Multi-Axis Motion Control Solution — Allen-Bradley 2093-AMP2 | Kinetix 6000S Series
Where This Product Is Used
The Allen-Bradley 2093-AMP2 Axis Module is engineered for high-precision, multi-axis servo motion control in demanding industrial environments. Engineers and system integrators specify this module across a wide range of applications:
- Automotive Assembly Lines — Coordinated multi-axis positioning for robotic welding, stamping, and body-in-white assembly cells requiring sub-millisecond synchronization.
- Packaging Machinery — High-speed pick-and-place, form-fill-seal, and cartoning systems where precise axis coordination directly impacts throughput and product quality.
- CNC Machining Centers — Integrated into multi-axis milling, turning, and grinding machines demanding tight contouring accuracy and dynamic response.
- Semiconductor & Electronics Manufacturing — Wafer handling, PCB drilling, and SMT placement equipment requiring micron-level repeatability.
- Material Handling & Conveyance — Gantry systems, palletizers, and automated storage/retrieval systems (AS/RS) with synchronized multi-axis travel.
- Printing & Converting — Web tension control, register mark tracking, and multi-axis die-cutting lines.
- Food & Beverage Processing — Hygienic-environment motion control for slicing, portioning, and packaging lines operating under HACCP protocols.
Technical Specifications
- Part Number: 2093-AMP2
- Series: Kinetix 6000S
- Manufacturer: Allen-Bradley / Rockwell Automation
- Module Type: Axis Module (Inverter Power Module)
- Axes Supported: 2-axis shared DC bus configuration
- Bus Interface: Integrated DC bus connection to Kinetix 6000S Integrated Axis Module (IAM)
- Feedback Support: Incremental encoder, absolute encoder, resolver (motor-dependent)
- Communication: SERCOS interface via IAM backplane
- Mounting: Panel-mount, DIN rail compatible with Kinetix 6000S system rail
- Weight: 700 g (approx.)
- Compliance: CE, UL Listed, RoHS
- Operating Temperature: 0 °C to 50 °C (32 °F to 122 °F)
- Storage Temperature: −40 °C to 85 °C
- Enclosure Rating: IP20 (panel-mount installation required)
Why Engineers Specify This Model
- Shared DC Bus Architecture — Regenerative energy sharing between axes reduces overall power consumption and eliminates the need for individual power supplies per axis, lowering panel footprint and BOM cost.
- Tight Integration with Logix Platform — Native integration with Studio 5000 Logix Designer and ControlLogix/CompactLogix PLCs enables unified programming, diagnostics, and motion coordination without third-party middleware.
- Scalable Multi-Axis Expansion — The 2093-AMP2 slots directly onto the Kinetix 6000S system rail alongside the IAM, allowing engineers to scale from 2 to 8+ axes without redesigning the power architecture.
- Advanced Motion Coordination — Supports electronic gearing, camming, and coordinated linear/circular interpolation natively within the Logix motion instruction set (MAM, MCD, MAPC, etc.).
- Proven Field Reliability — Kinetix 6000S has an established installed base across global OEM machine builders and end-user facilities, with extensive Rockwell Automation service network support.
- Simplified Commissioning — Auto-tuning and integrated motion analyzer tools in Studio 5000 reduce commissioning time versus standalone drive configurations.
Complete System Bill of Materials
The 2093-AMP2 Axis Module operates as part of the Kinetix 6000S system. A complete multi-axis drive system typically includes:
- 2093-AC05-MP1 / 2093-AC05-MP2 — Kinetix 6000S Integrated Axis Module (IAM) — required as the system power and communication hub
- 2093-AMP2 — This Axis Module (AM) — 2-axis expansion
- 2090-XXNFMF-Sxx — Motor power cables (motor-specific, length-dependent)
- 2090-XXNFBMP-Sxx — Feedback cables (encoder/resolver, motor-specific)
- MPL / VPL / MPM Series Servo Motors — Allen-Bradley servo motors matched to axis power rating
- 1756-M02AE / 1756-M08SE — ControlLogix Motion Module (if SERCOS-based architecture)
- 2093-PRF — System rail for mounting IAM and AM modules
- 2093-DNPT — DC bus terminator plug (required at end of system rail)
Contact Konmask for complete BOM assistance and compatibility verification for your specific motor and controller combination.
