ABB CT302A GJR2167200R0001 – PC Board Module Control Card | AC500 / DCS Platform
Engineering Background
The ABB CT302A (part number GJR2167200R0001) is a precision-engineered PC Board Module Control Card designed for deployment within ABB’s industrial automation and Distributed Control System (DCS) architecture. Built to ABB’s stringent manufacturing standards, this control card serves as a critical signal processing and control interface node within complex automation topologies.
Product Positioning
Targeted at maintenance engineers, system integrators, and procurement specialists managing ABB-based control infrastructure, the CT302A delivers a direct OEM-equivalent replacement path with full backward compatibility. Konmask.com sources this module through verified industrial supply channels, ensuring authenticity and traceability for mission-critical applications.
Complete Technical Specifications
| Manufacturer | ABB |
| Part Number / Model | CT302A |
| Reference Number | GJR2167200R0001 |
| Module Type | PC Board Module Control Card |
| Platform Compatibility | ABB AC500 / DCS Series |
| Form Factor | PCB Module (plug-in card) |
| Net Weight | 140 g |
| Operating Temperature | 0°C to +60°C (typical industrial range) |
| Storage Temperature | -40°C to +85°C |
| Humidity | 5% to 95% RH, non-condensing |
| Compliance | CE, RoHS (subject to production batch) |
| Condition | New / Refurbished (specify at inquiry) |
Proven Application Environments
- Power generation and grid control systems
- Oil & gas upstream/downstream process automation
- Chemical and petrochemical plant DCS networks
- Pulp, paper, and continuous manufacturing lines
- Water treatment and utility SCADA infrastructure
- Marine and offshore automation panels
- Railway traction and signaling control cabinets
Engineering Advantages
- OEM Authenticity: Sourced through traceable industrial channels with documentation available on request.
- Drop-in Replacement: Direct form-fit-function substitute for installed CT302A units — no firmware re-flashing required in standard configurations.
- Reduced Downtime: In-stock availability enables same-week dispatch, minimizing unplanned production stoppages.
- Quality Screened: Each unit undergoes visual inspection and functional verification prior to shipment.
- Long-term Supportability: Konmask maintains buffer stock of legacy ABB modules to support aging installed bases beyond OEM EOL dates.
System Architecture & Signal Flow
The CT302A functions as a control-plane interface card within the ABB DCS backplane. It manages inter-module communication, I/O signal conditioning, and control loop execution handoff between the processor module and field I/O termination assemblies. Integration follows standard ABB rack-and-slot addressing conventions; no custom wiring modifications are required for standard replacement scenarios.
Note: For system-specific integration diagrams, refer to ABB document GJR2167200R0001 installation manual or contact Konmask technical support.
Sourcing & Quality Verification
- All modules are inspected upon receipt and prior to dispatch.
- Serialization and date codes are recorded for traceability.
- Certificate of conformance (CoC) available upon request for regulated industries.
- Anti-counterfeit screening applied: component markings, PCB layer verification, and functional bench test where applicable.
- Packaging: ESD-safe anti-static bag + foam-lined carton for transit protection.
Procurement Process
- Confirm compatibility — provide your existing part number, rack type, and firmware revision to our technical team.
- Request a quotation — contact support@konmask.com or call +0086 19859288691 for volume pricing and lead time confirmation.
- Place order — via this product page or through a formal PO for B2B accounts.
- Dispatch & tracking — orders are processed within 1–2 business days; tracking number provided upon shipment.
- After-sales support — 12-month warranty on new units; technical assistance available throughout the product lifecycle.
