EMERSON A6220 Dual Channel Eccentric Vibration Monitoring | Replacement, Equivalent & Selection Guide
The EMERSON A6220 is a dual-channel eccentric vibration monitoring module designed for use within EMERSON’s Ovation distributed control system (DCS) and compatible industrial automation platforms. It continuously measures shaft eccentricity on rotating machinery, providing critical protection data for turbines, compressors, and large motors in power generation and process industries.
Selection Background
When sourcing the A6220, buyers frequently search for A6220 replacement, A6220 equivalent, or A6220 substitute options — whether due to long lead times, end-of-life status, budget constraints, or cross-brand standardization projects. This guide is designed to help engineers and procurement teams make an informed selection decision, covering direct drop-in options, functional equivalents, and cross-brand alternatives, along with the critical parameters that govern compatibility.
Technical Specifications
| Parameter | Specification | Replacement-Critical |
|---|---|---|
| Model | A6220 | — |
| Manufacturer | EMERSON | — |
| Function | Dual Channel Eccentric Vibration Monitoring | ★ |
| Channels | 2 (independent) | ★★ |
| Measurement Type | Shaft eccentricity (proximity probe input) | ★★ |
| Signal Input | Eddy-current proximity probe (Bently Nevada compatible) | ★★ |
| Output | 4–20 mA analog / digital to DCS backplane | ★ |
| Communication | Ovation DCS backplane bus | ★★ |
| Power Supply | 24 VDC (via backplane) | ★ |
| Weight | 300 g | — |
| Form Factor | DCS I/O module (card format) | ★★ |
| Certifications | CE, UL (verify with datasheet) | ★ |
★★ = Critical for replacement compatibility | ★ = Important to verify
Compatible Replacement & Equivalent Models
1. Direct Drop-in Replacements
Direct replacements share the same form factor, backplane connector, and firmware compatibility within the EMERSON Ovation system. These can be swapped without reconfiguration in most cases:
- EMERSON A6220 (new production run) — Identical OEM part; confirm revision level matches your system firmware.
- EMERSON A6220-xxx variants — Suffix variants may indicate firmware or hardware revision; verify with EMERSON part matrix before ordering.
Prerequisite: Same Ovation DCS chassis and backplane revision. Confirm firmware compatibility with your system integrator.
2. Functional Equivalents (Same Platform)
Modules with equivalent monitoring function within the EMERSON ecosystem, requiring configuration changes but no hardware modification:
- EMERSON A6215 — Single-channel vibration monitor; use two units to replicate dual-channel function. Requires I/O mapping reconfiguration.
- EMERSON A6230 — Expanded vibration monitoring card; superset of A6220 functionality. Verify backplane slot compatibility.
Note: Functional equivalents require engineering review and DCS configuration update. Not plug-and-play.
3. Cross-Brand Alternatives
For system migrations, budget sourcing, or multi-vendor standardization, the following cross-brand modules offer comparable eccentric vibration monitoring capability:
- Bently Nevada 3500/40M — Industry-standard proximity/eccentricity monitor; requires signal conditioning and DCS interface adapter.
- Rockwell Automation 1756-IRT8I — Configurable analog input module; can be programmed for proximity probe inputs with appropriate scaling.
- Siemens SIMATIC S7 SM 331 — Analog input module for vibration signal acquisition; requires custom engineering for eccentricity calculation.
Important: Cross-brand alternatives require full engineering validation, signal interface design, and DCS software modification. Contact Konmask for a compatibility assessment before ordering.
Why Choose the Original EMERSON A6220
- Measurement Precision: Factory-calibrated for EMERSON Ovation’s eccentricity algorithm, ensuring ±1% full-scale accuracy without field recalibration.
- OEM Certification: Fully certified and validated for use in EMERSON Ovation DCS environments — no additional qualification testing required.
- Seamless Backplane Compatibility: Plug-and-play replacement within the same Ovation chassis generation, minimizing downtime during maintenance windows.
- Integrated Diagnostics: Native self-diagnostics and fault reporting via Ovation operator station — not available with third-party substitutes.
- OEM Technical Support: Full EMERSON technical support, firmware updates, and lifecycle documentation available for original part numbers.
- Warranty & Traceability: Genuine parts sourced through authorized channels include full warranty coverage and traceable manufacturing documentation.
Typical Applications
- Power Generation: Steam turbine eccentricity monitoring during startup/shutdown sequences at coal, gas, and nuclear power plants.
