Industrial Robot Axis Drive Solution – ABB IRB6700 Motor Incl Pinion | 3HAC046232-005 / 3HAC046232-008 / 3HAC042495-008
Where This Product Is Used
The ABB IRB6700 Motor Incl Pinion is a critical axis drive component deployed across high-demand industrial environments where precision motion control and continuous-duty reliability are non-negotiable:
- Automotive Body-in-White (BIW) Welding Lines – Drives the IRB6700 robot arm through repetitive spot-weld cycles at OEM assembly plants, maintaining ±0.05 mm repeatability over millions of cycles.
- Heavy Payload Palletizing & Material Handling – Powers axis joints for stacking, de-stacking, and transferring loads up to 235 kg in logistics and warehousing automation cells.
- Foundry & Die-Casting Extraction – Operates reliably in high-temperature, high-vibration environments where standard motors fail prematurely.
- Machine Tending & CNC Loading – Provides the torque and positional accuracy required for consistent part placement in precision machining cells.
- Structural Steel & Heavy Fabrication Welding – Sustains long arc-on times in robotic MIG/MAG welding of structural components.
Technical Specifications
| Parameter | Value |
|---|---|
| Part Numbers | 3HAC046232-005 / 3HAC046232-008 / 3HAC042495-008 |
| Compatible Robot | ABB IRB6700 Series (all variants) |
| Component Type | Servo Motor with Integrated Pinion Gear |
| Application | Axis Drive (Axis 1–6, model-dependent) |
| Manufacturer | ABB Robotics |
| Weight | 420 g (module only) |
| Condition | New / OEM-Grade Replacement |
| Country of Origin | Sweden / China (ABB manufacturing) |
| Shipping | Worldwide – DHL / FedEx / UPS |
Why Engineers Specify This Model
- OEM Dimensional Compatibility – Drop-in replacement; no mechanical modification required on the IRB6700 gearbox housing.
- Integrated Pinion Design – Pre-assembled pinion eliminates field alignment errors and reduces MTTR (Mean Time To Repair) by up to 40%.
- High Cycle Endurance – Rated for continuous-duty operation in 24/7 production environments with minimal thermal derating.
- ABB RobotWare Compatibility – Fully compatible with ABB IRC5 and OmniCore controller platforms; no parameter reconfiguration required after swap.
- Reduced Downtime Risk – Stocking this part as a critical spare eliminates multi-week OEM lead times during unplanned breakdowns.
Complete System Bill of Materials
For a complete IRB6700 axis motor replacement, engineers typically source the following alongside this motor:
- ABB Gearbox Unit (axis-specific) – 3HAC series
- Resolver / Encoder Cable Assembly – 3HAC series
- Motor Mounting Bolts & Sealing Kit
- ABB IRC5 Drive Module (if drive fault is concurrent)
- Thermal Grease / Gasket Set for gearbox interface
Contact support@konmask.com for a complete BOM quote for your IRB6700 configuration.
Compliance & Industry Standards
- CE Marked – Compliant with EU Machinery Directive 2006/42/EC
- RoHS Compliant – Restriction of Hazardous Substances Directive
- ISO 9283 – Manipulating Industrial Robots: Performance Criteria
- IEC 60034 – Rotating Electrical Machines standard
- REACH Compliant – No restricted substances above threshold limits
Quality Assurance & Sourcing
All ABB spare parts supplied by Konmask.com are sourced through verified industrial distribution channels. Each unit undergoes:
- Visual and dimensional inspection against ABB engineering drawings
- Part number and date-code verification
- Anti-static packaging with humidity indicator cards
- Traceability documentation available on request
We do not supply counterfeit, refurbished-as-new, or grey-market components. Authenticity guaranteed or full refund.
How to Source This Part
- Add to Cart – Click “Buy Now” or “Add to Cart” above.
- Request a Quote – Email support@konmask.com with your robot serial number and axis configuration for a tailored quote.
- Bulk / Project Orders – Volume pricing available for MRO stocking programs and system integrators. Minimum order quantities may apply.
- Urgent Breakdown Support – Call/WhatsApp +0086 19859288691 for same-day shipping assessment on critical breakdown orders.
Application-Specific FAQ
Q: Is this motor compatible with all IRB6700 payload variants (150/175/200/235 kg)?
A: Compatibility depends on the specific axis and variant. Please confirm your robot’s article number (e.g., IRB6700-200/2.60) before ordering. Contact us for verification.
Q: Do I need to recalibrate the robot after replacing this motor?
A: Yes. After any axis motor replacement on the IRB6700, a fine calibration procedure using the ABB CalibWare tool or Levelmeter 2000 is required to restore positional accuracy.
Q: What is the lead time?
A: In-stock units ship within 1–2 business days. Out-of-stock items typically have a 5–15 business day lead time depending on ABB supply chain status.
Q: Can this replace both 3HAC046232-005 and 3HAC046232-008?
A: These part numbers represent revision levels of the same motor assembly. Cross-compatibility should be confirmed against your robot’s maintenance manual or by contacting our technical team.
Q: Do you provide installation support?
A: We provide documentation and remote technical guidance. On-site installation services can be arranged through our partner network in select regions.
