
- Power Consumption: 4.5 W (max)
- Operating Temperature: 0 °C to +60 °C
- Storage Temperature: −40 °C to +85 °C
- Relative Humidity: 5–95% (non-condensing)
- Mounting: DIN rail
- Dimensions (H × W × D): 110 × 45 × 99 mm
- Weight: Approx. 0.35 kg
- Protection Rating: IP20
- Certifications: UL, CE, cUL, ATEX Zone 2 (Class I Div 2)
Our 4-Step Quality Verification Process
Every Allen-Bradley component shipped from Konmask.com undergoes the following verification before it leaves our facility:
- Step 1 — Source Authentication: Units are procured exclusively from authorized distributors or factory-direct channels. Supplier documentation is retained on file.
- Step 2 — Physical Inspection: Label integrity, holographic seals, housing condition, and port/connector quality are inspected against OEM reference standards.
- Step 3 — Functional Power-On Test: Each switch is powered up and port link indicators are verified. Units exhibiting any fault are quarantined and not shipped.
- Step 4 — Packaging & Documentation Check: Original OEM packaging, datasheet, and certificate of conformance (where applicable) are confirmed before final dispatch.
Key Features & Benefits
- ✅ Zero-configuration deployment — plug-and-play unmanaged design reduces commissioning time on the plant floor
- ✅ DIN rail mount — integrates directly into standard control panel enclosures
- ✅ Dual redundant 24 VDC power inputs — eliminates single point of power failure for high-availability lines
- ✅ Auto-MDI/MDIX on all ports — eliminates crossover cable requirements
- ✅ Wide operating temperature range — suitable for harsh industrial environments
- ✅ Compact form factor — 45 mm width minimizes panel real estate
- ✅ Rockwell Automation ecosystem compatible — seamless integration with ControlLogix, CompactLogix, and other AB controllers
Typical Applications
- Machine-level Ethernet connectivity in manufacturing cells
- PLC-to-HMI and PLC-to-drive network segments
- Conveyor, packaging, and assembly line control panels
- Water/wastewater SCADA field panels
- Oil & gas skid-mounted control systems
- Building automation and energy management panels
- Retrofit and expansion of existing Stratix network infrastructure
Compatible System Components
- Controllers: ControlLogix (1756), CompactLogix (1769), MicroLogix (1100/1400), Micro800 series
- HMI: PanelView Plus 6 / 7, PanelView 800
- Drives: PowerFlex 520, 750, 755 series (EtherNet/IP adapter)
- I/O: Point I/O (1734-AENT), FLEX I/O (1794-AENT)
- Managed Switches (uplink): Stratix 5700 (1783-BMS), Stratix 5400 (1783-HMS)
- Software: Studio 5000 Logix Designer, FactoryTalk View SE/ME
Global Sourcing & Shipping Capabilities
- Stock Location: Mainland China warehouse with same-day or next-business-day dispatch on in-stock items
- Shipping Methods: DHL Express, FedEx International Priority, SF International, sea freight (LCL/FCL) for bulk orders
- Lead Time: In-stock items: 3–7 business days to most destinations; non-stock / special orders: quoted individually
- Export Documentation: Commercial invoice, packing list, certificate of origin, and customs HS code documentation provided as standard
- Bulk & OEM Orders: Volume pricing available — contact us for project quotations of 5+ units
- Regions Served: Southeast Asia, Middle East, Europe, North America, South America, Africa
Certifications & Compliance Statement
- UL Listed (UL 508 Industrial Control Equipment)
- CE Marked (EMC Directive 2014/30/EU; LVD Directive 2014/35/EU)
- cUL (Canadian Standards)
- ATEX / IECEx Zone 2 — Class I, Division 2, Groups A, B, C, D
- RoHS Compliant
- EtherNet/IP Conformance Tested (ODVA)
Konmask.com does not sell counterfeit, refurbished-as-new, or grey-market goods. All units are supplied with traceable sourcing documentation available upon request.
How to Order
- Add to Cart — select quantity and click “Add to Cart” or “Buy Now”.
- Request a Quote — for orders of 3+ units or project-based procurement, email support@konmask.com with your quantity, delivery address, and required lead time.
- Payment — we accept T/T (bank wire), PayPal, and major credit cards. Pro-forma invoice issued upon request.
- Shipping Confirmation — tracking number provided within 24 hours of dispatch.
- After-Sales Support — 12-month warranty against manufacturing defects. Replacement or full refund for verified authenticity issues.
Authenticity & Trust FAQ
Q: How do I know this is a genuine Allen-Bradley product?
A: All units pass our 4-step verification process and are sourced from authenticated supply channels. Supplier documentation is available upon request for B2B customers.
Q: Can you provide a certificate of conformance?
A: Yes. A certificate of conformance (CoC) is available for bulk orders. Please request it at the time of order.
Q: What if I receive a defective unit?
A: Contact us within 7 days of receipt. We will arrange replacement or refund after inspection. Return shipping is covered for verified defects.
Q: Do you offer technical support for installation?
A: Yes. Our team has hands-on experience with Rockwell Automation systems. Email or WhatsApp us for pre-sales and post-sales technical guidance.
Q: Can I order a sample unit before committing to a bulk order?
A: Absolutely. Single-unit sample orders are welcome. Contact us to discuss sample pricing and lead time.
