Robot Automation I/O Solution – ABB DQC1030 (3HAC058663-001) | DSQC Series
The ABB DQC1030, part number 3HAC058663-001, is a Digital Base I/O Module engineered for ABB IRC5 robot controllers. It serves as the foundational digital signal interface between the robot controller and external automation devices, enabling precise, high-speed digital I/O communication in demanding industrial environments.
Where This Product Is Used
The DQC1030 is specified by automation engineers across a wide range of industries and applications:
- Automotive Body-in-White (BIW) Lines – Coordinates digital signals between IRC5 controllers and welding guns, clamps, and conveyors on high-throughput assembly lines.
- Palletizing & Material Handling – Interfaces with sensors, grippers, and conveyor PLCs to manage pick-and-place cycles in logistics and warehousing automation.
- Arc & Spot Welding Cells – Provides reliable I/O handshaking between the robot and welding power sources, safety relays, and fixture controllers.
- Machine Tending & CNC Integration – Manages door-open/close signals, part-present detection, and cycle-start commands between the IRC5 and CNC machines.
- Painting & Coating Lines – Controls atomizer triggers, color-change valves, and conveyor tracking signals in automotive paint shops.
- Electronics Assembly – Supports high-precision digital I/O for PCB handling, dispensing, and inspection robots in cleanroom environments.
Technical Specifications
- Part Number: 3HAC058663-001
- Model: DQC1030
- Series: DSQC / IRC5 I/O System
- Type: Digital Base I/O Module
- Compatible Controller: ABB IRC5 (Single Cabinet, Dual Cabinet, Panel Mounted)
- Communication Interface: DeviceNet / Internal IRC5 I/O Bus
- Digital Inputs: 16 channels (24 VDC, IEC 61131-2 Type 1/3)
- Digital Outputs: 16 channels (24 VDC, 0.5 A per channel)
- Supply Voltage: 24 VDC (±10%)
- Power Consumption: ≤ 10 W typical
- Operating Temperature: 0°C to +55°C
- Storage Temperature: -25°C to +70°C
- Protection Class: IP20
- Weight: ~900 g
- Certifications: CE, UL, RoHS
- Country of Origin: Sweden
Why Engineers Specify This Model
- Native IRC5 Integration – Plug-and-play compatibility with ABB’s IRC5 controller eliminates custom wiring and reduces commissioning time.
- High Channel Density – 16 DI + 16 DO in a compact module reduces cabinet footprint versus discrete relay solutions.
- Proven Field Reliability – DSQC-series modules are deployed in millions of robot installations globally, with documented MTBF exceeding 100,000 hours.
- RobotWare Software Support – Fully configurable via ABB RobotStudio and FlexPendant without additional licensing.
- Hot-Swap Capable – Supports replacement without full controller shutdown in supported IRC5 configurations, minimizing production downtime.
Complete System Bill of Materials
For a complete IRC5 digital I/O expansion, engineers typically specify:
- ABB DQC1030 (3HAC058663-001) – Digital Base I/O Module (this item)
- ABB DSQC652 (3HAC025917-001) – 24 VDC I/O Unit (supplementary channels)
- ABB DSQC643 (3HAC025338-001) – Analog I/O Module (for process signals)
- ABB 3HAC044075-001 – I/O Bus Cable (IRC5 internal)
- ABB 3HAC026254-001 – DeviceNet Cable Assembly
- Phoenix Contact or Weidmüller terminal blocks – Field wiring termination
Compliance & Industry Standards
- CE Marking – Compliant with EU Machinery Directive 2006/42/EC and EMC Directive 2014/30/EU
- UL Listed – Recognized for use in North American industrial control panels
- RoHS 2 (2011/65/EU) – Restriction of hazardous substances compliant
- IEC 61131-2 – Digital input/output signal compatibility
- ISO 10218-1 – Industrial robot safety standard alignment
- REACH Compliant – No SVHC substances above threshold
Quality Assurance & Sourcing
- Genuine ABB Parts – Sourced directly from ABB authorized distributors and certified supply chain partners.
- Pre-Shipment Inspection – Each unit undergoes visual inspection, label verification, and functional continuity check before dispatch.
- Traceability – Full lot traceability with ABB original packaging, serial number, and date code documentation available on request.
- Anti-Counterfeit Policy – Konmask.com maintains a zero-tolerance policy on non-genuine components. All parts include original ABB holographic labels where applicable.
- Warranty – 12-month warranty against manufacturing defects. Replacement or full refund guaranteed.
How to Source This Part
Konmask.com maintains ready stock of the ABB DQC1030 (3HAC058663-001) for immediate dispatch. We serve OEMs, system integrators, MRO procurement teams, and plant maintenance engineers globally.
- Request a Quote: Email support@konmask.com with your required quantity and delivery timeline.
- Bulk Orders: Volume pricing available for orders of 5+ units. Contact us for a tiered pricing schedule.
- Urgent Requirements: Same-day dispatch available for in-stock items. DHL Express, FedEx International Priority, and UPS Worldwide available.
- Phone / WhatsApp: +0086 19859288691 (Monday–Saturday, 09:00–18:00 CST)
Application-Specific FAQ
Q: Is the DQC1030 compatible with IRC5 Compact controllers?
A: Yes. The DQC1030 is compatible with all IRC5 variants including Single Cabinet, Dual Cabinet, Panel Mounted (IRCP), and IRC5 Compact, provided the controller runs RobotWare 5.x or later.
Q: Can this module replace a DSQC651 or DSQC652 in an existing installation?
A: The DQC1030 is a newer-generation base I/O module. Compatibility depends on your RobotWare version and I/O configuration. We recommend verifying your system’s I/O map in RobotStudio before substitution. Contact our technical team for guidance.
Q: What is the maximum number of DQC1030 modules per IRC5 controller?
A: ABB IRC5 supports up to 10 I/O units on the internal DeviceNet bus. The exact limit depends on total I/O node count and bus load. Refer to ABB Application Manual 3HAC050917-001 for detailed configuration limits.
Q: Do you provide the original ABB datasheet and wiring diagram?
A: Yes. Original ABB technical documentation is available upon request with every order. Contact support@konmask.com.
Q: What is the lead time for out-of-stock units?
A: Standard lead time for non-stocked units is 3–7 business days from our global supply network. Expedited sourcing available for urgent production requirements.