Compliance & Industry Standards
- CE Marking — Compliant with EU Machinery Directive 2006/42/EC and Low Voltage Directive 2014/35/EU
- UL Listed — UL 508C (Power Conversion Equipment)
- RoHS Compliant — EU Directive 2011/65/EU (Restriction of Hazardous Substances)
- ISO 13849 / IEC 62061 — Compatible with functional safety architectures when paired with appropriate safety modules
- IEC 61800-5-1 — Adjustable speed electrical power drive systems safety requirements
- SEMI S2 / S8 — Applicable for semiconductor equipment installations
Quality Assurance & Sourcing
Konmask.com sources Allen-Bradley 2093-AMP2 modules through verified industrial distribution channels. Every unit offered is subject to the following quality controls:
- Authenticity Verification — Units are cross-referenced against Rockwell Automation authorized distributor records and factory serial number databases where accessible.
- Visual & Functional Inspection — Each module undergoes physical inspection for connector integrity, label authenticity, firmware revision marking, and absence of counterfeit indicators.
- Condition Grading — Units are clearly graded: New Surplus (factory-sealed), Refurbished (tested to OEM spec), or Used (as-removed, tested). Grade is stated on each listing.
- Traceability Documentation — Chain-of-custody documentation available upon request for regulated industries (semiconductor, pharma, defense).
- Warranty — 12-month operational warranty on all tested units. New surplus units carry full OEM warranty where applicable.
How to Source This Part
- In-Stock Orders — Add to cart and check out directly. Most in-stock units ship within 1–2 business days from our warehouse.
- Urgent / Emergency Requirements — Contact us via WhatsApp or email for same-day quotation and expedited shipping options (DHL Express, FedEx Priority).
- Volume / Project Procurement — Request a formal quotation for multi-unit orders, project BOM sourcing, or blanket purchase agreements.
- Cross-Reference & Compatibility Check — Not sure if 2093-AMP2 fits your system? Send us your existing IAM part number, motor catalog numbers, and controller model — our engineers will confirm compatibility before you order.
- Export & International Shipping — We ship globally. Export documentation, commercial invoices, and HS code declarations provided for customs clearance.
Application-Specific FAQ
Q: Can the 2093-AMP2 be used as a standalone drive without the Kinetix 6000S IAM?
A: No. The 2093-AMP2 is an Axis Module that requires a Kinetix 6000S Integrated Axis Module (IAM) to provide DC bus power and SERCOS communication. It cannot operate independently.
Q: How many 2093-AMP2 modules can be connected to a single IAM?
A: The number of AM modules per IAM is limited by the IAM’s total continuous output current rating and the system rail capacity. Typically 1–4 AM modules per IAM, depending on motor load. Consult Rockwell Automation publication 2093-UM001 for sizing guidelines.
Q: Is the 2093-AMP2 compatible with MPL, VPL, and MPM series motors?
A: Yes, provided the motor’s continuous stall current and peak current requirements fall within the AM’s rated output. Always verify using the Kinetix Motion Analyzer tool or contact Konmask for a compatibility check.
Q: What firmware version is required on the IAM for compatibility with 2093-AMP2?
A: Refer to Rockwell Automation compatibility matrix (publication MOTION-RM003). Generally, IAM firmware 1.x and above supports the 2093-AMP2, but always verify against your specific Studio 5000 version.
Q: Can this module be used in a Safety (SIL 2 / PLd) application?
A: The 2093-AMP2 itself does not include integrated safety functions. For SIL 2 / PLd applications, pair with a Kinetix 6000S safety option module and a GuardLogix safety controller per the applicable safety manual.
Q: Do you provide installation and commissioning support?
A: Konmask provides pre-sales technical consultation and documentation support. For on-site commissioning, we can refer you to certified Rockwell Automation system integrators in your region.
