ABB 3BHB003431R0101 KUC720 AE01 3BHB000652R0101 Power Panel – Drive Control Unit
When a critical drive control unit fails on the plant floor, production doesn’t slow down — it stops. The ABB KUC720 AE01 Power Panel (3BHB003431R0101 / 3BHB000652R0101) is the nerve center of ABB’s high-power drive systems. Without it, the entire variable-speed drive loses its ability to regulate motor output, monitor protection parameters, and communicate with the supervisory control layer. Every minute of unplanned downtime in a cement kiln, a steel rolling mill, or a marine propulsion system translates directly into lost revenue and potential equipment damage. Sourcing a verified replacement quickly is not optional — it is mission-critical.
The KUC720 AE01 occupies a flagship position within ABB’s drive control board family, engineered specifically for the ACS6000 and ACS1000 medium-voltage drive platforms — systems that govern multi-megawatt loads across the world’s most demanding industrial environments. With part numbers 3BHB003431R0101 and 3BHB000652R0101 representing the primary control board and its paired power supply assembly, this unit is recognized globally as a benchmark for reliability in high-voltage variable frequency drive (VFD) control architecture. Konmask.com maintains sourcing channels for this assembly to support urgent MRO and capital project requirements worldwide.
Technical Specifications
- Manufacturer: ABB
- Primary Part Number: 3BHB003431R0101
- Secondary Part Number: 3BHB000652R0101
- Module Designation: KUC720 AE01
- Module Type: Power Panel / Drive Control Unit
- Compatible Drive Series: ABB ACS6000, ACS1000 (medium-voltage VFD platforms)
- Function: Drive control, motor protection, gate pulse generation, I/O interface
- Form Factor: Plug-in control board assembly
- Weight: Approx. 100 g (board assembly)
- Condition Available: New, Refurbished, Tested Used
Note: All specifications are based on ABB published documentation. Konmask.com does not fabricate or alter technical parameters.
Key Features & Benefits
- Precision Drive Control: Executes real-time gate pulse commands for IGCT/IGBT power semiconductors, ensuring accurate motor speed and torque regulation.
- Integrated Protection Logic: Monitors overcurrent, overvoltage, thermal, and ground-fault conditions to protect both the drive and connected motor assets.
- Dual-Part Assembly Design: The 3BHB003431R0101 control board and 3BHB000652R0101 power supply work as a matched pair, reducing integration risk during replacement.
- High-Reliability Construction: Designed for continuous 24/7 operation in harsh industrial environments including high ambient temperature, vibration, and EMI exposure.
- Direct Drop-In Replacement: Maintains full backward compatibility with existing ACS6000/ACS1000 drive cabinets — no firmware re-flashing required in most configurations.
- Global MRO Support: Widely stocked by authorized distributors and specialist suppliers like Konmask.com to minimize lead times for emergency replacements.
Industry & Equipment Applications
- Oil & Gas: Compressor drives, pump drives, subsea motor control systems
- Mining & Minerals: SAG mill drives, conveyor belt drives, hoist systems
- Cement & Building Materials: Kiln drives, raw mill drives, fan control systems
- Steel & Metals: Rolling mill main drives, coiler drives, ladle crane hoists
- Marine & Offshore: Azipod propulsion systems, thruster drives, winch control
- Power Generation: Hydro turbine governors, wind turbine pitch control, pump-storage systems
- Water & Wastewater: Large pump station VFD control, desalination plant drives
System Integration & Compatible Parts
The KUC720 AE01 Power Panel is designed to integrate within the ABB ACS6000 and ACS1000 drive cabinet ecosystem. Compatible and commonly co-ordered parts include:
- ABB SDCS-CON-4 – Drive Control Board (ACS800 series)
- ABB RINT-5611C – Fiber Optic Interface Board
- ABB NAMC-11 – Motor Control Module
- ABB RDCU-12C – Drive Control Unit
- ABB APBU-44C – Branching Unit for Fiber Optics
Please contact our technical team to confirm compatibility with your specific drive serial number and firmware revision before ordering.
Our Quality Assurance Process
- Visual Inspection: Every unit is inspected for physical damage, corrosion, burnt components, and connector integrity upon receipt.
- Functional Testing: Where applicable, boards are bench-tested using ABB-compatible test rigs to verify core logic and communication functions.
- Traceability: Part numbers, revision codes, and serial numbers are verified against ABB documentation to confirm authenticity.
- Secure Packaging: All units are shipped in ESD-safe anti-static packaging with foam cushioning to prevent transit damage.
- Warranty: Konmask.com provides a limited warranty on all tested and refurbished units. Contact us for terms.
How to Order
- Submit your inquiry via the Contact / Request a Quote form on this page.
- Provide your drive model, serial number, and required quantity.
- Our technical team will confirm availability, condition, and lead time within 24 business hours.
- Upon agreement, we issue a proforma invoice and arrange secure international shipping (DHL, FedEx, UPS, or sea freight).
- Tracking information and documentation (test report, packing list, commercial invoice) are provided upon dispatch.
Why Choose Konmask.com?
- Industrial Automation Specialists: We focus exclusively on PLC, DCS, VFD, and industrial control components — not general electronics.
- Global Sourcing Network: Access to verified stock from authorized distributors, OEM surplus, and tested-used channels worldwide.
- Technical Expertise: Our team includes engineers with hands-on experience in ABB drive systems, ensuring accurate part identification and compatibility advice.
- Fast Response: Emergency inquiries receive priority handling. We understand that downtime is not an option.
- Transparent Documentation: Full traceability documentation provided with every shipment.
- Secure International Shipping: Experienced in export compliance and customs documentation for industrial components shipped to 50+ countries.
Frequently Asked Questions
Q: Is the 3BHB003431R0101 the same as the KUC720 AE01?
A: Yes. 3BHB003431R0101 is the ABB catalog part number for the KUC720 AE01 Power Panel control board assembly. The 3BHB000652R0101 is the associated power supply sub-assembly typically supplied as a matched pair.
Q: Which ABB drive series uses the KUC720 AE01?
A: The KUC720 AE01 is primarily used in ABB ACS6000 and ACS1000 medium-voltage variable frequency drives. Please verify against your drive’s documentation or contact us with your serial number for confirmation.
Q: Do you supply new or refurbished units?
A: Konmask.com can source new (factory-sealed), refurbished (tested and restored), and tested-used units depending on availability and your budget requirements. Condition is clearly stated in all quotations.
Q: What is the lead time for this part?
A: Lead time varies by stock availability. In-stock units typically ship within 2–5 business days. For sourced units, lead time is typically 2–4 weeks. Contact us for a real-time availability check.
Q: Can you provide test reports or certificates of conformance?
A: Yes. Test reports and certificates of conformance are available for refurbished and tested-used units. Please request these at the time of inquiry.
Q: Do you accept returns?
A: Returns are accepted within the warranty period for units that fail to perform as described. Please review our returns policy or contact support@konmask.com for details.
