ABB 086349-001 Gate Driver Board | Replacement, Equivalent & Selection Guide
The ABB 086349-001 is an OEM Gate Driver Board used in ABB drive and power conversion systems. This page provides full technical specifications, verified compatible replacements, equivalent cross-reference models, and a structured selection guide to help engineers and procurement teams make confident sourcing decisions.
Technical Specifications
| Part Number | 086349-001 |
| Manufacturer | ABB |
| Description | Gate Driver Board |
| Product Category | Drive Control / Power Electronics Board |
| Function | IGBT / power transistor gate drive signal conditioning |
| Compatibility | ABB ACS / DCS series drives (verify with drive nameplate) |
| Condition Available | New OEM, Refurbished, Tested Used |
| Lead Time | Contact for availability |
| SKU | 086349-001 |
Note: Detailed electrical parameters (voltage, current rating, isolation level) vary by drive series. Please provide your drive model number for exact confirmation.
Compatible Replacement & Equivalent Models
The following models are commonly evaluated as replacements or equivalents for the ABB 086349-001. Compatibility must be verified against your specific drive model and firmware revision before installation.
- ABB 086349-002 / -003 – Revised board revisions; may be direct drop-in replacements depending on drive series
- ABB NGDR-02C / NGDR-03C – Gate driver boards used in ACS800 series; functionally similar architecture
- ABB AINT-02C – Auxiliary interface board with gate drive functions in certain configurations
- Third-party compatible boards – Available for select ABB drive platforms; must match connector pinout, isolation rating, and PWM signal timing
⚠ Important: Always cross-reference the drive’s service manual before substituting any gate driver board. Incorrect substitution can damage IGBTs or void drive warranty.
Why Choose the Original Model
- OEM-matched signal timing – Designed to ABB’s exact PWM gate drive specifications for the target drive platform
- Isolation integrity – Factory-tested galvanic isolation between control and power stages
- Thermal performance – Optimized for the thermal envelope of the original drive enclosure
- Firmware compatibility – No risk of incompatibility with ABB drive control firmware
- Warranty & traceability – New OEM units carry full ABB traceability and warranty coverage
Typical Applications
- ABB ACS series variable frequency drives (VFDs) – motor speed control in industrial automation
- ABB DCS series DC drives – regenerative and non-regenerative DC motor control
- Industrial power conversion systems requiring IGBT gate drive boards
- Preventive maintenance and spare parts stocking for critical drive systems
- Field repair and board-level replacement in drive service centers
System Compatibility
The ABB 086349-001 Gate Driver Board is designed for integration within ABB drive control architectures. Confirmed or commonly associated platforms include:
- ABB ACS800 series drives
- ABB ACS600 series drives (selected variants)
- ABB DCS800 series DC drives
- Custom ABB OEM drive assemblies using the 086349-xxx board family
Please provide your drive model number, serial number, and firmware version when inquiring to confirm exact compatibility.
Selection Guide
Use the following decision framework to select the correct gate driver board for your application:
- Step 1 – Identify your drive model: Locate the nameplate on your ABB drive (model, power rating, firmware version).
- Step 2 – Confirm the failed board part number: The part number is printed on the PCB silkscreen or listed in the drive’s spare parts manual.
- Step 3 – Determine condition requirement: New OEM for critical uptime applications; tested refurbished for budget-sensitive or backup scenarios.
- Step 4 – Evaluate alternatives: If 086349-001 is unavailable, review the equivalent models listed above and confirm pinout and signal compatibility.
- Step 5 – Contact Konmask: Share your drive details and we will confirm availability, lead time, and pricing.
Quality Assurance & Sourcing
- All boards sourced through authorized channels or verified industrial surplus with full traceability documentation
- Refurbished units undergo functional testing, visual inspection, and cleaning prior to shipment
- Anti-static packaging (ESD-safe bags + foam) for all PCB shipments
- Certificate of conformance (CoC) available upon request for new OEM units
- Konmask.com specializes in industrial automation components with a focus on ABB, Siemens, Schneider, and Rockwell platforms
How to Order
- Contact us via email at [email protected] or call +0086 19859288691
- Provide your drive model number, required quantity, and preferred condition (new / refurbished)
- Receive a quotation with lead time and shipping options within 1 business day
- Confirm order and arrange payment via your preferred method
- Shipment with tracking number and packing documentation provided
Replacement & Compatibility FAQ
Q: Can I use a refurbished 086349-001 in a production-critical drive?
A: Yes, provided the board has been fully tested and documented. We recommend requesting a test report and CoC for production-critical applications.
Q: Is the 086349-001 interchangeable with the 086349-002?
A: In many cases yes, but revision changes may affect connector layout or firmware handshake. Always verify with the drive service manual or contact us for confirmation.
Q: How long does shipping take?
A: Domestic (China): 2–5 business days. International: 5–15 business days depending on destination and customs clearance.
Q: Do you provide a warranty on gate driver boards?
A: New OEM units carry the manufacturer’s warranty. Refurbished units carry a 90-day functional warranty from Konmask.com.
Q: Can you help identify the correct replacement if I don’t have the part number?
A: Yes. Send us your drive model, a photo of the failed board, and any visible markings — we will identify the correct replacement.
