DCS Process Control Solution – ABB 1KHW001223R0002 P4LT | AC800M Series
Where This Product Is Used
The ABB 1KHW001223R0002 P4LT Control Card is a core processing module deployed in ABB’s AC800M Distributed Control System (DCS) platform. It is widely specified in the following industrial environments:
- Oil & Gas – Upstream wellhead automation, midstream pipeline SCADA, and downstream refinery process control
- Power Generation – Turbine governor control, boiler management systems (BMS), and grid-tie protection relay coordination
- Pulp & Paper – Continuous digester control, bleaching sequence automation, and paper machine drive coordination
- Chemical & Petrochemical – Batch reactor sequencing, distillation column control, and safety instrumented system (SIS) integration
- Water & Wastewater – Pump station automation, SCADA remote I/O, and treatment plant PLC replacement projects
- Mining & Minerals – Conveyor drive control, crusher automation, and flotation cell process loops
Technical Specifications
| Part Number | 1KHW001223R0002 |
| Model | P4LT |
| Series | AC800M |
| Manufacturer | ABB |
| Module Type | Control Card / CPU Module |
| Platform | ABB AC800M DCS |
| Communication | MMS / IEC 61850 / Profibus / Modbus |
| Operating Temperature | 0°C to +55°C |
| Weight | 450 g |
| Form Factor | Rack-mount card, AC800M chassis compatible |
| Firmware | Compatible with ABB Control Builder M |
Why Engineers Specify This Model
- Proven AC800M Ecosystem – Seamlessly integrates with ABB’s full AC800M I/O library, eliminating custom driver development
- High Availability Architecture – Supports redundant controller configurations for SIL-rated and continuous-process applications
- IEC 61131-3 Compliant – Programmable in Structured Text, Function Block Diagram, Ladder Logic, and Sequential Function Chart
- Long Product Lifecycle – ABB’s AC800M platform is actively supported with firmware updates and spare-part availability
- Deterministic Scan Cycle – Ensures precise timing for closed-loop PID and cascade control strategies
- Compact Footprint – Card-slot form factor minimizes panel space in retrofit and brownfield upgrade projects
Complete System Bill of Materials
For a fully operational AC800M controller node, engineers typically specify the following alongside the P4LT:
- ABB PM864A / PM865A – Processor Module (redundant pair)
- ABB TB820V2 – ModuleBus Optical Interface
- ABB CI854B – PROFIBUS DP Interface Module
- ABB SD821 / SD822 – Power Supply Unit
- ABB S800 I/O Modules – AI810, AO810, DI810, DO810 series
- ABB AC800M Rack / Chassis – 19″ DIN-rail or rack-mount enclosure
Contact support@konmask.com for complete BOM pricing and availability.
Compliance & Industry Standards
- IEC 61131-3 – Programmable Controller Languages
- IEC 61850 – Communication Networks for Substations
- IEC 61511 – Functional Safety / SIS (SIL-capable platform)
- CE Marking – European Conformity
- UL Listed – Underwriters Laboratories
- RoHS Compliant – Restriction of Hazardous Substances
Quality Assurance & Sourcing
- Authentic ABB Origin – Sourced from authorized ABB distributors and verified OEM supply chains
- Pre-shipment Inspection – Each unit undergoes visual, label, and functional verification before dispatch
- Traceability – Batch records and serial number documentation available on request
- Packaging – Original ABB anti-static packaging retained where possible; ESD-safe repackaging applied otherwise
- Warranty – 12-month replacement warranty against manufacturing defects
How to Source This Part
Konmask.com maintains stock of the ABB 1KHW001223R0002 P4LT for immediate dispatch. To place an order or request a formal quotation:
- 📧 Email: support@konmask.com
- 📞 Phone / WhatsApp: +0086 19859288691
- 🌐 Web: https://konmask.com
Lead time: In-stock units ship within 1–3 business days. Out-of-stock units sourced within 7–15 business days.
Application-Specific FAQ
Q: Is the 1KHW001223R0002 P4LT compatible with ABB Control Builder M software?
A: Yes. The P4LT card is fully supported by ABB Control Builder M for configuration, programming, and diagnostics.
Q: Can this card be used in a redundant controller setup?
A: Yes. The AC800M platform supports 1:1 controller redundancy. Consult ABB’s redundancy configuration guide for wiring and parameter setup.
Q: What is the difference between P4LT and other AC800M CPU variants?
A: The P4LT designation refers to a specific hardware revision within the AC800M family. Always cross-reference your existing system’s hardware catalog before ordering.
Q: Do you supply the full AC800M system or individual cards only?
A: Konmask.com supplies both individual modules and complete configured systems. Contact us with your BOM for a consolidated quote.
Q: Can you provide a certificate of conformity or test report?
A: Yes. Documentation packages including CoC, inspection reports, and serial number traceability are available upon request.
