Genuine ABB ACH580-01-096A-4 LV AC Wall-Mounted Drive | ACH580 Series – Verified Source
The ABB ACH580-01-096A-4 is a low-voltage AC wall-mounted variable frequency drive from ABB’s industry-leading ACH580 series, purpose-built for HVAC and building automation applications. As a verified distributor at Konmask.com, we supply this drive with full traceability, ensuring your facility receives a genuine, performance-tested unit ready for immediate integration.
This product is sourced directly through authorized supply channels. Every unit we ship undergoes our internal verification process before dispatch — giving procurement engineers and facility managers the confidence they need when sourcing critical automation components globally.
Technical Specifications
- Part Number / SKU: ACH580-01-096A-4
- Brand: ABB
- Series: ACH580
- Drive Type: LV AC Wall-Mounted Variable Frequency Drive (VFD)
- Output Current: 96 A
- Voltage Rating: 380–480 V (3-phase, 50/60 Hz)
- Power Rating: 45 kW / 60 HP (typical at 400 V)
- Enclosure: IP21 / UL Type 1 (wall-mount)
- Control Method: Scalar (V/Hz) and Vector control
- Communication: Modbus RTU, BACnet MS/TP, N2 (HVAC protocols)
- Weight: ~9 kg (unit only)
- Certifications: CE, UL, cUL, RoHS
Note: Specifications are based on ABB published datasheets. Always verify with the official ABB ACH580 product manual for your specific installation requirements.
Our 4-Step Quality Verification Process
- Source Authentication — We verify the supply chain origin of every unit, cross-referencing manufacturer batch codes and packaging integrity before acceptance into our inventory.
- Visual & Physical Inspection — Each drive is inspected for physical damage, label accuracy, connector integrity, and correct model identification against ABB’s official part numbering system.
- Documentation Review — We confirm that accompanying documentation (CE declarations, serial number records) matches the unit and is consistent with ABB’s published specifications.
- Pre-Shipment Check — Before dispatch, units are re-inspected, securely packaged with anti-static and moisture protection, and assigned a shipment tracking reference for full end-to-end visibility.
Key Features & Benefits
- HVAC-Optimized Control: Built-in PID control, sleep/wake functions, and fire mode for life-safety applications — reducing engineering time on site.
- Energy Savings: ABB’s energy optimizer algorithm continuously adjusts motor flux to minimize energy consumption, delivering measurable kWh savings in fan and pump applications.
- Built-In EMC Filter: Integrated Class C2 EMC filter reduces installation complexity and ensures compliance with EN 61800-3 in most industrial environments.
- Native BACnet & Modbus Support: Seamless integration with building management systems (BMS) without additional gateway hardware.
- Safe Torque Off (STO): IEC 61508 SIL 2 / EN 13849-1 PLd certified safety function for machinery directive compliance.
- Compact Wall-Mount Design: Space-efficient footprint suitable for electrical rooms, rooftop AHUs, and panel installations.
Typical Applications
- HVAC air handling units (AHU) and fan coil units
- Chilled water pumps and condenser water pumps
- Cooling tower fans and exhaust ventilation systems
- Commercial building automation and energy management
- Industrial process pumps and compressors
- Water treatment and wastewater pumping stations
Compatible System Components
- Control Panels & I/O Modules: ABB ACH580 fieldbus adapter modules (FBAP series) for PROFIBUS, EtherNet/IP, PROFINET
- Brake Choppers: ABB NBRA-6xx series dynamic braking units for high-inertia loads
- Input Chokes: ABB CHK series line reactors for harmonic mitigation
- Output Filters: ABB dU/dt filters for long cable runs (>100 m)
- Control Panels: ABB ACS-AP-I and ACS-AP-W assistant control panels
- PLC Integration: Compatible with ABB AC500, Siemens S7, Allen-Bradley ControlLogix via standard fieldbus protocols
Global Sourcing & Shipping Capabilities
Konmask.com operates as a global industrial automation parts supplier serving customers across Europe, Southeast Asia, the Middle East, and the Americas. We ship the ABB ACH580-01-096A-4 worldwide with the following capabilities:
- Lead Time: Typically 3–7 business days for in-stock units; longer lead times quoted for special sourcing requests
- Shipping Methods: DHL Express, FedEx International Priority, sea freight for bulk orders
- Export Documentation: Commercial invoice, packing list, and certificate of origin provided as standard
- Minimum Order: 1 unit (no minimum order quantity)
- Bulk Pricing: Volume discounts available — contact us for project pricing on orders of 5+ units
Certifications & Compliance Statement
The ABB ACH580-01-096A-4 carries the following certifications as issued by ABB Group:
- CE Marking — Compliant with EU Low Voltage Directive (2014/35/EU) and EMC Directive (2014/30/EU)
- UL / cUL Listed — Recognized for use in North American markets
- RoHS Compliant — Restriction of Hazardous Substances Directive 2011/65/EU
- IEC 61800-5-1 — Safety requirements for adjustable speed electrical power drive systems
Konmask.com does not manufacture or modify any ABB products. All certifications are as issued by ABB and apply to genuine, unmodified units only.
How to Order
- Submit an Inquiry: Contact us via email at support@konmask.com or via the inquiry form on this page with your required quantity and delivery destination.
- Receive a Quote: Our team will respond within 1 business day with pricing, availability, and estimated lead time.
- Confirm & Pay: We accept T/T (bank transfer), PayPal, and other payment methods — confirmed upon inquiry.
- Shipment & Tracking: Your order is dispatched with full tracking information and export documentation.
Authenticity & Trust FAQ
- Q: Are the units you supply genuine ABB products?
- A: Yes. All units supplied by Konmask.com are genuine ABB products sourced through verified supply channels. We do not sell counterfeit, refurbished-as-new, or modified units.
- Q: Can you provide documentation to confirm authenticity?
- A: We provide available documentation including serial number records and packaging photos upon request. For formal factory certificates of conformity, please contact ABB directly with the serial number we supply.
- Q: What is your return policy if the unit is faulty on arrival?
- A: We offer a DOA (Dead on Arrival) replacement policy. If a unit is found to be non-functional upon receipt, contact us within 7 days with photographic evidence and we will arrange a replacement or refund.
- Q: Do you offer warranty on ABB drives?
- A: Units are supplied with the remaining manufacturer warranty where applicable. Extended warranty arrangements can be discussed — please inquire at the time of order.
- Q: Can you source other ABB ACH580 variants not listed on your site?
- A: Yes. We can source the full ABB ACH580 range including different power ratings, enclosure types, and option codes. Send us your part number and we will confirm availability.
