Genuine ABB IRB140 Upper Arm Spare Std/F | IRB 140 Series – Verified Source
Konmask.com supplies genuine ABB upper arm assemblies for the IRB 140 industrial robot platform. This structural spare part is critical to maintaining the full 6-axis articulation, payload capacity, and positional repeatability of your IRB 140 installation. All units are sourced through verified ABB distribution channels and undergo multi-point inspection before dispatch.
Primary Part Numbers: 3HAC021965-002 | 3HAC038547-002 | 3HAC10467-1
Applicable Robot: ABB IRB 140 (Std / Foundry variants)
OEM Brand: ABB Robotics (Sweden)
Technical Specifications
| Attribute | Detail |
|---|---|
| Part Number (Primary) | 3HAC021965-002 |
| Cross-Reference | 3HAC038547-002 / 3HAC10467-1 |
| Description | Upper Arm, Spare, Std/F |
| Compatible Robot | ABB IRB 140 (all variants) |
| Robot Payload | 6 kg |
| Robot Reach | 810 mm |
| Axes Supported | Axis 3–6 structural linkage |
| Variant Coverage | Standard (Std) & Foundry (F) |
| Country of Origin | Sweden |
| OEM Brand | ABB Robotics |
| Condition | New / Surplus New (specify on inquiry) |
| Warranty | 12 months (OEM standard) |
Our 4-Step Quality Verification Process
Every ABB spare part shipped from Konmask.com passes through a rigorous 4-step verification protocol designed for industrial procurement engineers:
- Source Authentication – Parts are procured exclusively from ABB-authorized distributors or directly from ABB Robotics inventory. No grey-market or counterfeit channels.
- Physical Inspection – Each unit is inspected for OEM markings, part number labels, casting integrity, and surface finish against ABB reference standards.
- Functional Pre-Check – Where applicable, mechanical fit and articulation points are verified against ABB IRB 140 assembly drawings.
- Documentation Package – Shipment includes packing list, part number certificate, and traceability record. CE/RoHS documentation available on request.
Key Features & Benefits
- ✅ OEM Genuine Part – Maintains ABB warranty compliance and robot certification status
- ✅ Dual Variant Coverage – Single SKU covers both Standard and Foundry (IP67) configurations
- ✅ Drop-In Replacement – No machining or modification required; direct fit to IRB 140 axis 3 mounting interface
- ✅ Precision Repeatability – Preserves ±0.03 mm positional repeatability specification of the IRB 140
- ✅ Reduced Downtime – In-stock availability enables same-week dispatch for urgent MRO requirements
- ✅ Global Export Ready – EXW, FOB, CIF Incoterms available; export documentation prepared for customs clearance
Typical Applications
- Scheduled preventive maintenance overhaul of ABB IRB 140 robot cells
- Collision damage repair – upper arm structural replacement after axis 3–4 impact event
- Foundry environment refurbishment (Std → F variant upgrade)
- Spare parts inventory replenishment for multi-robot automotive and electronics assembly lines
- OEM integrator build-out requiring pre-sourced structural spares
Compatible System Components
This upper arm assembly is designed to interface with the following ABB IRB 140 system components:
- Lower arm assembly – 3HAC021964-001
- Axis 3 gearbox – 3HAC026510-001
- Axis 4 motor unit – 3HAC026518-001
- Wrist unit (Std) – 3HAC021966-001
- IRC5 / IRC5 Compact controller
- RobotWare 5.x / 6.x software platform
Contact our engineering team to confirm compatibility with your specific robot serial number and software version.
Global Sourcing & Shipping Capabilities
- Stock Location: China (Xiamen) warehouse with EU/US forwarding partners
- Lead Time: In-stock orders ship within 3–5 business days; sourced orders 2–4 weeks
- Shipping Methods: DHL Express, FedEx International Priority, sea freight (LCL/FCL)
- Incoterms: EXW, FOB Xiamen, CIF destination port
- Export Markets: EU, USA, Southeast Asia, Middle East, Australia
- Customs Support: Commercial invoice, packing list, HS code declaration, COO certificate provided
Certifications & Compliance Statement
ABB IRB 140 spare parts supplied by Konmask.com comply with the following standards and declarations:
- CE Marking – Machinery Directive 2006/42/EC (as part of ABB robot system)
- RoHS 2 Directive 2011/65/EU – Hazardous substance compliance
- ISO 9283 – Manipulating industrial robots: performance criteria
- ABB OEM Part Traceability – Full supply chain documentation available on request
How to Order
- Confirm Part Number – Verify 3HAC021965-002, 3HAC038547-002, or 3HAC10467-1 against your robot’s spare parts manual (document 3HAC021999-001)
- Submit Inquiry – Email support@konmask.com with quantity, required delivery date, and destination port
- Receive Quotation – We respond within 1 business day with price, lead time, and Incoterm options
- Confirm & Pay – T/T bank transfer, PayPal, or Shopify secure checkout accepted
- Dispatch & Track – Tracking number and shipping documents issued within 24 hours of payment clearance
Authenticity & Trust FAQ
Q: Are these genuine ABB OEM parts or aftermarket copies?
A: All parts are genuine ABB OEM. We do not stock or sell aftermarket, clone, or reverse-engineered components. Part authenticity can be verified via ABB’s serial number lookup system.
Q: Can you provide an ABB purchase certificate or distributor authorization letter?
A: Yes. Traceability documentation is available for B2B orders upon request. Please specify your requirement at the time of inquiry.
Q: What if the part does not fit my robot?
A: We offer a 30-day return policy for unused parts in original packaging. Our engineering team will assist with cross-referencing before shipment to minimize fit issues.
Q: Do you support urgent / emergency orders?
A: Yes. For production-critical downtime situations, contact us directly at +0086 19859288691 for priority processing and express freight options.
Q: Can I order multiple part numbers in one shipment?
A: Absolutely. We consolidate multi-line ABB spare part orders into a single shipment to reduce freight costs and customs complexity.
