ABB C1900/0363/0360A — Control Board Data Recorder | AC500 / DCS Platform
Engineering Background
The ABB C1900/0363 (also referenced as C1900/0363/0360A) is a dedicated control board and data recorder module designed for integration within ABB’s distributed control system (DCS) and AC500 automation platform architectures. It serves as a critical data acquisition and process control interface in high-reliability industrial environments where signal integrity and continuous uptime are non-negotiable.
Product Positioning
Targeted at process industries including power generation, oil & gas, chemical processing, and heavy manufacturing, this module bridges field-level instrumentation with supervisory control layers. Procurement engineers specify the C1900/0363/0360A when replacing legacy ABB control boards or expanding existing DCS infrastructure without full system migration.
Complete Technical Specifications
| Part Number | C1900/0363 / C1900/0363/0360A |
| Manufacturer | ABB Ltd. |
| Module Type | Control Board / Data Recorder |
| Platform Compatibility | ABB DCS / AC500 Series |
| Form Factor | PCB Module (rack/panel mount) |
| Operating Temperature | 0°C to +60°C (standard industrial range) |
| Storage Temperature | -25°C to +85°C |
| Power Supply | Per ABB DCS backplane specification |
| Communication Interface | ABB proprietary DCS bus / internal backplane |
| Data Recording Function | Process variable logging, event capture, fault recording |
| Approvals / Standards | CE, IEC 61131-compatible platform |
| Weight (approx.) | ~100 g |
| Condition Available | New / Refurbished / Tested surplus |
Note: Detailed electrical parameters are available upon request. Contact support@konmask.com for full datasheet.
Proven Application Environments
- Power Generation: Turbine control systems, boiler management, and grid synchronization panels using ABB DCS infrastructure.
- Oil & Gas: Upstream SCADA integration, pipeline monitoring, and compressor station automation.
- Chemical & Petrochemical: Continuous process control loops requiring high-frequency data recording and fault logging.
- Pulp & Paper / Water Treatment: Multi-loop process controllers with legacy ABB DCS backbones.
- Heavy Manufacturing: CNC-adjacent automation cells and robotic workcell supervisory control.
Engineering Advantages
- Drop-in Compatibility: Designed as a direct replacement for existing C1900/0363 installations — no firmware re-flashing or rack modification required in standard configurations.
- Integrated Data Recording: Onboard data recorder function eliminates the need for external logging hardware, reducing panel footprint and wiring complexity.
- High MTBF Design: ABB industrial-grade components rated for continuous 24/7 operation in demanding environments.
- Backward Compatibility: Supports legacy ABB DCS signal protocols, protecting existing infrastructure investment.
- Reduced Downtime Risk: Stocking a spare C1900/0363/0360A board provides immediate swap-out capability, minimizing unplanned production stops.
System Architecture & Signal Flow
The C1900/0363/0360A operates as a sub-module within the ABB DCS control rack. Field signals (analog/digital I/O) are routed through the backplane to this board, where the control logic executes process algorithms and simultaneously records key process variables and system events to onboard memory. Recorded data is accessible via the DCS engineering workstation for trend analysis, alarm review, and regulatory compliance reporting.
The board interfaces upstream with the DCS controller CPU module and downstream with I/O termination assemblies, maintaining deterministic scan cycle performance consistent with ABB’s real-time control architecture.
Sourcing & Quality Verification
- Source Traceability: All units sourced from authorized distributors, OEM surplus channels, or certified refurbishers with documented chain of custody.
- Incoming Inspection: Visual inspection, board-level continuity check, and functional power-on test performed prior to dispatch.
- Packaging: Anti-static ESD bag + foam-lined carton; humidity indicator card included for long-haul shipments.
- Warranty: 90-day replacement warranty on all tested units. Extended warranty available upon request.
- Counterfeit Mitigation: Serial number and date code verification against ABB manufacturing records where available.
Procurement Process
- Submit RFQ: Contact support@konmask.com with your required quantity, delivery timeline, and acceptable condition (new / refurbished / tested).
- Quotation: Receive itemized quote with unit price, lead time, and shipping options within 1 business day.
- Order Confirmation: Purchase order accepted via email. Pro-forma invoice issued for prepayment or net terms (qualified accounts).
- Quality Check & Dispatch: Unit tested, photographed, and shipped with packing list and test report.
- After-Sales Support: Technical assistance available for installation verification and compatibility confirmation.
Technical FAQ
Q: Is C1900/0363 the same as C1900/0363/0360A?
A: Yes — C1900/0363/0360A is the full ABB part number including revision suffix. Both designations refer to the same control board assembly. Always cross-reference your existing board’s label before ordering.
Q: Can this board be used in non-ABB systems?
A: No. The C1900/0363 is designed exclusively for ABB DCS backplane architectures. It is not compatible with third-party PLC racks or generic industrial controllers.
Q: What is the typical lead time?
A: In-stock units ship within 3–5 business days. For sourced/refurbished units, lead time is typically 2–4 weeks depending on availability.
Q: Do you provide a test report?
A: Yes. A functional test report is included with every refurbished unit. New surplus units include original ABB documentation where available.
Q: Can you supply multiple units for a plant-wide spare parts program?
A: Yes. Volume pricing is available for orders of 3+ units. Contact us for a blanket order arrangement.
