ABB DSQC402 3HAC038768-0001 Panel Extension Cable 15m – IRC5 / S4C+ Robot Controller Series
Imagine a robotic welding cell mid-production when the operator panel suddenly loses communication with the IRC5 controller cabinet — no E-stop response, no teach pendant feedback, no safe override. Without the correct panel extension cable, the entire line halts, costing thousands per hour in downtime. The ABB DSQC402 panel extension cable (P/N 3HAC038768-0001, also cross-referenced as 3HNA014320001 and 1200SMB) is the OEM-specified interconnect that keeps the operator panel in continuous, noise-immune communication with the controller — making it an irreplaceable component in any ABB robot installation.
Within the ABB IRC5 and S4C+ controller ecosystem, the DSQC402 occupies a critical position as the primary panel-to-cabinet signal harness. At 15 meters, it provides the reach required for large-cell layouts where the controller cabinet is mounted remotely from the operator station. Globally, ABB IRC5 controllers power over 300,000 installed robot axes across automotive, electronics, food & beverage, and metal fabrication industries — and the DSQC402 cable is a standard service and replacement part stocked by system integrators worldwide.
Technical Specifications
- Part Number: 3HAC038768-0001
- Cross Reference: DSQC402 | 3HNA014320001 | 1200SMB
- Manufacturer: ABB Robotics
- Cable Type: Panel Extension Cable
- Cable Length: 15 meters (49.2 ft)
- Application: Operator panel to IRC5 / S4C+ controller cabinet
- Weight: 420 g
- Condition: New / Surplus New / Refurbished (specify on inquiry)
Key Features & Benefits
- OEM Specification: Manufactured to ABB’s exact electrical and mechanical tolerances — guaranteed plug-and-play compatibility with no signal degradation.
- 15-Meter Reach: Ideal for large robot cells where the controller cabinet is positioned away from the operator panel or safety fence.
- Multi-Reference Compatibility: Covers DSQC402, 3HAC038768-0001, 3HNA014320001, and 1200SMB — one cable, multiple ordering codes, zero confusion.
- Shielded Construction: Industrial-grade shielding protects signal integrity in high-EMI environments such as welding cells and servo drive cabinets.
- Rapid Replacement: Keyed connectors allow field replacement without tools or re-parameterization, minimizing MTTR.
- Durable Jacket: Flexible, oil-resistant outer jacket rated for continuous flexing in cable drag chains and conduit runs.
Industry & Equipment Applications
- Automotive Manufacturing: Spot welding, sealing, and assembly robots in body-in-white lines.
- Electronics & Semiconductor: Pick-and-place and dispensing robots requiring precise panel control.
- Metal Fabrication: Arc welding and plasma cutting cells with remote operator stations.
- Food & Beverage: Hygienic packaging and palletizing robots with wash-down environments.
- Logistics & Warehousing: High-throughput sorting and depalletizing systems.
- Compatible Controllers: ABB IRC5 Single Cabinet, IRC5 Compact, IRC5 Panel Mounted Controller, S4C+.
System Integration & Compatible Parts
The DSQC402 cable interfaces directly with the following ABB components. When planning a repair or upgrade, consider sourcing these complementary parts:
- ABB DSQC679 / 3HAC028357-001 — FlexPendant (Teach Pendant)
- ABB DSQC662 / 3HAC026254-001 — I/O Module
- ABB DSQC663 / 3HAC026253-001 — Analog I/O Module
- ABB DSQC1000 / 3HAC044168-001 — Main Computer Unit
- ABB DSQC609 / 3HAC14265-1 — Power Supply Unit
Our Quality Assurance Process
- Source Verification: All parts are sourced from ABB-authorized distributors, OEM surplus channels, or certified refurbishers.
- Visual & Dimensional Inspection: Each cable is inspected for connector integrity, jacket condition, and correct labeling before dispatch.
- Continuity & Insulation Test: Electrical continuity and insulation resistance are verified on every unit.
- Secure Packaging: Anti-static bags and foam-lined cartons protect connectors during international shipping.
- Traceability: Batch records and inspection reports available on request for MRO and OEM customers.
How to Order
- Submit an inquiry via the Contact / RFQ form on this page or email support@konmask.com.
- Provide your required quantity, preferred condition (new / surplus / refurbished), and delivery timeline.
- Receive a formal quotation with lead time and shipping options within 24 business hours.
- Confirm the order and receive proforma invoice for payment processing.
- Parts are dispatched with full documentation; tracking number provided upon shipment.
Why Choose Konmask.com?
- Industrial Automation Specialists: We focus exclusively on PLC, DCS, robot, and drive components — not a generalist marketplace.
- Global Sourcing Network: Access to OEM surplus, authorized distributor stock, and certified refurbished inventory worldwide.
- Technical Pre-Sales Support: Our engineers verify cross-references and compatibility before you commit to an order.
- Fast International Shipping: DHL / FedEx / UPS express options with export documentation for customs clearance.
- Competitive B2B Pricing: Volume discounts available for MRO contracts and system integrators.
Frequently Asked Questions
Q: Is 3HAC038768-0001 the same as DSQC402?
A: Yes. DSQC402 is the functional designation; 3HAC038768-0001 is the ABB spare part ordering number. Both refer to the same 15-meter panel extension cable. The cross-references 3HNA014320001 and 1200SMB are also equivalent.
Q: Which ABB robot controllers is this cable compatible with?
A: The DSQC402 / 3HAC038768-0001 is designed for ABB IRC5 family controllers (Single Cabinet, Compact, Panel Mounted) and S4C+ controllers. Please confirm your controller generation when submitting an inquiry.
Q: Can I use a shorter cable instead of the 15m version?
A: ABB offers panel extension cables in multiple lengths. The 15m version (3HAC038768-0001) is specified for large-cell installations. Contact us if you need a different length — we can advise on the correct part number.
Q: Do you ship internationally?
A: Yes. We ship globally via DHL, FedEx, and UPS Express. Export documentation and commercial invoices are provided for customs clearance in all major markets.
Q: What is the lead time?
A: Lead time depends on stock availability and your location. In-stock items typically ship within 1–3 business days. Submit an RFQ for a confirmed lead time.
Q: Can I get a test report or certificate of conformance?
A: Yes. Inspection reports and certificates of conformance are available on request for MRO and OEM procurement teams.
