Allen-Bradley 2711P-T6C20D8 – 6″ Color Touch HMI | PanelView Plus 6 Series
Engineering Background: The PanelView Plus 6 platform is Rockwell Automation’s flagship operator interface series, engineered for demanding industrial environments where reliable human-machine interaction is non-negotiable. The 2711P-T6C20D8 represents the 6-inch form factor with a color TFT touchscreen and 24 VDC power input — the most widely deployed configuration across discrete manufacturing, process control, and infrastructure automation.
Product Positioning: Designed for procurement engineers sourcing verified replacement or expansion units for existing Allen-Bradley / FactoryTalk View ME architectures. This unit integrates natively with Studio 5000, RSLogix 5000, and FactoryTalk View Studio without additional licensing overhead, making it the lowest-risk HMI choice for Rockwell-centric control systems.
Complete Technical Specifications
- Part Number: 2711P-T6C20D8
- Series: PanelView Plus 6
- Manufacturer: Allen-Bradley / Rockwell Automation
- Display Size: 6.5″ (diagonal) TFT Color LCD
- Resolution: 640 × 480 (VGA)
- Touch Technology: Resistive analog touchscreen
- Input Power: 24 VDC (DC input variant)
- Power Consumption: ~18 W typical
- Communication Ports: Dual Ethernet (10/100 Mbps), USB Type-A (host), USB Type-B (device), RS-232
- Application Memory: 512 MB Flash storage
- Operating System: Windows CE 6.0
- Runtime Software: FactoryTalk View ME (pre-installed)
- Operating Temperature: 0 °C to +55 °C
- Storage Temperature: −40 °C to +85 °C
- Humidity: 5–95% RH (non-condensing)
- Ingress Protection: NEMA 4/4X, 12, 13 (front face); IP65 (front face)
- Certifications: UL Listed, CE Marked, cUL, RoHS compliant
- Panel Cutout: 192 mm × 138 mm (W × H)
- Weight: ~1,150 g
- Catalog Suffix -D8: Conformal coating for enhanced environmental protection
Proven Application Environments
- Discrete Manufacturing: Assembly line operator stations, conveyor control, robotic cell HMI
- Process Industries: Water/wastewater SCADA panels, chemical dosing control, HVAC automation
- Food & Beverage: Washdown-tolerant (NEMA 4X) packaging and filling line interfaces
- Oil & Gas: Wellhead and pipeline monitoring panels (conformal coat -D8 variant)
- Infrastructure: Building automation, power distribution, and utility control rooms
- OEM Machine Builders: Standard HMI platform for multi-site fleet standardization
Engineering Advantages
- Native FactoryTalk View ME Integration: Zero-configuration runtime — upload application via USB or Ethernet directly from Studio 5000 / FT View Studio.
- Dual Ethernet Ports: Supports device-level ring (DLR) topology for network redundancy without additional switches.
- Conformal Coating (-D8): PCB-level protection against moisture, dust, and corrosive atmospheres — critical for harsh industrial enclosures.
- Compact 6″ Form Factor: Fits standard NEMA 4/12 enclosure cutouts; ideal for space-constrained panel designs.
- Long Product Lifecycle: Rockwell Automation’s extended support commitment ensures spare parts and firmware availability through the platform lifecycle.
- USB Application Transfer: Field technicians can load or back up HMI applications without a laptop — reduces commissioning time on-site.
System Architecture & Signal Flow
The 2711P-T6C20D8 operates as an EtherNet/IP Class 1 I/O device and implicit messaging client. Typical signal flow in a Rockwell architecture:
- PLC Layer: CompactLogix / ControlLogix controller hosts the tag database and ladder/function block logic.
- Network Layer: EtherNet/IP switch connects PLC, HMI, and I/O modules on a common subnet; DLR ring topology supported via dual ports on this unit.
- HMI Layer: 2711P-T6C20D8 subscribes to PLC tags via FactoryTalk Linx; operator inputs write tag values back to the controller in real time.
- Data Logging: Alarm history and data logs stored to onboard Flash or external USB drive; exportable to CSV for MES/SCADA integration.
- Remote Access: FactoryTalk View ME supports VNC-based remote monitoring when connected to plant network.
Sourcing & Quality Verification
- Stock Condition: Surplus / refurbished units inspected prior to listing; functional test performed on power-up and communication ports.
- Authenticity: All units sourced from traceable industrial channels — no counterfeit risk. Nameplate and catalog number verified against Rockwell Automation part records.
- Warranty: 90-day Konmask operational warranty covering power-on functionality and communication integrity.
- Packaging: Anti-static bag + foam-lined carton; ships with original mounting hardware where available.
- Lead Time: In-stock units ship within 1–3 business days; contact us for volume or expedited requirements.
Procurement Process
- Step 1 — Confirm Part Number: Verify 2711P-T6C20D8 against your BOM or existing panel label. Check suffix (-D8 = conformal coat, DC input).
- Step 2 — Request Quote: Email support@konmask.com with quantity, required delivery date, and destination port for freight calculation.
- Step 3 — Order Confirmation: Pro-forma invoice issued within 24 hours; payment via T/T bank transfer or approved credit terms for qualified accounts.
- Step 4 — Shipment & Documentation: Commercial invoice, packing list, and test report provided with every shipment. Export documentation available on request.
- Step 5 — Technical Support: Post-delivery commissioning support available via email or WhatsApp (+86 198 5928 8691).
Technical FAQ
Q: Is this unit compatible with FactoryTalk View Studio v10 and later?
A: Yes. PanelView Plus 6 terminals are supported in FT View Studio ME through the current release. Ensure your .MER application is compiled targeting PVP6 runtime version.
Q: Can I replace a 2711P-T6C20D8 with a 2711P-T6C21D8?
A: The -C21 suffix denotes AC input (100–240 VAC). If your panel supplies 24 VDC, the -C20D8 (DC) is the correct replacement. Swapping AC/DC variants requires power supply modification.
Q: Does the -D8 conformal coating affect touchscreen sensitivity?
A: No. Conformal coating is applied to the PCB only, not the display or touch surface. Touchscreen performance is identical to non-coated variants.
Q: What firmware version is pre-loaded?
A: Units ship with the firmware version present at time of testing. Firmware can be updated via USB using the PanelView Plus 6 firmware upgrade kit from Rockwell Automation’s Product Compatibility and Download Center (PCDC).
Q: Can I order in bulk for a plant-wide HMI standardization project?
A: Yes. Contact us for volume pricing, staggered delivery schedules, and dedicated account management for multi-unit procurement.
