ABB CI801 3BSE022366R1 Profibus DP Communication Interface Module – AC 800M Series
When a Profibus DP communication link fails in a process control environment, the consequences cascade instantly — field devices go silent, operator stations lose visibility, and production lines halt without warning. In high-stakes industries such as oil & gas, power generation, and chemical processing, even minutes of unplanned downtime translate into significant financial loss and safety risk. The ABB CI801 3BSE022366R1 is the purpose-built solution that keeps this communication backbone alive, providing a reliable, high-speed Profibus DP interface that your AC 800M controller depends on.
The CI801 (part number 3BSE022366R1) is ABB’s dedicated Profibus DP master/slave communication interface module within the AC 800M controller platform — one of the most widely deployed DCS architectures in global process industries. Designed to integrate seamlessly with the PM8xx processor modules, the CI801 extends the AC 800M’s fieldbus reach to hundreds of Profibus DP slave devices, making it a cornerstone component in distributed control architectures across refineries, power plants, pulp & paper mills, and pharmaceutical facilities worldwide.
Technical Specifications
- Part Number: CI801 / 3BSE022366R1
- Manufacturer: ABB
- Series: AC 800M (Advant Controller 800M)
- Module Type: Profibus DP Communication Interface Module
- Fieldbus Protocol: Profibus DP (EN 50170 / IEC 61158)
- Communication Role: DP Master (Class 1 & Class 2) / DP Slave
- Connector Type: 9-pin D-Sub (DB9)
- Baud Rate: Up to 12 Mbit/s
- Max Slave Devices: Up to 125 DP slaves per segment (with repeaters)
- Power Supply: Supplied via AC 800M backplane
- Operating Temperature: 0°C to +55°C
- Storage Temperature: -40°C to +70°C
- Humidity: 5% to 95% RH (non-condensing)
- Weight: Approx. 260 g
- Certifications: CE, UL (refer to ABB datasheet for full listing)
- Compatible Software: ABB Control Builder M
Key Features & Benefits
- Dual-Role Flexibility: Operates as both DP Master and DP Slave, enabling versatile network topologies in complex DCS architectures.
- High-Speed Communication: Supports Profibus DP baud rates up to 12 Mbit/s, ensuring low-latency data exchange between the AC 800M controller and field instruments.
- Hot-Swap Capable: Designed for insertion and removal without powering down the controller, minimizing maintenance downtime in live production environments.
- Seamless AC 800M Integration: Plug-and-play compatibility with PM851, PM856, PM860, PM861, and PM866 processor modules via the AC 800M backplane.
- Robust Industrial Design: Engineered to withstand harsh industrial environments including vibration, EMI, and wide temperature ranges.
- Diagnostics & Status LEDs: Onboard LED indicators provide real-time communication status and fault diagnostics, simplifying troubleshooting.
- GSD File Support: Standard Profibus GSD file support ensures compatibility with third-party DP master configuration tools.
Industry & Equipment Applications
- Oil & Gas: Upstream wellhead control, midstream pipeline SCADA, downstream refinery DCS integration with Profibus-enabled field transmitters and valve positioners.
- Power Generation: Turbine control systems, boiler management, and substation automation using Profibus DP for I/O expansion.
- Chemical & Petrochemical: Reactor control loops, batch processing systems, and safety instrumented systems (SIS) interfacing.
- Pulp & Paper: Distributed drive control and process variable monitoring via Profibus DP networks.
- Pharmaceutical & Food & Beverage: GMP-compliant process control with validated Profibus DP communication links.
- Water & Wastewater: Pump station automation and SCADA integration with Profibus DP field devices.
System Integration & Compatible Parts
The CI801 3BSE022366R1 is designed to operate within the ABB AC 800M ecosystem. Commonly paired components include:
- Processor Modules: PM851-1 (3BSE018168R1), PM856-1 (3BSE018100R1), PM860-1 (3BSE018100R1), PM861A-1 (3BSC050197R1), PM866-1 (3BSE050198R1)
- Power Supply Units: SS822 (3BSC610065R1), SS823 (3BSC610066R1)
- Communication Modules: CI840A (DeviceNet), CI854A (PROFIBUS DP redundant), CI857 (Industrial Ethernet)
- Backplane / Rack: TB820V2 (3BSE013208R1), TB840A (3BSE037760R1)
- Profibus Cables & Connectors: Standard Profibus DP shielded twisted-pair cable (Type A, IEC 61158)
If you need assistance identifying compatible modules for your existing AC 800M system, our technical team is available to support your BOM review.
Our Quality Assurance Process
At Konmask.com, every ABB CI801 3BSE022366R1 module undergoes a rigorous multi-stage inspection before shipment:
- Visual Inspection: PCB, connectors, and housing checked for physical damage, corrosion, or counterfeit indicators.
- Functional Verification: Power-on test and communication link verification where applicable.
- Authenticity Check: Part number, date code, and manufacturer markings verified against ABB documentation.
- ESD-Safe Packaging: All modules are packed in anti-static bags with foam cushioning to prevent transit damage.
- Traceability: Each unit is logged with inspection records available upon request.
How to Order
- Submit your inquiry via the Contact Us form or email [email protected].
- Provide your required quantity, delivery timeline, and destination country.
- Receive a formal quotation with lead time and shipping options within 24 business hours.
- Confirm the order and complete payment via your preferred method (T/T, PayPal, or other agreed terms).
- Track your shipment with the provided logistics information.
Phone / WhatsApp: +0086 19859288691 | Email: [email protected]
Why Choose Konmask.com?
- ✅ Specialized in Industrial Automation: Focused exclusively on PLC, DCS, and automation components — not a generalist marketplace.
- ✅ Global Sourcing Network: Access to genuine ABB modules from verified supply channels worldwide.
- ✅ Fast Response: Quotations within 24 hours; urgent orders accommodated.
- ✅ Technical Support: Pre-sales compatibility consultation and post-sales integration guidance from experienced engineers.
- ✅ Flexible MOQ: Single-unit orders accepted — ideal for emergency replacements and MRO procurement.
- ✅ Secure Export Packaging: ESD-safe, double-boxed packaging with full documentation for international shipments.
Frequently Asked Questions
Q: Is the CI801 3BSE022366R1 compatible with the AC 800M PM866 processor?
A: Yes. The CI801 is compatible with all AC 800M processor modules including PM851, PM856, PM860, PM861, and PM866, when installed in the same AC 800M rack via the backplane.
Q: Can the CI801 operate as both a Profibus DP master and slave?
A: Yes. The CI801 supports both DP Master (Class 1 and Class 2) and DP Slave modes, configurable via ABB Control Builder M software.
Q: What is the maximum number of Profibus DP slaves the CI801 can manage?
A: Up to 125 DP slave devices per Profibus segment (with repeaters). Without repeaters, up to 32 devices per segment.
Q: Do you supply new, refurbished, or used modules?
A: We supply both new (factory-sealed) and professionally tested surplus/refurbished units. The condition is clearly stated in your quotation. All units pass our QA inspection regardless of condition.
Q: How long does shipping take?
A: Standard international shipping takes 5–15 business days depending on destination. Express DHL/FedEx options are available for urgent requirements.
Q: Can you provide a certificate of conformance or test report?
A: Yes. Inspection records and certificates of conformance are available upon request for all orders.
