Allen-Bradley 2711-T10C8L1 PanelView 1000 Color Touch Terminal | Replacement, Equivalent & Selection Guide
The Allen-Bradley 2711-T10C8L1 is a 10.4″ color touch screen operator interface terminal from Rockwell Automation’s PanelView 1000 series. Designed for demanding industrial environments, it delivers reliable HMI performance for machine control and process visualization applications. This page provides full technical specifications, compatible replacement models, and a structured selection guide to help engineers and procurement teams make informed sourcing decisions.
Technical Specifications
- Part Number: 2711-T10C8L1
- Brand / Manufacturer: Allen-Bradley (Rockwell Automation)
- Series: PanelView 1000
- Display Type: Color TFT LCD Touch Screen
- Display Size: 10.4 inches
- Resolution: 640 × 480 (VGA)
- Touch Technology: Resistive Touch
- Communication: DH-485 / RS-232
- Power Supply: 24 VDC
- Operating Temperature: 0°C to 55°C
- Storage Temperature: -40°C to 85°C
- Protection Rating: NEMA 4/4X, 12, 13 (front panel)
- Memory: 512 KB application memory
- Weight: Approx. 3.6 kg
- Certifications: UL, CE, CSA
Compatible Replacement & Equivalent Models
The following models are commonly evaluated as direct or functional replacements for the 2711-T10C8L1. Compatibility depends on communication protocol, panel cutout dimensions, and application software version.
- 2711-T10C8L2 — Revised firmware revision; functionally equivalent, same form factor
- 2711P-T10C4D8 — PanelView Plus 1000, 10.4″ color touch, DH-485/Ethernet; direct upgrade path
- 2711P-T10C4D8K — PanelView Plus 1000 with keypad; suitable when touch-only is insufficient
- 2711P-T10C21D8S — PanelView Plus 7 Standard 1000, modern replacement with enhanced connectivity
- 2715-T10CD — PanelView 5500, 10.4″ color touch; high-performance next-generation replacement
- Weintek MT8102iE — Third-party equivalent; 10.1″ color touch, supports AB DF1/DH-485 protocols
- Proface GP4501TW — Third-party equivalent; 10.4″ color touch, multi-protocol support
Note: Always verify panel cutout dimensions, communication protocol, and PLC compatibility before substituting. Contact Konmask for pre-sales compatibility verification.
Why Choose the Original Model
- Proven Reliability: The 2711-T10C8L1 has an extensive field track record in automotive, food & beverage, and discrete manufacturing environments.
- Native AB Integration: Seamless integration with Allen-Bradley PLCs (SLC 500, MicroLogix, PLC-5) via DH-485 without additional gateways.
- Existing Application Compatibility: Retains compatibility with legacy PanelBuilder 32 application files, eliminating costly reprogramming.
- Spare Parts Availability: Konmask maintains sourced stock of tested units to support MRO and emergency replacement needs.
- Lower Total Cost for Legacy Lines: Replacing with the original model avoids PLC firmware upgrades and HMI application migration costs.
Typical Applications
- Discrete manufacturing machine control panels
- Automotive assembly line operator stations
- Food & beverage processing line HMI
- Packaging machinery operator interfaces
- Water/wastewater SCADA local operator panels
- OEM machine retrofits and MRO replacements
System Compatibility
| PLC Family | Protocol | Compatible |
|---|---|---|
| SLC 500 | DH-485 | ✔ Native |
| MicroLogix 1000/1100/1400 | DH-485 / RS-232 DF1 | ✔ Native |
| PLC-5 | DH+ (via 1785-KA5 gateway) | ✔ With gateway |
| ControlLogix / CompactLogix | Ethernet/IP | ✗ Not supported (use PanelView Plus) |
| Third-party PLCs | RS-232 DF1 | ⚠ Protocol-dependent |
Selection Guide
Use the decision tree below to determine whether the 2711-T10C8L1 or an alternative model best fits your application:
- Existing DH-485 network + SLC 500/MicroLogix + PanelBuilder 32 application? → Order 2711-T10C8L1 (original replacement)
- Need Ethernet/IP connectivity or ControlLogix integration? → Upgrade to 2711P-T10C4D8 (PanelView Plus 1000)
- Require modern web-based configuration and higher resolution? → Consider 2711P-T10C21D8S (PanelView Plus 7)
- Budget-constrained retrofit with multi-brand PLC environment? → Evaluate Weintek MT8102iE or Proface GP4501TW
- Long-term greenfield project requiring future scalability? → Specify 2715-T10CD (PanelView 5500)
Not sure which model fits your system? Contact our selection team with your PLC model, communication protocol, and panel cutout dimensions.
Quality Assurance & Sourcing
- Source: Authorized distributor channels and verified surplus stock
- Inspection: Each unit undergoes visual inspection, power-on functional test, and communication port verification prior to shipment
- Condition: New, refurbished (tested), and surplus options available — specify at time of inquiry
- Warranty: 12-month warranty on all units shipped from Konmask.com
- Traceability: Batch records and test reports available upon request for critical applications
- Packaging: Anti-static packaging with foam protection; export carton available for international shipments
How to Order
- Confirm part number: 2711-T10C8L1
- Specify required condition: New / Refurbished-Tested / Surplus
- Provide delivery destination and required lead time
- Submit inquiry via email or phone — quotation returned within 1 business day
Email: [email protected]
Phone/WhatsApp: +0086 19859288691
Website: https://Konmask.com
Replacement & Compatibility FAQ
Q: Is the 2711-T10C8L1 still in production?
A: This model has been discontinued by Rockwell Automation. Konmask supplies tested surplus and refurbished units to support ongoing MRO requirements.
Q: Can I use a PanelView Plus 1000 (2711P-T10C4D8) as a direct replacement?
A: The PanelView Plus 1000 uses the same 10.4″ panel cutout and supports DH-485, making it a viable upgrade. However, application files must be migrated from PanelBuilder 32 to FactoryTalk View ME software.
Q: What is the panel cutout dimension for the 2711-T10C8L1?
A: The standard panel cutout is 310 mm × 248 mm (W × H). Verify against your enclosure before ordering a replacement.
Q: Does Konmask provide a warranty on refurbished units?
A: Yes. All refurbished units carry a 12-month warranty covering functional defects. Units are tested prior to shipment.
Q: Can this terminal communicate with a ControlLogix PLC?
A: The 2711-T10C8L1 does not natively support Ethernet/IP. For ControlLogix systems, we recommend upgrading to the PanelView Plus or PanelView Plus 7 series.
Q: How long does delivery take?
A: In-stock units typically ship within 1–3 business days. Lead time for sourced units is quoted individually. Contact us for current availability.
