ABB DI814 3BUR001454R1 Digital Input Module | Replacement, Equivalent & Selection Guide
The ABB DI814 (Part No. 3BUR001454R1) is a high-density digital input module designed for ABB’s AC 800M / S800 I/O distributed control system. It provides reliable, noise-immune digital signal acquisition for industrial process automation environments. This page serves as a comprehensive selection guide covering technical specifications, compatible replacements, equivalent alternatives, and ordering information.
Technical Specifications
- Manufacturer: ABB
- Part Number: 3BUR001454R1
- Model: DI814
- Module Type: Digital Input (DI)
- Number of Channels: 8 channels
- Input Voltage: 24 V DC
- Input Signal Type: Discrete / Digital
- Logic Level (High): ≥ 15 V DC
- Logic Level (Low): ≤ 5 V DC
- Isolation: Galvanic isolation between field and system bus
- Communication Interface: S800 I/O bus
- Compatible Controller: ABB AC 800M (PM851, PM856, PM860, PM861, PM864, PM866)
- Mounting: DIN rail via S800 I/O carrier (TB820, TB840)
- Operating Temperature: 0 °C to +55 °C
- Storage Temperature: -40 °C to +70 °C
- Humidity: 5–95% RH (non-condensing)
- Weight: Approx. 160 g
- Certifications: CE, UL, cUL
- Product Status: Active / Available
Compatible Replacement & Equivalent Models
If the ABB DI814 3BUR001454R1 is unavailable or you are evaluating alternatives, the following models offer compatible or equivalent functionality:
- ABB DI810 (3BSE008508R1) – 8-channel 24 V DC DI, same S800 bus, direct functional equivalent with slightly different form factor
- ABB DI811 (3BSE008552R1) – 8-channel 24 V DC DI, compatible with same carrier modules
- ABB DI820 (3BSE008544R1) – 16-channel 24 V DC DI, suitable when higher channel density is required
- ABB DI821 (3BSE008566R1) – 16-channel 120 V AC DI, for AC signal environments
- ABB DI830 (3BSE013210R1) – 16-channel 24 V DC DI with HART support
- Siemens 6ES7321-1BH02-0AA0 – S7-300 DI module, cross-platform alternative for Siemens-based systems
- Rockwell 1756-IB16 – Allen-Bradley ControlLogix 16-channel 24 V DC DI, for Rockwell migration projects
Note: Cross-brand replacements require engineering review for bus compatibility, I/O addressing, and software configuration.
Why Choose the Original ABB DI814 3BUR001454R1
- Guaranteed Compatibility: Plug-and-play with ABB AC 800M / S800 I/O systems — no firmware or configuration changes required
- Proven Reliability: Designed for continuous 24/7 operation in demanding process industries
- Galvanic Isolation: Protects the control system from field-side voltage transients and ground loops
- Minimal Downtime: Hot-swap capable on supported carrier modules — replace without shutting down the system
- Long Service Life: ABB’s industrial-grade components rated for extended lifecycle in harsh environments
- OEM Support: Full ABB documentation, firmware updates, and technical support available
Typical Applications
- Oil & gas process control (upstream, midstream, downstream)
- Chemical and petrochemical plant automation
- Power generation and utilities (thermal, hydro, nuclear auxiliary systems)
- Pulp and paper manufacturing
- Water and wastewater treatment facilities
- Pharmaceutical and food & beverage production lines
- Marine and offshore platform control systems
- Mining and minerals processing
System Compatibility
The DI814 is designed exclusively for the ABB S800 I/O system and is compatible with the following components:
- Controllers: AC 800M — PM851, PM856, PM860, PM861, PM864, PM866
- Carrier Modules: TB820V2, TB840A (Modulebus optical), TB807, TB811, TB815
- Communication: Modulebus (optical fiber or copper) via CI801, CI810, CI820, CI830, CI840
- Engineering Tool: ABB Control Builder M (CBM) Professional / Plus
- Not compatible with: ABB Freelance, ABB 800xA Symphony Plus, or third-party DCS platforms without gateway hardware
Selection Guide
Use the following criteria to confirm the DI814 is the right module for your application:
- Signal Type: Do you need to read discrete ON/OFF signals (limit switches, pushbuttons, relay contacts, proximity sensors)? → DI814 ✓
- Voltage Level: Are your field devices 24 V DC? → DI814 ✓ | If 120 V AC → consider DI821
- Channel Count: Do you need 8 channels per module? → DI814 ✓ | If 16 channels → consider DI820 or DI830
- HART Support: Not required for digital inputs — DI814 is appropriate
- Controller Platform: ABB AC 800M with S800 I/O bus? → DI814 ✓
- Redundancy: For redundant I/O, pair with TB840A carrier and CI840 communication interface
- Environment: Standard industrial (0–55 °C, non-condensing) → DI814 ✓ | Extreme environments may require additional enclosure protection
Quality Assurance & Sourcing
- Authenticity: All ABB modules supplied by Konmask.com are sourced from authorized distributors or verified surplus channels with full traceability
- Inspection: Each unit undergoes visual inspection, label verification, and functional pre-shipment checks
- Packaging: Original ABB anti-static packaging preserved where available; ESD-safe repackaging applied otherwise
- Warranty: 12-month warranty against manufacturing defects; DOA replacement within 30 days
- Documentation: ABB datasheet, wiring diagram, and installation manual available upon request
- Certifications on file: CE Declaration of Conformity available for customs and compliance purposes
How to Order
- Confirm your part number: ABB DI814 / 3BUR001454R1
- Verify quantity and lead time requirements with our team
- Submit your inquiry via email or phone (see contact below)
- Receive proforma invoice with shipping options (DHL, FedEx, sea freight)
- Payment processed — order dispatched within 1–3 business days for in-stock units
For urgent requirements or bulk orders (>5 units), please contact us directly for priority pricing and expedited shipping.
Replacement & Compatibility FAQ
Q: Can I replace DI814 with DI810 directly?
A: Yes, in most cases. Both are 8-channel 24 V DC DI modules on the S800 bus. Verify the carrier module and I/O address configuration in Control Builder M before swapping.
Q: Is DI814 compatible with ABB 800xA?
A: Yes. The AC 800M controller running S800 I/O (including DI814) integrates fully with ABB 800xA as the supervisory DCS layer.
Q: Can DI814 be used with third-party PLCs?
A: No. DI814 communicates exclusively via the ABB Modulebus protocol. Integration with Siemens, Rockwell, or other PLCs requires a gateway or migration to a compatible I/O platform.
Q: What is the difference between DI814 and DI820?
A: DI820 offers 16 channels vs. DI814’s 8 channels. Both operate at 24 V DC on the S800 bus. Choose DI820 when higher I/O density is needed to reduce module count.
Q: Do you supply new, refurbished, or used units?
A: We supply new-in-box (NIB), factory-refurbished (FR), and tested-used (TU) units. Condition is clearly stated on each listing. Contact us to confirm current stock condition.
Q: Can you provide a certificate of conformity or test report?
A: Yes. Documentation packages including CoC, test reports, and ABB datasheets are available upon request for quality-critical procurement.
