Industrial HMI & Machine Control Solution — Allen-Bradley 2706-M1N1 | PanelView Operator Interface
Where This Product Is Used
The Allen-Bradley 2706-M1N1 PanelView Operator Interface is deployed across a wide range of industrial automation environments where reliable human-machine interaction is critical:
- Discrete Manufacturing Lines — Machine status monitoring, fault acknowledgment, and operator command entry on assembly and packaging lines.
- Food & Beverage Processing — Hygienic-environment control panels requiring durable, easy-to-clean operator terminals.
- Water & Wastewater Treatment — Remote pump station and valve control interfaces integrated with Allen-Bradley PLCs.
- Automotive Body Shops & Paint Lines — Cycle start/stop, recipe selection, and alarm display at point-of-use stations.
- Material Handling & Conveyor Systems — Speed setpoint entry and conveyor zone control at operator workstations.
- OEM Machine Builders — Embedded as the primary operator interface in custom-built machinery shipped to end users worldwide.
Technical Specifications
| Attribute | Detail |
|---|---|
| Part Number | 2706-M1N1 |
| Manufacturer | Allen-Bradley (Rockwell Automation) |
| Product Family | PanelView Operator Interface |
| Display Type | Keypad / Membrane operator terminal |
| Communication | DH-485 / RS-232 serial |
| Power Supply | 24V DC |
| Operating Temperature | 0°C to 55°C (32°F to 131°F) |
| Enclosure Rating | NEMA 4 / IP65 (panel-mount) |
| Weight | 5.9 kg |
| Compatible Software | PanelBuilder 1400e |
| Replacement / Successor | PanelView 800 / PanelView Plus 7 |
Note: Verify exact specifications against the official Rockwell Automation product bulletin prior to installation.
Why Engineers Specify This Model
- Proven DH-485 Ecosystem Compatibility — Seamlessly integrates with legacy SLC 500 and MicroLogix PLC networks without gateway hardware.
- Rugged NEMA 4 / IP65 Enclosure — Withstands wash-down, dust, and harsh plant-floor conditions without additional protective enclosures.
- Low-Complexity Replacement — Drop-in form factor simplifies panel retrofits; existing cutouts and wiring harnesses are typically reused.
- Deterministic Serial Communication — DH-485 protocol delivers reliable, low-latency data exchange in electrically noisy environments.
- Long Field Service History — Extensive installed base means experienced technicians and abundant documentation are readily available.
- Cost-Effective MRO Sourcing — Refurbished and surplus units provide significant CAPEX savings versus new-generation HMI upgrades.
Complete System Bill of Materials
For a fully functional 2706-M1N1 operator station, engineers typically specify the following complementary components:
- PLC Controller — Allen-Bradley SLC 5/03, SLC 5/04, or MicroLogix 1100/1400
- Communication Cable — 1747-C13 or 1747-C20 DH-485 shielded cable
- Power Supply — 24V DC regulated DIN-rail PSU (e.g., 1606-XLP series)
- Programming Software — PanelBuilder 1400e (for terminal configuration)
- I/O Modules — 1746-series digital/analog I/O as required by application
- Enclosure — NEMA 12 or NEMA 4 steel enclosure for panel assembly
- Surge Protection — DIN-rail surge suppressor on 24V DC supply rail
Contact support@konmask.com for bundled BOM pricing and availability checks.
Compliance & Industry Standards
- UL Listed — Meets UL 508 requirements for industrial control equipment.
- CE Marked — Compliant with EU Low Voltage Directive and EMC Directive for European installations.
- NEMA 4 / IP65 — Rated for protection against dust ingress and water jets.
- RoHS — Manufactured in compliance with EU RoHS Directive (verify unit-specific documentation for refurbished stock).
- CSA Certified — Certified for use in Canadian industrial installations.
Quality Assurance & Sourcing
At Konmask.com, every Allen-Bradley 2706-M1N1 unit undergoes a structured quality process before shipment:
- Visual Inspection — Keypad membrane, housing, and connector integrity checked against cosmetic acceptance criteria.
- Functional Power-On Test — Unit is powered and communication ports are verified for signal integrity.
- Authenticity Verification — Part markings, date codes, and label formats are cross-referenced against genuine Rockwell Automation documentation.
- Anti-Static Packaging — Units are shipped in ESD-safe bags with foam cushioning inside double-wall cartons.
- Traceability Records — Batch and inspection records retained for 3 years; available upon request for regulated industries.
How to Source This Part
- Add to Cart — Click the purchase button above to place an order directly through Konmask.com.
- Request a Quote — For quantities ≥ 3 units or urgent MRO requirements, email support@konmask.com for volume pricing.
- Lead Time — In-stock units typically ship within 1–3 business days. Lead time for sourced units is quoted individually.
- Export Orders — International buyers: contact us for HS code documentation, commercial invoice templates, and freight options.
- Phone / WhatsApp — Reach our technical sales team at +0086 19859288691 for urgent inquiries.
Application-Specific FAQ
Q: Is the 2706-M1N1 compatible with ControlLogix or CompactLogix PLCs?
A: Not natively. The 2706-M1N1 communicates via DH-485, which is native to SLC 500 and MicroLogix platforms. ControlLogix/CompactLogix integration requires a 1761-NET-AIC or similar protocol converter.
Q: Can I use RSLinx or Studio 5000 to configure this terminal?
A: No. The 2706-M1N1 is configured exclusively with PanelBuilder 1400e software. RSLinx is used only for communication path setup, not terminal programming.
Q: What is the difference between 2706-M1N1 and 2706-M1N2?
A: The suffix typically denotes firmware revision or regional variant. Confirm the exact part number against your existing panel documentation before ordering.
Q: Is this a new or refurbished unit?
A: Konmask.com supplies both new-surplus and refurbished units depending on availability. Unit condition is specified at checkout. All units pass our QA process regardless of condition grade.
Q: Do you provide a warranty?
A: Yes. All units carry a 90-day functional warranty covering defects in operation. Contact support@konmask.com within the warranty period for RMA processing.
