ABB 5SHX 0445D0001 / 3BHL000382P0101 IGBT Drive Board | Replacement, Equivalent & Selection Guide
The ABB 5SHX 0445D0001 (cross-reference: 3BHL000382P0101) is a high-power IGBT gate drive board designed for ABB’s ACS/ACS800/ACS6000 series medium-voltage and high-power AC drives. This page provides full technical specifications, verified compatible replacements, application guidance, and a structured selection guide to help engineers and procurement teams make confident sourcing decisions.
Technical Specifications
- Part Number: 5SHX 0445D0001
- Cross Reference: 3BHL000382P0101
- Manufacturer: ABB Ltd.
- Type: IGBT Gate Drive Board
- Series: 5SHX / ACS High-Power Drive Series
- Function: Gate drive signal conditioning and protection for IGBT power modules
- Rated Voltage: Compatible with medium-voltage IGBT stacks (consult drive documentation)
- Weight: Approx. 700 g
- Condition Available: New, Refurbished, Tested Used
- Origin: ABB Switzerland / Sweden manufacturing
Compatible Replacement & Equivalent Models
The following models are commonly evaluated as replacements or equivalents. Always verify electrical and mechanical compatibility before installation:
- 3BHL000382P0101 – Direct OEM cross-reference (same unit, alternate part number)
- 5SHX 0445D0002 – Revised revision; confirm firmware compatibility
- 3BHL000387P0001 – Functionally similar drive board for adjacent IGBT stack ratings
- 5SHY 3545L0001 – Alternative IGBT module with integrated drive; verify stack configuration
- Third-party aftermarket boards rated for equivalent IGBT gate drive parameters – contact Konmask for vetted options
Note: Konmask.com supplies both OEM original and verified-compatible alternatives. Contact us with your drive model and serial number for a confirmed match.
Why Choose the Original ABB 5SHX 0445D0001
- OEM Precision: Engineered specifically for ABB IGBT stacks — no adaptation or tuning required
- Integrated Protection: Built-in desaturation detection, short-circuit protection, and gate voltage monitoring
- Long Service Life: Designed for continuous industrial duty in high-power drive environments
- Firmware Compatibility: Guaranteed compatibility with ABB ACS drive control boards
- Traceability: Full OEM documentation and batch traceability available
Typical Applications
- ABB ACS800 / ACS6000 series high-power AC variable frequency drives (VFDs)
- Medium-voltage motor control centers (MCCs)
- Industrial pump, fan, compressor, and conveyor drive systems
- Power generation and grid-tie inverter systems
- Steel, mining, oil & gas, and marine propulsion applications
System Compatibility
- Compatible Drive Families: ABB ACS800, ACS6000, ACS5000 (verify by drive rating plate)
- IGBT Stack Interface: Designed for ABB 5SHX-series IGBT press-pack modules
- Control Interface: Fiber-optic gate signal input (standard ABB DDCS/RDCO protocol)
- Cooling: Designed for forced-air or liquid-cooled drive cabinet environments
Selection Guide
Use the following criteria to confirm the correct drive board for your application:
- Step 1 – Identify your IGBT module: Locate the IGBT stack part number on the drive cabinet label (e.g., 5SHX 0445D0001)
- Step 2 – Match the drive board revision: Check the PCB revision label; some drive software versions require specific board revisions
- Step 3 – Confirm fiber-optic channel count: Verify the number of gate drive channels matches your IGBT stack topology (single, dual, or multi-level)
- Step 4 – Check voltage class: Confirm the drive board is rated for your DC bus voltage level
- Step 5 – Contact Konmask: Provide your drive model, serial number, and existing board part number for a guaranteed-compatible recommendation
Quality Assurance & Sourcing
- All units sourced from authorized ABB distributors or verified industrial surplus channels
- Pre-shipment functional test and visual inspection on every unit
- Anti-static packaging with humidity indicator cards
- Certificate of conformance (CoC) available on request
- Warranty: 12 months from date of shipment (new units); 90 days (refurbished/tested)
How to Order
- Online: Add to cart directly from this page
- Email RFQ: support@konmask.com — include part number, quantity, and required condition
- Phone/WhatsApp: +0086 19859288691
- Lead Time: In-stock units ship within 1–3 business days; sourced units 5–15 business days
- Payment: T/T, PayPal, credit card, and trade assurance accepted
Replacement & Compatibility FAQ
Q: Is 3BHL000382P0101 the same as 5SHX 0445D0001?
A: Yes — these are dual part numbers for the same ABB IGBT drive board. Both numbers appear on the OEM label.
Q: Can I use a third-party replacement board?
A: Aftermarket alternatives exist, but must match gate drive voltage, current, and fiber-optic interface specifications exactly. Konmask can advise on vetted alternatives.
Q: Do you supply tested/refurbished units?
A: Yes. All refurbished units are bench-tested under load conditions and carry a 90-day warranty.
Q: What information do I need to confirm compatibility?
A: Drive model number, serial number, existing board part number, and PCB revision (if visible). Send to support@konmask.com.
Q: Do you offer volume pricing?
A: Yes — contact us for OEM/MRO volume quotes and blanket order arrangements.
