ABB CI543 3BSE010699R1 PROFIBUS DP Communication Interface – AC 800M Series
Imagine a critical production line where your AC 800M controller loses its ability to communicate with field devices — variable frequency drives go silent, remote I/O stations become unreachable, and the entire PROFIBUS DP network collapses. Without the CI543 communication interface module, your distributed control architecture is reduced to an isolated island, unable to exchange real-time process data. Unplanned downtime follows, and every minute costs thousands. The ABB CI543 3BSE010699R1 is the essential bridge that keeps your automation network alive.
The CI543 is ABB’s dedicated PROFIBUS DP master/slave communication interface designed specifically for the AC 800M controller platform — ABB’s flagship mid-to-high-end process automation controller used across oil & gas, power generation, pulp & paper, and chemical industries worldwide. Within the AC 800M ecosystem, the CI543 occupies a critical role: it extends the controller’s fieldbus reach to PROFIBUS DP networks at up to 12 Mbit/s, enabling seamless integration with thousands of PROFIBUS-compatible field devices. Its 3BSE010699R1 part number is the globally recognized ordering reference, stocked and sourced by automation engineers across Europe, Asia, and the Americas.
Technical Specifications
- Part Number: CI543 / 3BSE010699R1
- Brand: ABB
- Series: AC 800M
- Module Type: PROFIBUS DP Communication Interface
- Fieldbus Protocol: PROFIBUS DP (EN 50170 / IEC 61158)
- Communication Speed: Up to 12 Mbit/s
- Operating Mode: DP Master (Class 1) / DP Slave
- Connector Type: 9-pin D-Sub (RS-485)
- Power Supply: Supplied via AC 800M controller backplane
- Operating Temperature: 0°C to +55°C
- Storage Temperature: -40°C to +70°C
- Humidity: 5% to 95% RH (non-condensing)
- Certifications: CE, UL, cUL
- Weight: Approx. 300 g
- Compatible Controller: ABB AC 800M (PM851, PM856, PM860, PM861, PM864, PM866 series)
Note: All specifications are based on ABB official documentation. Konmask.com does not fabricate or alter technical parameters.
Key Features & Benefits
- High-Speed PROFIBUS DP: Supports full 12 Mbit/s data rate for time-critical process control loops.
- Dual Operating Modes: Functions as both DP Master (Class 1) and DP Slave, providing maximum network topology flexibility.
- Seamless AC 800M Integration: Plug-in module design with direct backplane connection — no external power wiring required.
- Robust Industrial Design: Engineered for 24/7 continuous operation in harsh industrial environments.
- Wide Device Compatibility: Connects to any PROFIBUS DP-compliant field device including drives, valves, remote I/O, and analyzers.
- Deterministic Communication: Guarantees cycle-time consistency critical for process automation applications.
- Hot-Swap Capable: Supports module replacement without full controller shutdown (subject to system configuration).
Industry & Equipment Applications
- Oil & Gas: Offshore platform DCS networks, pipeline SCADA integration, compressor control systems.
- Power Generation: Turbine control, boiler management, substation automation with PROFIBUS field devices.
- Pulp & Paper: Distributed drive control, consistency measurement, and process variable acquisition.
- Chemical & Petrochemical: Reactor control, batch processing, and safety instrumented system (SIS) integration.
- Water & Wastewater: Pump station automation, SCADA-linked remote I/O networks.
- Mining & Minerals: Conveyor drive networks, crusher control, and plant-wide DCS expansion.
System Integration & Compatible Parts
The CI543 3BSE010699R1 is designed to work within the ABB AC 800M controller family. Commonly paired components include:
- Controllers: PM856 (3BSE018161R1), PM860 (3BSE042240R1), PM864 (3BSE018100R1), PM866 (3BSE050198R1)
- Power Supply Units: SD821 (3BSC610037R1), SD822 (3BSC610038R1)
- Communication Modules: CI854 (PROFINET), CI855 (IEC 61850), CI856 (Modbus TCP)
- I/O Modules: AI810, AO810, DI810, DO810 series
- PROFIBUS Field Devices: ABB ACS880 drives, TZID-C positioners, FieldIT transmitters
Contact Konmask.com for cross-reference assistance and system compatibility verification.
Our Quality Assurance Process
- Source Verification: All ABB modules are sourced from authorized distributors or directly from decommissioned OEM systems with full traceability.
- Visual Inspection: Each unit is inspected for physical damage, corrosion, and component integrity before listing.
- Functional Testing: Where applicable, modules undergo power-on and communication link verification.
- Secure Packaging: Anti-static ESD packaging with foam cushioning for safe international transit.
- Documentation: Original ABB labels and part numbers preserved; no remarking or relabeling.
How to Order
- Submit an inquiry via the Contact / RFQ form on this page or email support@konmask.com.
- Provide your required quantity, delivery timeline, and destination country.
- Our team will respond within 24 business hours with availability, lead time, and a formal quotation.
- Upon order confirmation, we arrange secure export packaging and international logistics.
- Tracking information is provided upon shipment.
Why Choose Konmask.com?
- ✅ Specialized in Industrial Automation: Focused exclusively on PLC, DCS, and fieldbus components — not a general electronics marketplace.
- ✅ Global B2B Export Experience: Serving engineering firms, system integrators, and MRO buyers across 50+ countries.
- ✅ Competitive Pricing: Direct sourcing relationships enable pricing advantages over traditional distribution channels.
- ✅ Fast Response: Dedicated technical sales team with deep ABB product knowledge.
- ✅ Reliable Logistics: DHL, FedEx, and freight forwarding options for all order sizes.
- ✅ After-Sales Support: Technical guidance on installation, compatibility, and system integration.
Frequently Asked Questions
Q: Is the CI543 3BSE010699R1 compatible with all AC 800M controllers?
A: The CI543 is compatible with the AC 800M controller family including PM851, PM856, PM860, PM861, PM864, and PM866 variants. Always verify your specific controller firmware version against ABB’s compatibility matrix.
Q: Can the CI543 operate as both a PROFIBUS master and slave?
A: Yes. The CI543 supports both DP Master (Class 1) and DP Slave operating modes, configurable via ABB Control Builder software.
Q: Do you supply new or refurbished units?
A: Konmask.com supplies both new-in-box and tested used units depending on availability. Condition is clearly stated in the quotation. All units pass our quality inspection process.
Q: What is the lead time for the CI543 3BSE010699R1?
A: Lead time varies by stock availability. In-stock units typically ship within 3–5 business days. Contact us for current availability.
Q: Can you provide an export declaration or certificate of origin?
A: Yes. We provide standard export documentation including commercial invoice, packing list, and certificate of origin upon request.
Q: What warranty is offered?
A: We offer a 90-day warranty against defects in materials and workmanship for all tested units. Terms are detailed in the quotation.