- Petrochemical: Large compressor shaft monitoring in ethylene crackers and refinery process trains.
- LNG Terminals: Cryogenic pump and expander eccentricity measurement in liquefaction and regasification facilities.
- Steel & Metals: Rolling mill drive shaft monitoring for early detection of bearing wear and rotor bow.
- Water & Wastewater: Large centrifugal pump protection in municipal water treatment and desalination plants.
- Marine & Offshore: Propulsion shaft eccentricity monitoring on LNG carriers and FPSO vessels with EMERSON Ovation-based automation.
System Compatibility
The A6220 is designed for use within the following EMERSON Ovation ecosystem components:
- Ovation Controller (OCR400/OCR1100) — Primary DCS controller communicating with A6220 via backplane.
- Ovation I/O Subsystem Chassis — Standard 19″ rack chassis providing backplane power and data bus.
- Proximity Probe Systems (Bently Nevada 3300/3500 series) — Eddy-current probe and driver providing raw eccentricity signal to A6220 input.
- Ovation Operator Station (OWS) — Engineering workstation for configuration, calibration, and alarm management.
- EMERSON AMS Machinery Manager — Asset management software for vibration trend analysis and predictive maintenance integration.
- Ovation Historian — Process data historian for long-term eccentricity trend storage and reporting.
Selection Guide
Answer these three questions to confirm A6220 compatibility before ordering:
- Is your DCS platform EMERSON Ovation? — The A6220 is designed exclusively for the Ovation backplane architecture. If you operate a different DCS (ABB, Honeywell, Yokogawa), a cross-brand alternative with interface engineering is required. Contact Konmask for a compatibility assessment.
- What is your chassis and firmware revision? — Confirm your Ovation chassis generation and controller firmware version to ensure the A6220 revision you order is compatible. Provide your existing module part number suffix when requesting a quote.
- How many eccentricity channels do you need? — The A6220 provides 2 independent channels. If you require 4+ channels, consider the A6230 or multiple A6220 units. Contact Konmask for multi-channel configuration advice.
Quality Assurance & Sourcing
Sourcing Channels: Konmask sources EMERSON A6220 modules through authorized distributors, certified refurbishers, and verified surplus channels. All units undergo multi-stage inspection before shipment.
4-Step Inspection Process:
- Visual Inspection: PCB, connectors, and housing checked for physical damage, corrosion, and counterfeit indicators.
- Functional Test: Module powered and tested for correct I/O response, channel isolation, and backplane communication.
- Calibration Verification: Output signal accuracy verified against reference standard; recalibrated if outside tolerance.
- Documentation Review: Serial number, firmware version, and manufacturing date recorded and cross-referenced with EMERSON product database.
Available Documentation: Test report, calibration certificate, material traceability record, and EMERSON datasheet available upon request.
How to Order
- Submit Your Inquiry: Email support@konmask.com or call +0086 19859288691 with your model number (A6220), required quantity, and chassis/firmware details.
- Receive Quote & Compatibility Confirmation: Konmask will verify compatibility with your system and provide a detailed quotation within 24 hours.
- Confirm & Ship: Upon order confirmation, modules are inspected, documented, and dispatched with full traceability paperwork.
Replacement & Compatibility FAQ
Q: Can I use the A6220 as a direct replacement for a failed eccentricity monitoring card in my Ovation system?
A: Yes — the A6220 is designed as a field-replaceable module within the EMERSON Ovation DCS. In most cases it is a direct drop-in replacement for a failed unit of the same part number. Confirm the firmware revision matches your system before installation.
Q: Is the A6220 compatible with Bently Nevada proximity probes, or do I need a substitute signal conditioner?
A: The A6220 accepts standard eddy-current proximity probe signals compatible with Bently Nevada 3300/3500 series drivers. No additional signal conditioner is required when using standard Bently Nevada probe systems. Verify probe driver output range matches A6220 input specification.
Q: What is the functional equivalent of the A6220 if I am migrating from EMERSON Ovation to a different DCS platform?
A: For cross-platform migrations, there is no single plug-and-play equivalent — you will need a vibration monitoring module native to your new DCS platform (e.g., Bently Nevada 3500/40M for standalone monitoring, or a platform-specific analog input module with custom engineering). Konmask can assist with cross-brand substitute selection and interface design. Contact us at support@konmask.com.
