Allen-Bradley 2711P-K6M20D8 PanelView Plus 600 Grayscale Keypad | Replacement, Equivalent & Selection Guide
The Allen-Bradley 2711P-K6M20D8 is a 6-inch grayscale keypad terminal from the PanelView Plus 600 series, manufactured by Rockwell Automation. Designed for demanding industrial HMI applications, it delivers reliable operator interface functionality in environments where color displays are not required. This page provides full technical specifications, compatible replacement models, application guidance, and sourcing information to help engineers and procurement teams make confident selection decisions.
Technical Specifications
- Part Number: 2711P-K6M20D8
- Series: PanelView Plus 600
- Manufacturer: Allen-Bradley / Rockwell Automation
- Display Type: Grayscale (Monochrome)
- Display Size: 6 inches diagonal
- Input Type: Keypad (no touchscreen)
- Communication: DH-485, DF1, DH+, Ethernet/IP (via catalog variant)
- Operating Voltage: 24V DC
- Operating Temperature: 0°C to 55°C (32°F to 131°F)
- Storage Temperature: -40°C to 70°C
- Enclosure Rating: NEMA 4/4X, 12, 13; IP65 (front panel)
- Weight: Approx. 700 g
- Software: FactoryTalk View ME (Machine Edition)
- Memory: 32 MB Flash / 32 MB RAM (standard configuration)
- Certifications: UL, CE, CSA
Compatible Replacement & Equivalent Models
The following models are commonly evaluated as direct or functional replacements for the 2711P-K6M20D8. Always verify communication protocol and software compatibility before substitution.
- 2711P-K6C20D8 — PanelView Plus 600, Color TFT, Keypad (color upgrade equivalent)
- 2711P-T6M20D8 — PanelView Plus 600, Grayscale, Touchscreen (touch variant)
- 2711P-T6C20D8 — PanelView Plus 600, Color, Touchscreen
- 2711P-K6M5A8 — PanelView Plus 600, Grayscale, Keypad, AC power variant
- 2711-K6C15 — PanelView 600 (legacy series, functional predecessor)
- 2711P-K6M20D — Earlier revision without D8 suffix (check firmware compatibility)
- Weintek MT6070iH — Third-party HMI equivalent, 7-inch, supports AB PLC protocols
- Siemens KTP600 Basic Mono PN — Cross-brand equivalent for Siemens-integrated systems
Note: Third-party equivalents require protocol adapter configuration. Contact our technical team for compatibility verification.
Why Choose the Original Model
- Native FactoryTalk View ME integration — zero configuration overhead with existing AB PLC systems
- Proven NEMA 4X / IP65 sealing — suitable for washdown and harsh industrial environments
- Rockwell Automation ecosystem compatibility — seamless with Studio 5000, RSLogix 500/5000, and ControlLogix/CompactLogix platforms
- Long service life and spare parts availability — widely supported in global MRO supply chains
- Grayscale display advantage — superior readability in high-ambient-light environments vs. color TFT
- Keypad interface — preferred in gloved-hand or high-vibration applications where touchscreen accuracy degrades
Typical Applications
- Automotive assembly line operator stations
- Food & beverage processing control panels (washdown environments)
- Water/wastewater treatment SCADA terminals
- Pharmaceutical batch control interfaces
- Oil & gas field equipment HMI
- Material handling and conveyor system controls
- Machine tool and CNC operator panels
System Compatibility
- PLC Platforms: ControlLogix, CompactLogix, MicroLogix, SLC 500, PLC-5
- Networks: EtherNet/IP, DH-485, DF1 (RS-232), DH+
- Software: FactoryTalk View ME v5.0 and above
- Power Supply: 24V DC (external supply required)
- Panel Cutout: Standard PanelView Plus 600 cutout dimensions apply
Selection Guide
Use the following criteria to confirm the 2711P-K6M20D8 is the right choice, or to identify the best alternative:
- Display size needed: 6″ → 2711P-K6xx series | 7″+ → consider 2711P-T7 or 2711P-K7 series
- Color vs. Grayscale: Grayscale (M) = 2711P-K6M20D8 | Color (C) = 2711P-K6C20D8
- Input method: Keypad (K) = 2711P-K6M20D8 | Touchscreen (T) = 2711P-T6M20D8
- Power supply: DC (D8) = 2711P-K6M20D8 | AC (A8) = 2711P-K6M20A8
- Communication protocol: Confirm DH-485 / EtherNet/IP requirement matches your PLC network
- Environment rating: NEMA 4/4X standard — suitable for most industrial washdown applications
Quality Assurance & Sourcing
- All units sourced from authorized distributors or verified surplus channels
- Each unit undergoes visual inspection and functional verification prior to shipment
- Original packaging and documentation preserved where available
- Traceability records maintained for MRO and OEM procurement compliance
- Warranty: 90-day replacement warranty on all stocked units
- Counterfeit prevention: units verified against Rockwell Automation part marking standards
How to Order
- Step 1: Confirm part number: 2711P-K6M20D8
- Step 2: Verify quantity and lead time requirements with our team
- Step 3: Add to cart or contact us for bulk/OEM pricing
- Step 4: Provide shipping destination for freight quote (international orders welcome)
- Email: support@konmask.com
- Phone/WhatsApp: +0086 19859288691
- Website: https://Konmask.com
Replacement & Compatibility FAQ
Q: Can the 2711P-K6M20D8 replace a 2711-K6C15 (legacy PanelView 600)?
A: Functionally yes, but the application must be migrated from PanelView software to FactoryTalk View ME. Physical cutout dimensions differ — verify panel cutout before installation.
Q: Is the 2711P-K6M20D8 compatible with CompactLogix L-series PLCs?
A: Yes, via EtherNet/IP or DF1 serial. Ensure FactoryTalk View ME project is configured with the correct communication driver.
Q: What is the difference between 2711P-K6M20D8 and 2711P-K6M20D?
A: The “8” suffix denotes the Series B hardware revision with updated firmware support. Series B is recommended for new installations.
Q: Can I use a third-party HMI (e.g., Weintek, Siemens) as a drop-in replacement?
A: Third-party HMIs can communicate with AB PLCs via protocol drivers, but require application re-development. Not a true drop-in replacement — consult our technical team.
Q: Do you offer exchange/repair services for faulty 2711P-K6M20D8 units?
A: Yes. Contact support@konmask.com with your unit’s serial number and fault description for a repair/exchange quote.
