ABB 3HAC057549-003 Rotational AC Motor with Pinion – IRB 6650 Industrial Robot Series
When a rotational axis motor fails on an ABB IRB 6650 robot, the entire production line stops. In high-throughput automotive welding, heavy-duty material handling, and precision foundry operations, even a single hour of unplanned downtime can cost tens of thousands of dollars. The axis drive motor is not a peripheral component — it is the mechanical heart of every articulated movement the robot makes. Without a verified, OEM-compatible replacement like the ABB 3HAC057549-003, restoring full robot functionality is impossible.
The 3HAC057549-003 is ABB’s factory-designated rotational AC servo motor with integrated pinion gear, engineered specifically for the IRB 6650 series — one of ABB’s most widely deployed heavy-payload industrial robots, rated for payloads up to 235 kg and reach up to 3.9 m. This motor assembly is a precision-matched drive component that interfaces directly with the robot’s axis gearbox, ensuring torque transmission accuracy, positional repeatability, and long-term mechanical integrity. It is a critical spare part stocked by maintenance engineers in automotive OEMs, tier-1 suppliers, and industrial automation integrators worldwide.
Technical Specifications
- Part Number: 3HAC057549-003
- Manufacturer: ABB Robotics
- Compatible Robot Series: IRB 6650
- Motor Type: Rotational AC Servo Motor with Pinion
- Component Category: Axis Drive Motor Assembly
- Weight: 1,040 g (approx.)
- Condition: New / Refurbished (specify at inquiry)
- OEM Reference: ABB Robotics genuine spare part
Note: Electrical ratings, gear ratio, and encoder specifications are application-dependent. Contact our engineering team for full datasheet access.
Key Features & Benefits
- OEM-Matched Pinion Interface: The integrated pinion gear is precision-machined to ABB’s exact tolerances, ensuring zero-backlash engagement with the IRB 6650 axis gearbox.
- AC Servo Technology: Delivers high torque density, smooth velocity control, and superior thermal stability compared to DC motor alternatives.
- Drop-In Replacement: Designed as a direct swap for the original motor assembly — no mechanical modification required during installation.
- Encoder Compatibility: Fully compatible with ABB’s IRC5 controller resolver/encoder feedback system for closed-loop axis control.
- Robust Construction: Built to withstand continuous industrial duty cycles in harsh environments including foundry dust, weld spatter, and high-ambient-temperature conditions.
- Traceability: Each unit supplied with verifiable part number markings for maintenance record compliance.
Industry & Equipment Applications
- Automotive Manufacturing: Spot welding, arc welding, and body-in-white assembly lines using ABB IRB 6650 robots.
- Foundry & Die Casting: High-temperature part extraction and machine tending where motor thermal resilience is critical.
- Heavy Material Handling: Palletizing, press tending, and large-component transfer in steel, aerospace, and heavy equipment manufacturing.
- Maintenance & Overhaul (MRO): Scheduled preventive maintenance programs for robot fleets requiring certified spare part inventories.
- System Integrators: Rebuilding or refurbishing IRB 6650 units for secondary market deployment.
System Integration & Compatible Parts
The 3HAC057549-003 motor is designed to operate within the ABB IRB 6650 robot ecosystem. Commonly paired components include:
- ABB IRC5 Robot Controller (M2004 / M2000 variants)
- ABB Axis Gearbox assemblies (axis 1–6, model-dependent)
- ABB Motor Cable Harnesses and Resolver Cables
- ABB Brake Release Units (where applicable per axis)
- ABB FlexPendant and RAPID programming interface for post-replacement calibration
If you require a complete axis rebuild kit or complementary spare parts, contact our team for a consolidated BOM quotation.
Our Quality Assurance Process
At Konmask.com, every ABB spare part undergoes a structured verification process before shipment:
- Part Number Verification: Physical label and internal marking cross-checked against ABB’s official spare parts catalog.
- Visual & Mechanical Inspection: Pinion gear teeth, motor housing, connector pins, and encoder interface inspected for wear, damage, or non-conformance.
- Functional Testing (where applicable): Refurbished units are bench-tested for winding resistance, insulation integrity, and encoder signal output.
- Secure Packaging: Anti-static, foam-padded packaging with moisture barrier for international freight.
- Documentation: Packing list, inspection report, and certificate of conformance provided upon request.
How to Order
- Submit an Inquiry: Use the contact form or email support@konmask.com with your required quantity and delivery timeline.
- Receive a Quotation: Our team will respond within 24 business hours with pricing, lead time, and shipping options.
- Confirm & Pay: Orders confirmed via proforma invoice. Payment via T/T bank transfer, PayPal, or other agreed methods.
- Shipment & Tracking: Parts shipped via DHL, FedEx, or UPS Express with full tracking provided.
- After-Sales Support: Technical assistance available for installation verification and compatibility questions.
Why Choose Konmask.com?
- ✅ Specialized in Industrial Automation Spare Parts — ABB, Siemens, Fanuc, KUKA, and more.
- ✅ Global Shipping — Serving customers in 50+ countries with reliable express logistics.
- ✅ Engineering-Led Team — Our staff understand robot architecture, not just part numbers.
- ✅ Competitive Lead Times — In-stock items ship within 3–5 business days; sourced items within 2–4 weeks.
- ✅ Transparent Sourcing — We disclose part condition (new/refurbished) and origin clearly in every quotation.
- ✅ Long-Term Partnership — Preferred supplier relationships with MRO teams and procurement departments globally.
Frequently Asked Questions
Q: Is the 3HAC057549-003 compatible with all IRB 6650 variants?
A: The IRB 6650 series includes multiple payload/reach configurations (e.g., IRB 6650-125/3.2, IRB 6650-200/2.75, IRB 6650-235/2.55). Axis motor assignments can vary by variant. Please confirm your robot’s full model designation and axis number before ordering.
Q: Do you supply new or refurbished units?
A: We supply both. New OEM units and professionally refurbished units are available. Condition is clearly stated in the quotation. Refurbished units include inspection reports.
Q: Can you provide the full technical datasheet?
A: Yes. ABB spare part datasheets and wiring diagrams are available upon request for verified procurement inquiries. Contact support@konmask.com.
Q: What is the warranty on this part?
A: New units carry the standard manufacturer warranty. Refurbished units carry a 90-day functional warranty from Konmask.com. Terms are specified in the sales agreement.
Q: How long does international shipping take?
A: DHL/FedEx Express typically delivers within 3–7 business days to most destinations. Economy freight options are available for larger orders.
